CADILLAC ESCALADE ESV 2019 Convenience & Personalization Guide ESCALADE
Convenience &
Personalization Guide
2019
cadillac.com

Page 2 of 20

CADILLAC ESCALADE ESV 2019 Convenience & Personalization Guide 2
Review this quick reference guide for an overview of some important features in your Cadillac
Escalade. Some optional equipment described in this guide (denoted by ♦) may not be included in
you

Page 3 of 20

CADILLAC ESCALADE ESV 2019 Convenience & Personalization Guide 3
Lock
Press to lock all doors.
Unlock
Press to unlock the driver’s door. Press
again to unlock all doors. Press and hold
for 4 seconds to open all windows.
Liftglass
Press twice t

3
Lock
Press to lock all doors.
Unlock
Press to unlock the driver’s door. Press
again to unlock all doors. Press and hold
for 4 seconds to open all windows.
Liftglass
Press twice to open the liftglass.
Power Liftgate
Press twice to open or close the power liftgate.
Remote Start
Use to start the engine from outside the vehicle. See Adaptive
Remote Start on page 4.
Vehicle Locator/Panic AlarmPress and release to locate your vehicle. The turn signal lamps flash
and the horn sounds.
Press and hold for 3 seconds to activate the alarm. The turn

signal lamps flash and the horn sounds for 30 seconds or until
the
button is pressed again.
Door Key
Press the button (A) on the side of the transmitter to pull the door
key out of the transmitter. Use the key to lock/unlock the driver’s
door if needed.
Note: If a transmitter is left in the vehicle when locking the vehicle, the
Remote Left in Vehicle Alert may sound. To change the Remote Keyless Entry
settings, go to Settings > Vehicle > Remote Lock, Unlock, Start.
See Keys, Doors and Windows in your Owner's Manual.
REMOTE
KEYLESS ENTRY
TRANSMITTER (KEY FOB) KEYLESS
ACCESS SYSTEM
The Keyless Access System enables operation of the doors, liftgate
and ignition without removing the Remote Keyless Entry transmit -
ter from your pocket or purse. The transmitter must be within 3
feet of the door being unlocked or within 3 feet of the liftgate.
KEYLESS UNLOCKING
With the transmitter within range:
Press the lock button on the

driver’s door handle to unlock
the driver’s door; press it again
within 5 seconds to unlock all
doors.
Press the lock button on a

passenger door handle to unlock
all doors.
Press the touch pad on the liftgate handle to open the
power liftgate.
KEYLESS LOCKING
With the ignition off, the transmitter out of the vehicle, and all
doors closed:
Press the lock button on any door handle to lock all doors
immediately.
If Passive Locking is turned on, all doors will lock automatically
after a short delay once all doors are closed.
Note: To change the door lock and unlock settings, go to Settings > Vehicle
> Remote Lock, Unlock, Start.
See Keys, Doors and Windows in your Owner's Manual.
A
♦
Optional equipment

Page 4 of 20

CADILLAC ESCALADE ESV 2019 Convenience & Personalization Guide 4
KEYLESS (PUSHBUTTON) START
The Remote Keyless
Entry (RKE) transmitter
must be in the vehicle to
turn on the ignition.
START
With the vehicle in
Park or Neutral,
press the brake pedal
and

4
KEYLESS (PUSHBUTTON) START
The Remote Keyless
Entry (RKE) transmitter
must be in the vehicle to
turn on the ignition.
START
With the vehicle in
Park or Neutral,
press the brake pedal
and then press the
ENGINE START/
STOP button to start the engine. The green indicator on the

button will illuminate.
Note: If the RKE transmitter battery is weak, place the transmitter in the
pocket in the center console storage compartment to enable the engine to
start. Replace the transmitter battery as soon as possible.
STOP/OFF
Shift to Park and press the ENGINE START/STOP button to
turn off the engine.
Power will be available for 10 minutes to operate the audio system
until the driver’s door is opened and to operate the windows and
sunroof
♦ until any door is opened.
ACCESSORY
With the engine off and the brake pedal NOT depressed, press
the ENGINE START/STOP button to place the ignition system
in the Accessory mode. The amber indicator on the button will
illuminate.
See Driving and Operating in your Owner's Manual.
ADAPTIVE REMOTE START
STARTING THE VEHICLE
1. Press and release the Lock button on the Remote Keyless
Entry transmitter.
2. Immediately press and hold the
Remote Start button until
the turn signal lamps flash (about 4 seconds).
When the vehicle starts, the doors remain locked and the park -
ing lamps will light and remain on while the engine is running.
The engine will continue running for 10 minutes. Repeat these
steps for a 10-minute time extension. Remote start can be
extended only once.
3. Before driving, press the brake pedal and then press the
ENGINE START/STOP button to turn on the ignition.
CANCELING A REMOTE START
Press and hold the Remote Start button until the parking
lamps turn off.
HEATED/COOLED SEAT OPERATION
Remote Start Auto \f#2#"H--*#"#2s – The heated or cooled
seats will turn on during a remote start when outside temperatures
warrant if the Remote Start Heated or Cooled Seats option is select -
ed in the Settings menu. Go to Settings > Vehicle > Remote Lock,
Unlock, Start. \b30',%0#+-2#1202A2&#1#2 3w-,',"'!2-01"-
not illuminate. The heated or cooled seats turn off when the igni -
tion is turned on. For the seats to remain on after the remote start,
the Auto Heated and Cooled Seats feature must be enabled.
Auto \f#2#","--*#"#21 – Anytime the vehicle is on, the
heated or cooled seats will activate automatically based on the vehi -
cle’s interior temperature. The seat button indicators will illuminate
when the heated or cooled seats are on. To enable this feature, go to
Settings > Vehicle > Climate and Air Quality.
See Keys, Doors and Windows in your Owner's Manual.

Page 5 of 20

CADILLAC ESCALADE ESV 2019 Convenience & Personalization Guide Press and hold the Cancel button to switch between regular
Cruise Control and Adaptive Cruise Control. When ACC is active, a
green
indicator illuminates and the following gap is displayed.
Wh

Press and hold the Cancel button to switch between regular
Cruise Control and Adaptive Cruise Control. When ACC is active, a
green
indicator illuminates and the following gap is displayed.
When the vehicle is turned on, the Cruise Control is set to the last
mode used.
Following Gap (Adaptive Cruise Control♦
)
Press repeatedly to set a following gap (the time between your

vehicle and a detected vehicle ahead) of Far, Medium, or Near.
When a slower vehicle is detected ahead, the
Vehicle Ahead
Indicator is displayed and the vehicle brakes to maintain the select -
ed following gap. The ACC system may slow your vehicle to a stop
behind the detected vehicle. When the ACC system is holding the
vehicle at a stop, be prepared to manually apply the brakes.
If driver action is required to apply sufficient braking behind a
detected vehicle, a red alert flashes on the windshield and the
Safety Alert Seat pulses or beeps sound (if selected). See Safety
Alert Seat on page 14.
Note: Changing the gap settings automatically changes the alert timing
sensitivity for the Forward Collision Alert system.
See Driving and Operating in your Owner's Manual.
VOICE RECOGNITION
Push to Talk
Press to interact with the OnStar, Bluetooth or Infotainment

system. Wait for the beep before speaking.
End Call/Mute
Press to end/decline a call or mute/unmute the audio system.
See Instruments and Controls in your Owner's Manual.
CRUISE CONTROL/ADAPTIVE
CRUISE CONTROL♦
On/Off
SET Set Speed
With Cruise Control on, press
the control bar down fully to
set the cruise speed. The

indicator illuminates in green.
RES Resume Speed
With Cruise Control on, press the control bar up fully to resume the
previous set speed. Adaptive Cruise Control♦ can be resumed from
a stop.
+ – Adjust Speed
When active, press the control bar up (+) or down (–) lightly to
increase or decrease the set speed by 1-mph increments; press and
hold to continue increasing/decreasing speed.
With Adaptive Cruise Control
♦, press and release the control bar
up (+) or down (–) to increase or decrease the set speed by 1-mph
increments; press and hold momentarily to increase or decrease
the set speed to the next 5-mph interval on the
speedometer.
Cancel
Press to cancel Cruise Control without erasing the set speed
from memory.
Switching between Regular Cruise Control and Adaptive
Cruise Control♦
Adaptive Cruise Control (ACC) maintains the driver-selected

following gap by braking or accelerating automatically while you
continue to steer.
5
STEERING WHEEL CONTROLS
♦ Optional equipment

Page 6 of 20

CADILLAC ESCALADE ESV 2019 Convenience & Personalization Guide 6
INSTRUMENT CLUSTER
STEERING WHEEL CONTROLS
CLUSTER DISPLAY ZONES
Use the 5-way control on the steering wheel to move between the
different display zones and scroll through the various menus in
ea

Page 7 of 20

$CADILLAC ESCALADE ESV 2019 Convenience & Personalization Guide 7 DRIVER INFORMATION CENTER The �\b�0��4�#�0�� ,�$�-�0�+��2��-�,��#�,�2�#�0��I�\bIC) on the instrument cluster can be set to display a variety of vehicle information. DIC MENUS Use the 5-w$

Page 8 of 20

CADILLAC ESCALADE ESV 2019 Convenience & Personalization Guide 8
CADILLAC USER EXPERIENCE CONTROLS
Applications♦:
Touch a screen icon to access a desired application.

Power/Mute:
Press and hold to turn
the system On/Off.
Press to mute audio.
OFF
