2018 YAMAHA WOLVERINE service

1-8
1
YAMAHA2MB-F1696-20
AVERTISSEMENT
Une pression de gonflage incorrecte des pneus ou la
s u rcharge du v éhicu le risqu ent de pro voqu er u ne perte
de contrô le ou u n capotage, entraînant des
b lessu res, v oire la mort.Ne jamais régler la pression de gonflage ni la
laisser b aisser sou s le seuil minimal; le pneu risque
de se déjanter.
CHARGE DU VÉHICULE : de 0 kg (0 l bs) à 327 kg (721 lb s)Recommandation:
AVANT:
ARRIÈRE:
Minim um:
AVANT:
ARRIÈRE:
(11 psi)
(11 psi)
(10 psi)
(10 psi)
75 kPa
75 kPa
70 kPa
70 kPa
*
La charge du v éhicule comprend le poids du conducteur,
du passager, des accessoires, de l’équipement et
(le cas échéant) du timon. Ne pas dépasser la charge
maximale du v éhicule.Poids nominal br ut du véhicule (PNBV) : 975 kg (2150 lbs)
maxim um, y compris le poids du v éhicule, du conducteur,
du passager, des accessoires, de l’équipement, et
(le cas échéant) du timon.PRESSION DE SERVICE DES PN EUS : Régler les pneu s à froid.
YAMAHA 2MB-F1696-10
WARNING
Improper tire pressure or overloading this v ehicle may
cause se vere injury or death from loss of control or
rollo ver.Ne ver set or allo w tire pressure to be belo w the minimum.
Tire may dislodge from rim. VEHICLE LOAD of 0 kg (0 lb) ~ 327 kg (721 lbs)
Recommended: FRONT:
REAR:
Minim um: FRONT:
REAR:75 kPa
75 kPa
70 kPa
70 kPa (11 psi)
(11 psi)
(10 psi)
(10 psi)
*V ehicle load is w eight of operator, passengers,
accessories, cargo, and (if applica ble) trailer tongue
w eight. Do not exceed maxim um vehicle load.Gross Vehicle Weight Rating: 975 kg (2150 lbs)
maxim um including v ehicle, weight of operator,
passengers, accessories, cargo, and (if applicab le)
trailer tongue w eight.OPERATING TIRE PRESSURE: With tires cold, set as follows.11 12
UB3D7AE0.book Page 8 Tuesday, November 7, 2017 9:38 AM

4-7
4
Odometer and tripmeters
The odometer shows the total distance trav-
eled by the vehicle. The odometer can be
used for maintenance and service intervals.
The tripmeters show the distance traveled
since they were last reset. The tripmeters can
be used to record the distance traveled on a
single trip, or to estimate the distance that
can be traveled with a full tank of gas, etc.Push the “SELECT” button to switch between
the odometer “ODO” and the tripmeters
“TRIP A” and “TRIP B” in the following order:
ODO
→ TRIP A → TRIP B → ODO
To reset a tripmeter, set the display to the
tripmeter you want to reset, then push the
“RESET” button for three seconds.
TIP The odometer will lock at 99999.
 The tripmeters will reset and continue
counting after 9999.9 is reached.
1. “SELECT” button
2. “RESET” button
3. Odometer/Tripmeter A/Tripmeter B12
3
UB3D7AE0.book Page 7 Tuesday, November 7, 2017 9:38 AM

4-27
4
WARNING
EWB00411These shock absorber assemblies contain
highly pressurized nitrogen gas. Read and
understand the following information be-
fore handling the shock absorber assem-
blies.
Do not tamper with or attempt to open
the cylinder assemblies.
 Do not subject the shock absorber as-
semblies to an open flame or other high
heat source. This may cause the unit to
explode due to excessive gas pressure. 
Do not deform or damage the cylinders
in any way. Cylinder damage will result in
poor damping performance.
 Do not dispose of a damaged or worn
out shock absorber assembly yourself.
Take the shock absorber assembly to a
Yamaha dealer for any service.
EBU33623Rear shock absorbersThe rear shock absorber assemblies are
equipped with a spring preload adjusting nut,
a rebound damping force adjusting screw, a
fast compression damping force adjusting
bolt, and a slow compression damping force
adjusting screw.
WARNING
EWB02492 Suspension components become hot
during operation. Never touch the com-
pression damping force adjusting bolt
and screw, the rebound damping force
Slow compression damping force settings:
Minimum (soft):18 click(s) in direction (b)*
Standard: 12 click(s) in direction (b)*
Maximum (hard): 1 click(s) in direction (b)*
* With the adjusting screw fully turned in di- rection (a)
UB3D7AE0.book Page 27 Tuesday, November 7, 2017 9:38 AM

4-32
4
WARNING
EWB03500These shock absorber assemblies contain
highly pressurized nitrogen gas. Read and
understand the following information be-
fore handling the shock absorber assem-
blies.
 Do not tamper with or attempt to open
the cylinder assemblies.
 Do not subject the shock absorber as-
sembly to an open flame or other high
heat source. This may cause the unit to
explode due to excessive gas pressure. 
Do not deform or damage the cylinders
in any way. Cylinder damage will result in
poor damping performance.
 Do not dispose of a damaged or worn
out shock absorber assembly yourself.
Take the shock absorber assembly to a
Yamaha dealer for any service.
EBU31552Trailer hitch bracket and receiver
Slow compression damping force settings: Minimum (soft):18 click(s) in direction (b)*
Standard: 12 click(s) in direction (b)*
Maximum (hard): 1 click(s) in direction (b)*
* With the adjusting screw fully turned in di- rection (a)
1. Trailer hitch bracket
2. Receiver
1
2
UB3D7AE0.book Page 32 Tuesday, November 7, 2017 9:38 AM

5-1
5
EBU31574
FOR YOUR SAFETY – PRE-OPERATION CHECKS
EBU31584Before starting off, inspect the vehicle to make sure it is in safe operating condition. Use the fol-
lowing checklist and related information as a guide. Also, follow the service intervals in the peri-
odic maintenance chart to keep the vehicle in safe operating condition.
WARNING
EWB00482Failure to inspect or maintain the vehicle properly increases the possibility of an accident
or equipment damage. Do not operate the vehicle if you find any problem. If a problem can-
not be corrected by the procedures provided in this manual, have the vehicle inspected by
a Yamaha dealer. Pre-operation checklist
ITEM ROUTINE PAGE
Brakes • Check operation, free play, fluid level, and fluid leakage.
• Fill with DOT 4 brake fluid if necessary. 5-3, 8-39, 8-42
Parking brake • Check for proper operation. 8-42
Fuel • Check fuel level.
• Fill with the recommended fuel if necessary. 5-3
Engine oil • Check oil level.
• Fill with oil to proper level if necessary. 5-5, 8-14
UB3D7AE0.book Page 1 Tuesday, November 7, 2017 9:38 AM

8-1
8
EBU32005PERIODIC MAINTENANCE AND ADJUSTMENTEBU32010Periodic inspection, adjustment, and lubrica-
tion will keep your vehicle in the safest and
most efficient condition possible. Safety is an
obligation of the vehicle owner/operator. The
most important points of vehicle inspection,
adjustment, and lubrication are explained on
the following pages.
WARNING
EWB01842Failure to properly maintain the vehicle or
performing maintenance activities incor-
rectly may increase your risk of injury or
death during service or while using the ve-
hicle. If you are not familiar with vehicle
service, have a Yamaha dealer perform the
service.
WARNING
EWB02563Turn off the engine when performing main-
tenance unless otherwise specified.
A running engine has moving parts that
can catch on body parts or clothing and
electrical parts that can cause shocks or
fires.
 Running the engine while servicing can
lead to eye injury, burns, fire, or carbon
monoxide poisoning - possibly leading
to death. See page 2-5 for more informa-
tion about carbon monoxide.
WARNING
EWB02691Brake discs, calipers, drums, and linings
can become very hot during use. To avoid
possible burns, let brake components cool
before touching them.
UB3D7AE0.book Page 1 Tuesday, November 7, 2017 9:38 AM

8-2
8
EBU33561Owner’s Manual and tool kitYou are recommended to put this manual in
the vinyl bag and always carry it in the glove
compartment as shown. Put the tool kit and
tire pressure gauge under the passenger
seat.The maintenance information included in this
manual is intended to provide you, the owner,
with the necessary information for completing
your own preventive maintenance and minor
repairs.
The tools provided in the tool kit are sufficient
for this purpose, and should be kept on the
vehicle in case of emergency repairs.
Other tools and equipment are required for
certain service items. If you do not have a
torque wrench available during a service op-1. Owner’s Manual
1
1. Tool kit
2. Tire pressure gauge
1
2
UB3D7AE0.book Page 2 Tuesday, November 7, 2017 9:38 AM

8-9
8
Hydraulic brake service
• Regularly check and, if necessary, correct the brake fluid level.
• Every two years replace the internal components of the brake master cylinder and calipers,
and change the brake fluid.
• Replace the brake hoses every four years and if cracked or damaged. UB3D7AE0.book Page 9 Tuesday, November 7, 2017 9:38 AM
