2019 FIAT 500E service schedule

The RBS uses conventional hydraulic friction brakes, re-
generative braking, or a combination to slow the vehicle. If
the system detects slippery conditions while braking,
ONLY friction is used to slow the vehicle. The RBS can
result in extended life of the hydraulic service brakes;
however, all inspection, scheduled maintenance, and ser-
vice intervals for the vehicle service brakes must be fol-
lowed.
AUXILIARY DRIVING SYSTEMS
Tire Pressure Monitor System
The Tire Pressure Monitor System (TPMS) will warn the
driver of a low tire pressure based on the vehicle recom-
mended cold placard pressure.
The tire pressure will vary with temperature by about 1psi
(7 kPa) for every 12°F (6.5°C). This means that when the
outside temperature decreases, the tire pressure will de-
crease. Tire pressure should always be set based on cold
inflation tire pressure. This is defined as the tire pressure
after the vehicle has not been driven for at least three
hours, or driven less than 1 mile (1.6 km) after a three hour
period. The cold tire inflation pressure must not exceed the
maximum inflation pressure molded into the tire sidewall.
Refer to “Tires – General Information” in “Servicing AndMaintenance” for information on how to properly inflate
the vehicle’s tires. The tire pressure will also increase as the
vehicle is driven. This is normal and there should be no
adjustment for this increased pressure.
The TPMS will warn the driver of a low tire pressure if the
tire pressure falls below the low-pressure warning limit for
any reason, including low temperature effects and natural
pressure loss through the tire.
The TPMS will continue to warn the driver of low tire
pressure as long as the condition exists, and will not turn
off until the tire pressure is at or above the recommended
cold placard pressure. Once the low tire pressure warning
(Tire Pressure Monitoring System Warning Light) illumi-
nates, you must increase the tire pressure to the recom-
mended cold placard pressure in order for the Tire Pressure
Monitoring System Warning Light to turn off. The system
will automatically update and the Tire Pressure Monitoring
System Warning Light will turn off once the system re-
ceives the updated tire pressures. The vehicle may need to
be driven for up to 20 minutes above 15 mph (24 km/h) in
order for the TPMS to receive this information.
For example, your vehicle may have a recommended cold
(parked for more than three hours) placard pressure of 33
psi (227 kPa). If the ambient temperature is 68°F (20°C) and
5
SAFETY 107

SERVICING AND MAINTENANCE
CONTENTS
SCHEDULED SERVICING .................211
▫ Maintenance Plan .......................211
 UNDERHOOD COMPARTMENT ............214
▫ Adding Washer Fluid ...................215
▫ Maintenance-Free Battery 12 Volt ...........215
 DEALER SERVICE ...................... .216
▫ Power Electronics And Battery Thermal
Management Systems ....................217
▫ Power Electronics And Battery Thermal
Management Systems — Coolant Level Check . .217
▫ Power Electronics And Battery Thermal
Management Systems — Cooling Pressure
Caps ............................... .219
▫ Selection Of Coolant .....................219
▫ Adding Coolant ....................... .220▫
Power Electronics And Battery Thermal
Management Systems — Drain, Flush And
Refill ............................... .220
▫ Disposal Of Used Power Electronics And Battery
Thermal Management Systems Coolant .......221
▫ Points To Remember .....................221
▫ Air Conditioner Maintenance ..............222
▫ Body Lubrication ..................... .223
▫ Windshield Wiper Blades .................223
▫ Brake System ........................ .225
 RAISING THE VEHICLE ..................226
 TIRES ............................... .226
▫ Tire Safety Information ..................226
▫ Tires — General Information ..............234
▫ Tire Types ........................... .240
8

SCHEDULED SERVICING
Once A Month Or Before A Trip:
•Check windshield washer fluid level
• Check the tire inflation pressures and look for unusual
wear or damage
• Check the fluid levels of the coolant reservoirs and brake
master cylinder
• Check function of all interior and exterior lights
Maintenance Plan
Required Maintenance Intervals
Refer to the maintenance schedules on the following page
for the required maintenance intervals.
At Every Service Interval:
• Rotate the tires. Rotate at the first sign of irregular
wear.
• Inspect brake pads, shoes, rotors, drums, and hoses.
• Inspect battery cooling system protection and
hoses.
• Check and adjust hand brake.
Refer to the Maintenance Plan on the following pages for
the required maintenance intervals.
8
SERVICING AND MAINTENANCE 211

CAUTION!(Continued)
positive post and the negative cable is attached to the
negative post. Battery posts are marked positive (+)
and negative (-) and are identified on the battery
case. Cable clamps should be tight on the terminal
posts and free of corrosion.
• If a 12 Volt Low Voltage Battery System “fast char-
ger” is used while the battery is in the vehicle,
disconnect both vehicle battery cables before con-
necting the charger to the battery. Do not use a “fast
charger” to provide starting voltage.
DEALER SERVICE
WARNING!
Your vehicle has both a high voltage DC and AC
system as well as a 12 Volt system. DC and AC high
voltage are both extremely dangerous and can cause
severe burns, electric shock, serious injury or even
death. In order to avoid personal injuries:
•
DO NOT TOUCH THE HIGH VOLTAGE CABLES
(ORANGE COLORED) AND/OR THE CONNECTORS.
(Continued)
WARNING! (Continued)
•Follow all Caution and Warning labels attached to
the High Voltage components.
• Do not remove or replace any of the 500e System
components. All replacement or repairs of 500e Sys-
tem components should be performed by a factory-
trained technician at an authorized dealer.
The pages that follow contain the requiredmaintenance
services determined by the engineers who designed your
vehicle.
Besides those maintenance items specified in the fixed
maintenance schedule, there are other components which
may require servicing or replacement in the future.
CAUTION!
• Failure to properly maintain your vehicle or perform
repairs and service when necessary could result in
more costly repairs, damage to other components or
negatively impact vehicle performance. Immediately
have potential malfunctions examined by an autho-
rized dealer or qualified repair center.
(Continued)
216 SERVICING AND MAINTENANCE

Tread Wear Indicators
Tread wear indicators are in the original equipment tires to
help you in determining when your tires should be re-
placed.
These indicators are molded into the bottom of the tread
grooves. They will appear as bands when the tread depthbecomes a 1/16 of an inch (1.6 mm). When the tread is
worn to the tread wear indicators, the tire should be
replaced.
Refer to “Replacement Tires” in this section for further
information.
Life Of Tire
The service life of a tire is dependent upon varying factors
including, but not limited to:
•
Driving style.
• Tire pressure - Improper cold tire inflation pressures can
cause uneven wear patterns to develop across the tire
tread. These abnormal wear patterns will reduce tread
life, resulting in the need for earlier tire replacement.
• Distance driven.
• Performance tires, tires with a speed rating of V or
higher, and Summer tires typically have a reduced tread
life. Rotation of these tires per the vehicle scheduled
maintenance is highly recommended.
Tire Tread
1—WornTire
2—NewTire 238 SERVICING AND MAINTENANCE

Lights............................... .58, 154
AirBag......................... .92, 123, 152
Brake Assist Warning ..................... .106
Brake Warning ...........................92
Bulb Replacement ....................... .182
Cruise .................................99
Daytime Running .........................58
Dimmer Switch, Headlight ...................58
Exterior .............................. .154
Headlights ..............................58
High Beam ..............................59
High Beam/Low Beam Select .................58
Instrument Cluster ........................58
Lights On Reminder .......................58
Park ............................... .59, 99
Passing ............................. .58, 59
Seat Belt Reminder ........................94
Security Alarm ...........................42
Service ............................... .182
Traction Control ........................ .106
Turn Signals .....................58, 60, 99, 154
Warning Instrument Cluster Descriptions ........99
Loading Vehicle ........................... .173
Tires................................. .230Locks
Power Door .............................46
Lubrication, Body ......................... .223
Lug Nuts/Bolts ........................... .255
Maintenance Free Battery .....................215
Maintenance, General ...................... .216
Maintenance Procedures ..................... .216
Maintenance Schedule .......................211
Manual Service ............................... .286
Master Cylinder Brakes ............................... .225
Memory Seat ..............................49
Mirrors ..................................56
Automatic Dimming .......................56
Electric Powered ..........................57
Heated ............................. .56, 58
Outside ................................56
Rearview ...............................56
Modifications/Alterations V
ehicle .................................5
Mopar Parts ............................. .285
MP3 Control ............................. .273
292 INDEX

Schedule, Maintenance.......................211
Seat Belt Reminder ..........................94
Seat Belts .............................114,152
Child Restraints ........................ .135
Energy Management Feature ................120
Extender ...............................119
Front Seat .......................114,115,117
Inspection ............................. .152
Lap/Shoulder Belt Operation ................117
Lap/Shoulder Belts .......................115
Lap/Shoulder Belt Untwisting ...............119
Operating Instructions .....................117
Pregnant Women ........................ .120
Pretensioners .......................... .120
Rear Seat ..............................115
Reminder ..............................114
Seat Belt Extender ........................119
Seat Belt Pretensioner .....................120
Untwisting Procedure .....................119
Seat Belts Maintenance ...................... .251
Seats ....................................47
Adjustment .............................47
Heated .................................50
Rear Folding .............................47
Tilting .................................47 Security Alarm
.............................42
Selection Of Coolant (Antifreeze) ...............257
Sentry Key Key Programming .........................42
Sentry Key (Immobilizer) ......................41
Service Assistance ......................... .282
Service Contract .......................... .284
Service Manuals .......................... .286
Settings Personal .............................. .261
Shoulder Belts .............................115
Side View Mirror Adjustment ...................56
Signals, Turn ..................... .58, 60, 99, 154
Snow Chains (Tire Chains) ....................245
Snow Tires .............................. .241
Spare Tires ........................ .241, 242, 243
Speed Control Cancel ............................... .168
Resume .............................. .168
Speed

Control (Cruise Control) .................165
Starting ................................ .157
Button .................................39
Steering Power ............................... .164
Tilt Column .............................55
294 INDEX
