2019 LEXUS RX350 seat adjustment

RX350/RX350L_U Pictorial index Search by illustration
1
For safety
and security Make sure to read through them
2
Instrument cluster How to read the gauges and meters, the variety of
warning lights and indicators, etc.
3
Operation of
each component Opening and closing the doors and windows,
adjustment before driving, etc.
4
Driving Operations and advice which are necessary for driving
5
Lexus Display
Audio system Operating the Lexus Display Audio system
6
Interior features Usage of the interior features, etc.
7
Maintenance
and care Caring for your vehicle and maintenance procedures
8
When trouble
arises What to do in case of malfunction or emergency
9
Vehicle
specifications Vehicle specifications, customizable features, etc.
10
For owners Reporting safety defects for U.S. owners, and seat belt,
SRS airbag and headlight aim instructions for Canadian
owners
Index Search by symptom
Search alphabetically

311-1. For safe use
1
For safety and security
RX350/RX350L_U WARNING
Observe the following precautions.
Failure to do so may result in death or serious injury.●
Do not adjust the position of the driver’s seat while driving.
Doing so could cause the driver to lose control of the vehicle. ●
Do not place a cushion between the dr iver or passenger and the seatback.
A cushion may prevent correct posture from being achieved, and reduce the effec-
tiveness of the seat be lt and head restraint.●
Do not place anything under the front seats.
Objects placed under the fr ont seats may become jammed in the seat tracks and stop
the seat from locking in plac e. This may lead to an accident and the adjustment mech-
anism may also be damaged. ●
Always observe the legal speed limi t when driving on public roads.●
When driving over long distances, take regular breaks before you start to feel tired.
Also, if you feel tired or sleepy while drivin g, do not force yourself to continue driving
and take a break immediately.

62 1-2. Child safety
RX350/RX350L_U
While pushing the child restraint
system down into the rear seat,
allow the shoulder belt to retract
until the child restraint system is
securely in place. After the shoulder belt has retracted
to a point where there is no slack in
the belt, pull the belt to check that it
cannot be extended.
After installing the child restraint syst em, rock it back and forth to ensure
that it is installed securely. (  P. 66)■
Forward-facing — Convertible seat
Adjust the seat 
When using the front passenger seat
If installing the child restraint system to the front passenger seat is unavoid-
able, refer to P. 59 for the fr ont passenger seat adjustment.
When using the rear seat
If there is a gap between the child se at and the seatback, adjust the seat-
back angle until good contact is achieved.
Remove the head restraint if it
interferes with your child restraint
system. (  P. 177)If the head restraint cannot be
removed, raise it to the uppermost
position.
Place the child restraint system
on the seat facing the front of the
vehicle. 5
6
1
2
3

64 1-2. Child safety
RX350/RX350L_U ■
Booster seat
If installing the child restraint system to the front passenger seat is unavoid-
able, refer to P. 59 for the fr ont passenger seat adjustment.
High back type: Remove the head
restraint if it interferes with your
child restraint system. (  P. 177)If the head restraint cannot be
removed, raise it to the uppermost
position.
Place the child restraint system on the seat facing the front of the vehicle.
Sit the child in the child restraint
system. Fit the seat belt to the
child restraint system according
to the manufacturer’s instructions
and insert the plate into the
buckle. Make sure that the belt is
not twisted. Check that the shoulder belt is cor-
rectly positioned over the child’s
shoulder and that the lap belt is as
low as possible. (  P. 32)1
2
3
Booster type 
High back type
4

156
RX350/RX350L_U 3-3. Adjusting the seats
Seat position adjustment switch
Seat cushion (front) angle adjust-
ment switch
Vertical height adjustment switch
Seatback angle adjustment switch
Lumbar support firmness adjust-
ment switch
Lumbar support height adjustment
switch (if equipped)
Seat cushion length adjustment
switch (if equipped) ■
Power easy access system
The driver’s seat (on some models) and steering wheel move in accordance with engine
switch mode and the driver’s seat belt condition. (  P. 172)Front seats Adjustment procedure 1
2
3
4
5
6
7
WARNING ■
When adjusting the seat position ●
Take care when adjusting the seat position to ensure that other passengers are not
injured by the moving seat. ●
Do not put your hands under the seat or near the moving parts to avoid injury.
Fingers or hands may become jammed in the se at mechanism.●
Make sure to leave enough space around the feet so they do not get stuck. ■
Seat adjustment
To reduce the risk of sliding under the lap be lt during a collision, do not recline the seat
more than necessary.
If the seat is too reclined, the lap belt may slide past the hips and apply restraint forces
directly to the abdomen, or your neck may contact the shou lder belt, increasing the risk
of death or serious injury in the event of an accident.
Adjustments should not be made while drivin g as the seat may unexpectedly move and
cause the driver to lose control of the vehicle.

1573-3. Adjusting the seats
3
Operation of each component
RX350/RX350L_U 
Manual seat
Seatback angle adjustment lever
Seat position adjustment lever 
Power seat
Seatback angle adjustment switch
Seat position adjustment leverRear seats Second-row seats (RX350)
1
2
1
2

158 3-3. Adjusting the seats
RX350/RX350L_U 
Separate seat
Seatback angle adjustment lever
Seat position adjustment lever
Seatback folding lever 
Bench seat
Seatback angle adjustment lever
Seat position adjustment lever
Seatback folding leverSecond-row seats (RX350L)
1
2
3
1
2
3

160 3-3. Adjusting the seats
RX350/RX350L_U ■
Before folding the rear seatbacks
Stow the center seat seat belt buckle.
Lower the rear seat head restra ints to the lowest position. (  P. 177)■
Folding the rear seatbacks (manual seat) 
Using the seatback angle adjustment lever
Pull the lever and fold the rear seat-
back. 
Using the lever in the luggage compartment
Pull the lever and fold the rear seat-
back.Folding the second-row seat seatbacks (RX350) 1
2
