2019 Lexus ES300h Owner's Manual Quick Guide (OM33D23U)

9
ES300h_QG_OM33D23U_(U)
■Interior
SRS airbags*
Floor mats ..................................................................................................................... .P.11
Front seats ................................................................................................................... P .18
Head restraints
*
Seat belts*
Inside lock buttons ................................................................................................... P.88
Console box
*
Cup holder*
Assist grips*
*
: Refer to the “OWNER’S MANUAL”.
A
B
C
D
E
F
G
H
I

10
ES300h_QG_OM33D23U_(U)
■Ceiling
Interior lights*1
Personal lights*1
Moon roof switches*1, 2
“SOS” button*2........................................................................................................ P.83
Door-linked personal light switch
*1
Vanity mirrors*1
Sun visors*1
Inside rear view mirror*1
Garage door opener buttons................................................................................ P.79
*1: Refer to the “OWNER’S MANUAL”.
*2: If equipped
A
B
C
D
E
F
G
H
I

11
ES300h_QG_OM33D23U_(U)
1Insert the retaining hooks (clips) into
the floor mat eyelets.
2Turn the upper knob of each retaining
hook (clip) to secure the floor mats in
place.
Always align the marks .
The shape of the retaining hooks (clips) may di ffer from that shown in the illustration.
Floor Mat Installation
Use only floor mats designed specifically for vehicles of the same model and model year
as your vehicle. Fix them securely in place onto the carpet.
A

12
ES300h_QG_OM33D23U_(U)
Charge area
Shows regeneration
* status. Regener-
ated energy will be used to charge the
hybrid battery (traction battery).
*: When used in this manual, “regenera-
tion” refers to the conversion of energy
created by the movement of the vehicle
into electrical energy.
Hybrid Eco area
Shows that gasoline engine power is not being used very often.
The gasoline engine will automatically stop and restart under various conditions.
Eco area
Shows that the vehicle is being dr iven in an Eco-friendly manner.
By keeping the bar display with in Eco area, more Eco-friendly driving can be achieved.
Power area
Shows that an Eco-friendly driving range is being exceed ed (during full power driving
etc.)
If the shift lever is in N, th e hybrid battery (traction battery) will not be charged even when
the engine is running. Therefore, if the vehicle is left with the shift lever in N for a certain
period of time, the hybrid battery (traction battery) will discharge, and this may result in the
vehicle not being able to start.
Hybrid System
Your vehicle is a hybrid vehicle. It has charac teristics different from conventional vehicles.
Be sure you are closely familiar with the characteristics of your vehicle, and operate it with
care.
The hybrid system combines the use of a gaso line engine and an electric motor (traction
motor) according to driving conditions, impr oving fuel efficiency and reducing exhaust
emissions.
For details, refer to the “OWNER’S MANUAL”.
Hybrid System Indicator
A
Hybrid battery (traction battery) charge
B
C
D

13
ES300h_QG_OM33D23U_(U)
In the following situations, kinetic energy is converted to electric energy and deceleration
force can be obtained in conjunction with the recharging of the hybrid battery (traction bat-
tery).
● The accelerator pedal is released while driving with the shift lever in D or S.
● The brake pedal is depressed while driv ing with the shift lever in D or S.
There may be no engine sound or vibration even though the vehicle is able to move with the
“READY” indicator is illuminated. For safety, apply the parking brake and make sure to shift
the shift lever to P when parked.
The following sounds or vibrat ions may occur when the hybrid system is operating and are
not a malfunction:
● Motor sounds may be heard from the engine compartment.
● Sounds may be heard from the hybrid battery (traction battery) behind the rear seats
when the hybrid syst em starts or stops.
● Relay operating sounds such as a snap or so ft clank will be emitted from the hybrid bat-
tery (traction battery), behind the rear seats, when the hybrid system is started or
stopped.
● Sounds from the hybrid system may be heard when the trunk lid is open.
● Sounds may be heard from the transmission when the gasoline engine starts or stops,
when driving at low speeds, or during idling.
● Engine sounds may be heard when accelerating sharply.
● Sounds may be heard due to regenerative braking when the brake pedal is depressed or
as the accelerator pedal is released.
● Vibration may be felt when the gasoline engi ne starts or stops.
● Cooling fan sounds may be heard from th e air intake vent under the rear seat.
Regenerative braking
Sounds and vibrations specific to a hybrid vehicle

14
ES300h_QG_OM33D23U_(U)
When the vehicle has run out of fuel and the hybrid system cannot be started, refuel the
vehicle with at least enough gasoline to make the low fuel level warning light go off. If there is
only a small amount of fuel, the hybrid system may not be able to start. (The standard amount
of fuel is about 2.4 gal. [9.0 L, 2.0 Imp.gal.], when the vehicle is on a level surface. This value
may vary when the vehicle is on a slope. Add extra fuel when the vehicle is inclined.)
A message is automatically disp layed when a malfunction occurs in the hybrid system or an
improper operation is attempted.
If a warning message is shown on the multi-
information display, read the message and
follow the instructions.
Running out of fuel
Hybrid warning message

15
ES300h_QG_OM33D23U_(U)
●Smart access system with push-button
start ( P.16)
● Wireless remote control
To take out the mechanical key, push the
release button and take the key out.
The mechanical key can only be inserted in
one direction, as the key only has grooves
on one side. If the key cannot be inserted in
a lock cylinder, turn it over and re-attempt
to insert it.
After using the mechanic al key, store it in
the electronic key. Carry the mechanical
key together with the electronic key. If the
electronic key battery is depleted or the
entry function does not operate properly,
you will need the mechanical key.
Locks the doors
Unlocks the doors
Opens the windows and moon roof
(press and hold)
*
Opens the trunk
Sounds the alarm
*: This setting must be customized at your Lexus dealer.
Keys
Electronic key
Mechanical key
Wireless remote control
A
B
C
D
E

16
ES300h_QG_OM33D23U_(U)
1Grip the driver’s door handle to unlock
the door. Holding the driver’s door
handle for approximately 2 seconds
unlocks all the doors. Grip the passen-
ger’s door handle to unlock all the
doors.
*
Make sure to touch the sensor on the
back of the handle.
The doors cannot be unlocked for
3 seconds after the doors are locked.
*: The door unlock settings can bechanged.
2Touch the lock sensor (the indentation on the upper part of the door handle) to lock all
the doors.
Check that the door is securely locked.
Smart Access System with Push-button Start
The following operations can be performed si mply by carrying the electronic key on your
person, for example in your pocket. The driv er should always carry the electronic key.
For details on starting the hybrid system, see page 19.
Unlocking and locking the doors from the outside
