Instrument and control functions
3-4
3
EAU4939D
In dicator li ghts an d warnin g
li g hts
EAU11032Turn si gnal in dicator li ghts “ ”
an d“”
Each indicator light will flash when its
corresponding turn signal lights are
flashing.
EAU11061Neutral in dicator li ght “ ”
This indicator light comes on when the
transmission is in the neutral position.
EAU11081Hi gh beam in dicator li ght “ ”
This indicator light comes on when the
high beam of the headlight is switched
on.
EAU11124Oil level warnin g li ght “ ”
This warning light comes on if the en-
gine oil level is low.
The electrical circuit of the warning
light can be checked by turning the key
to “ON”. The warning light should
come on for a few seconds, and then
go off.
If the warning light does not come on
initially when the key is turned to “ON”,
or if the warning light remains on, have
a Yamaha dealer check the electrical
circuit.
TIP
Even if the oil level is sufficient, the
warning light may flicker when riding
on a slope or during sudden accelera-
tion or deceleration, but this is not a
malfunction.
EAU58402Cruise control in dicator li ghts “ ”
an d “SET”
These indicator lights come on when
the cruise control system is activated.
(See page 3-7.)
TIP
When the vehicle is turned on, these
lights should come on for a few sec-
onds and then go off. If the lights do
not come on, have a Yamaha dealer
check the vehicle.
EAU73171En gine trou ble warnin g lig ht “ ”
This warning light comes on if a prob-
lem is detected in the engine or other
vehicle control system. If this occurs,
have a Yamaha dealer check the on-
board diagnostic system.
1. Immobilizer system indicator light “ ”
2. Stop mode indicator light “ ”
3. YCC-S system warning light “ ”
4. Shift down indicator light “ ”
5. Left turn signal indicator light “ ”
6. Engine trouble warning light “ ”
7. Oil level warning light “ ”
8. Neutral indicator light “ ”
9. High beam indicator light “ ”
10.Anti-lock Brake System (ABS) warning light “ ”
11.Right turn signal indicator light “ ”
12.Suspension system warning light “ ”
13.Traction control system indicator light “ ”
14.Cruise control indicator lights “ ” “SET”
GEARN25A.TEMP ˚C
LoC.TEMP˚C
0:06TIME TRIP
12345116107
131214
98
ABS
UB95E1E0.book Page 4 Tuesday, September 26, 2017 12:01 PM

Instrument and control functions
3-23
3
EAU49433
D-mo de ( drive mo de)
D-mode is an electronically controlled
engine performance system with two
mode selections (touring mode “T” and
sports mode “S”).
Push the drive mode switch “MODE”
to switch between modes. (See page
3-25 for an explanation of the drive
mode switch.)
TIP
Before using D-mode, make sure you
understand its operation along with the
operation of the drive mode switch.
Tourin g mo de “T”
The touring mode “T” is suitable for
various riding conditions.
This mode allows the rider to enjoy
smooth drivability from the low-speed
range to the high-speed range.
Sports mo de “S”
This mode offers a sportier engine re-
sponse in the low- to mid-speed range
compared to the touring mode.
EAU1234M
Han dle bar switches
Left
Ri ght
EAU73020Dimmer/Pass switch “ / /PASS”
Set this switch to “ ” for the high
beam and to “ ” for the low beam.
To flash the high beam, push the pass
side “PASS” of the switch while the
headlights are on low beam.
1. Drive mode switch “MODE”
STOP
M ODE
RUNSTART
1
1. Menu switch “MENU”
2. Select switch “ / ”
3. Stop mode switch “ ”
4. Cruise control switches
5. Horn switch “ ”
6. Turn signal switch “ / ”
7. Dimmer/Pass switch “ / /PASS”
1. Stop/Run/Start switch “ / / ”
2. Drive mode switch “MODE”
3. Hazard switch “ ”
1
7
6
5
2
4
3
STOP
M ODE
RUNSTART
3
2
1
UB95E1E0.book Page 23 Tuesday, September 26, 2017 12:01 PM

Instrument and control functions
3-39
3

Do not excee d the maximum
loa d of 208 k g (459 l b) for the ve-
hicle.
EAU39612
A djustin g the hea dlig ht beams
The headlight beam adjusting knobs
are used to raise or lower the height of
the headlight beams. It may be neces-
sary to adjust the headlight beams to
increase visibility and help prevent
blinding oncoming drivers when carry-
ing more or less load than usual. Obey
local laws and regulations when ad-
justing the headlights.
To raise the headlight beams, turn the
knobs in direction (a). To lower the
headlight beams, turn the knobs in di-
rection (b).
1. Headlight beam adjusting knob
11
(b)(a)(b)(a)
UB95E1E0.book Page 39 Tuesday, September 26, 2017 12:01 PM

10-1
10
Index
A
ABS ...................................................... 3-28
ABS warning light ................................... 3-5
Accessory box...................................... 3-38
Air filter element ................................... 6-17
Auxiliary DC jack .................................. 3-49
B
Battery .................................................. 6-31
Brake and shift pedals, checking and
lubricating .......................................... 6-28
Brake and YCC-S clutch fluid levels, checking............................................. 6-25
Brake and YCC-S clutch fluids, changing ............................................ 6-26
Brake lever ........................................... 3-27
Brake lever, checking and lubricating .......................................... 6-28
Brake lever free play, checking ............ 6-23
Brake light switches ............................. 6-23
Brake pedal .......................................... 3-28
C
Cables, checking and lubricating ......... 6-27
Canister ................................................ 6-11
Care ........................................................ 7-1
Catalytic converters ............................. 3-33
Centerstand and sidestand, checking and lubricating ................................... 6-29
Coolant ................................................. 6-16
Cornering lights .................................... 3-50
Cowling vents, opening and closing .... 3-40
Cruise control indicator lights ................ 3-4
Cruise control switches ........................ 3-24
Cruise control system ............................ 3-7
D
Diagnostic connector ............................. 9-2
Dimmer/Pass switch ............................ 3-23
D-mode (drive mode) ........................... 3-23
E
Engine break-in ...................................... 5-5
Engine idling speed, checking ............. 6-18
Engine oil and oil filter cartridge ........... 6-11
Engine serial number.............................. 9-1
Engine trouble warning light................... 3-4
F
Final gear oil ......................................... 6-14
Front and rear brake pads, checking ... 6-24
Front fork, checking ............................. 6-29
Fuel....................................................... 3-31
Fuel consumption, tips for reducing ...... 5-4
Fuel tank cap........................................ 3-31 Fuel tank overflow hose ........................ 3-33
Fuses, replacing.................................... 6-32
H
Handlebar position, adjusting ............... 3-40
Handlebar switches .............................. 3-23
Hand shift lever ..................................... 3-27
Hazard switch ....................................... 3-24
Headlight beams, adjusting .................. 3-39
High beam indicator light........................ 3-4
Horn switch........................................... 3-24
I
Identification numbers ............................ 9-1
Ignition circuit cut-off system ............... 3-47
Immobilizer system ................................. 3-1
Immobilizer system indicator light .......... 3-6
Indicator lights and warning lights .......... 3-4
M
Main switch/steering lock ....................... 3-2
Maintenance and lubrication, periodic ... 6-4
Maintenance, emission control
system .................................................. 6-3
Matte color, caution ................................ 7-1
Menu switch ......................................... 3-24
Model label ............................................. 9-1
Multi-function meter unit ...................... 3-10
N
Neutral indicator light.............................. 3-4
O
Oil level warning light .............................. 3-4
P
Panels, removing and installing .............. 6-7
Parking .................................................... 5-6
Part locations .......................................... 2-1
R
Rear view mirrors .................................. 3-42
Rider seat height, adjusting .................. 3-35
S
Safety information................................... 1-1
Seats ..................................................... 3-34
Select switch ........................................ 3-24
Shift down indicator light ........................ 3-5
Shifting .................................................... 5-3
Shift pedal............................................. 3-26
Sidestand .............................................. 3-47
Spark plugs, checking .......................... 6-10
Specifications ......................................... 8-1
Starting the engine.................................. 5-2
Steering, checking ................................ 6-30
Stop mode indicator light ....................... 3-6
Stop mode switch ................................. 3-24
UB95E1E0.book Page 1 Tuesday, September 26, 2017 12:01 PM
