2019 LEXUS RCF Owners Manual

4977-2. Steps to take in an emergency
RC F_U 7
When trouble arises Chock the tires.
Slightly loosen the wheel nuts (one
turn).
Turn the tire jack portion “A” by hand
until the notch of the jack is in con-
tact with the jack point. The jack point guides are located under
the rocker panel. They indicate the jack
point positions. WARNING ■
When storing the spare tire
Be careful not to catch fingers or other body parts between the spare tire and the body
of the vehicle.
Replacing a flat tire 1
Flat tire Wheel chock positions
Front Left-hand side Behind the rear right-hand side tire
Right-hand side Behind the rear left-hand side tire
Rear Left-hand side In front of the front right-hand side tire
Right-hand side In front of the front left-hand side tire2
3

498 7-2. Steps to take in an emergency
RC F_U Raise the vehicle until the tire is
slightly raised off the ground.
Remove all the wheel nuts and the
tire. When resting the tire on the ground,
place the tire so that the wheel design
faces up to avoid scratching the wheel
surface. 4
5
WARNING ■
Replacing a flat tire ●
Do not touch the disc wheels or the area around the brakes immediately after the
vehicle has been driven.
After the vehicle has been driven the disc wheels and the area around the brakes will
be extremely hot. Touching these areas with hands, feet or other body parts while
changing a tire, etc. may result in burns. ●
Failure to follow these precautions could cau se the wheel nuts to loosen and the tire
to fall off, resulting in death or serious injury.
• Never use oil or grease on the wheel bolts or wheel nuts.
Oil and grease may cause the wheel nuts to be excessively tightened, leading to
bolt or disc wheel damage. In addition, the oil or grease can cause the wheel nuts
to loosen and the wheel may fall off, causing a serious accident. Remove any oil or
grease from the wheel bolts or wheel nuts.
• Have the wheel nuts tightened with a torque wrench to 76 ft•lbf (103 N•m,
10.5 kgf•m) as soon as possible after changing wheels.
• Do not attach a heavily damaged wheel or nament, as it may fly off the wheel while
the vehicle is moving.
• When installing a tire, only use wheel nuts that have been specifically designed for
that wheel.
• If there are any cracks or deformations in the bolt screws, nut threads or bolt holes
of the wheel, have the vehicle inspected by your Lexus dealer.

4997-2. Steps to take in an emergency
RC F_U 7
When trouble arises Remove any dirt or foreign matter
from the wheel contact surface. If foreign matter is on the wheel contact
surface, the wheel nuts may loosen
while the vehicle is in motion, causing
the tire to come off.
Install the spare tire and loosely tighte n each wheel nut by hand by approxi-
mately the same amount.
When replacing an aluminum wheel
with a steel wheel, tighten the wheel
nuts until the tapered portion comes
into loose contact with the disc
wheel seat.
When replacing an aluminum wheel
with an aluminum wheel, turn the
wheel nuts until the washers come
into contact with the disc wheel.
Lower the vehicle.Installing the spare tire 1
2
Disc wheel
seatTapered portion
WasherDisc wheel
3

500 7-2. Steps to take in an emergency
RC F_U Firmly tighten each wheel nut two or
three times in the order shown in the
illustration. Tightening torque:
76 ft•lbf (103 N•m, 10.5 kgf•m)
Stow the flat tire, tire jack and all tools. ■
The spare tire ●
RC350/RC300:
The spare tire is identified by the label “TEMPORARY USE ONLY” on the tire sidewall.●
Use the spare tire temporarily , and only in an emergency.●
Make sure to check the tire inflat ion pressure of the spare tire. (  P. 548)■
When using the spare tire
As the spare tire is not equipped with a tire pressure warning valv e and transmitter, low
inflation pressure of the spare tire will not be indicated by the tire pressure warning sys-
tem. Also, if you replace the spare tire after the tire pressure warn ing light comes on, the
light remains on. ■
When the spare tire is equipped
The vehicle becomes lower when driving with the spare tire compared to when driving
with standard tires. ■
If you have a flat rear tire on a road covered with snow or ice (vehicles with front and
rear tires of the same size except fo r vehicles with LDH and 19-inch tires)
Install the spare tire on one of the front whee ls of the vehicle. Perform the following steps
and fit tire chains to the rear tires:
Replace a front tire with the spare tire.
Replace the flat rear tire with the tire removed from the front of the vehicle.
Fit tire chains to the rear tires. 4
5
1
2
3

5017-2. Steps to take in an emergency
RC F_U 7
When trouble arises WARNING ■
When using the spare tire ●
Remember that the spare tire provided is specifically designed for use with your vehi-
cle. Do not use your spare tire on another vehicle. ●
Do not use more than one spare tires simultaneously. ●
Replace the spare tire with a stan dard tire as soon as possible.●
Avoid sudden acceleration, abrupt steering, sudden braking and shifting operations
that cause sudden engine braking. ■
When the spare tire is attached
The vehicle speed may not be correctly detected, and the following systems may not
operate correctly:
Also, not only can the following system not be utilized fully, but it may even negatively
affect the drive-train components:
• AWD system (if equipped) ■
Speed limit when using the spare tire
Do not drive at speeds in excess of 50 mp h (80 km/h) when a spar e tire is installed on
the vehicle.
The spare tire is not designed for driving at high speeds. Fa ilure to observe this precau-
tion may lead to an accident causing death or serious injury. ■
After using the tools and jack
Before driving, make sure all the tools and jack are securely in place in their storage
location to reduce the possibilit y of personal injury during a collision or sudden brak-
ing.
NOTICE ■
Driving with tire chains and the spare tire
Do not fit tire chains to the spare tire.
Tire chains may damage the vehicle body and adversely affect driving performance.■
When replacing the tires
When removing or fitting the wheels, tires or the tire pressure warning valve and trans-
mitter, contact your Lexus dealer as the tire pressure warning valve and transmitter
may be damaged if not handled correctly.• ABS & Brake assist
•VSC
•TRAC
• Dynamic radar cruise control
•PCS
•EPS
• Adaptive Variable Suspension System
(if equipped)
• LDA (Lane Departure Alert with
steering control)
• VGRS (if equipped) • LDH (Lexus Dynamic Handling sys-
tem) (if equipped)
• DRS (Dynamic Rear Steering) (if
equipped)
• VDIM (Vehicle Dynamics Integrated
Management)
• Tire pressure warning system
• Lexus parking assist monitor
• Intuitive parking assist (if equipped)
• Navigation system (if equipped)

502 7-2. Steps to take in an emergency
RC F_UIf you have a flat tire (v ehicles with an emergency
tire puncture repair kit) Your vehicle is not equipped with a spar e tire, but instead is equipped with an
emergency tire puncture repair kit.
A puncture caused by a nail or screw passing through the tire tread can be
repaired temporarily with the emer gency tire puncture repair kit.WARNING ■
If you have a flat tire
Do not continue driving with a flat tire.
Driving even a short distance with a flat ti re can damage the tire and the wheel beyond
repair. Driving with a flat tire may cause a circumferential groove on the side wall. In
such a case, the tire may explode when using the emergency tire puncture repair kit,
resulting in death or serious injury.

5037-2. Steps to take in an emergency
RC F_U 7
When trouble arises ●
Stop the vehicle in a safe pl ace on a hard, flat surface.●
Set the parking brake. ●
Shift the shift lever to P. ●
Stop the engine. ●
Turn on the emergency flashers. (  P. 442)●
Check the degree of the tire damage.
A tire should only be repaired with
the emergency tire puncture repair
kit if the damage is caused by a nail
or screw passing through the tire
tread.
• Do not remove the nail or screw
from the tire. Removing the
object may widen the opening
and disenable emergency repair
with the kit.
• To avoid sealant leakage, move the vehi cle until the area of the puncture, if
known, is positioned at the top of the tire. ■
A flat tire that cannot be repaired with the emergenc y tire puncture repair kit
In the following cases, the tire cannot be repaired with the emergency tire puncture
repair kit. Contact your Lexus dealer. ●
When the tire is damaged due to driving without sufficient air pressure ●
When the tire lost air pressure due to a crack or damage in the tire sidewall●
When the tire is visibly separated from the wheel ●
When the cut or damage to the tread is 0.16 in. (4 mm) long or more ●
When the wheel is damaged ●
When 2 or more sharp objects, such as nails or screws, have passed through the tread
on a single tire ●
When there is more than one hole or cut in the damaged tire ●
When the sealant has expiredBefore repairing the vehicle

504 7-2. Steps to take in an emergency
RC F_U * : Use of the jack (  P. 497)Location of the emergency tire puncture repair kit, jack and tools
Jack handle
Wheel nut wrench
Screwdriver
Towing eyelet Emergency tire puncture repair
kits
Jack
*1
2
3
4 5
6
