2018 VOLKSWAGEN CC lock

(2) Strap indicating the location of the storage compartment handle
(3) MDI (MEDIA-IN) jack in the pull-down storage compartment
Opening and closing the glove compartment
If necessary, unlock the glove compartment with the emergency key
⇒  Vehicle key set. It is locked when the key slot is vertical.
To open, pull the handle ⇒ fig. 124.
To close, push the lid up.
Opening and closing the storage compartment for the Owner's
Manual or MDI (MEDIA-IN) jack
Depending on equipment, the storage compartment at the top of the
glove compartment is designed to hold either the Owner's Manual or
the MDI (MEDIA-IN) jack.
The Owner's Manual compartment or MDI (MEDIA-IN) jack is located
in a storage compartment at the top, which can be pulled down to
open ⇒ fig. 125 (3).
The strap (2) indicates the handle for opening the storage compart-
ment.
If the vehicle is not equipped with the MDI (MEDIA-IN) jack, always
keep the Owner's Manual in this storage compartment. To stow the
Owner's Manual, place it in the slot with the binding facing the inside
of the glove compartment door.
Holders
Depending on the model, there may be holders for a pen and a note-
pad in the glove compartment.
Cooling the glove compartment
There is an air vent (1) in the back of the glove compartment. Cool air
can be directed into the glove compartment if the air conditioner is on.
Open or close the air vent by turning it.

WARNING
Improper use of vehicle keys can result in serious personal in-
jury.
Always take the key with you when you leave the vehicle. The
engine can be started and vehicle systems such as the power
windows can be operated, leading to serious personal injury.
Never leave children, disabled persons, or anyone who can-
not help themselves in the vehicle. The doors can be locked
with the remote control vehicle key. This could result in people
being trapped in the vehicle in an emergency. For example, de-
pending on the time of year, people trapped in the vehicle can
be exposed to very high or very low temperatures.
Heat buildup in the passenger and luggage compartment of a
parked vehicle can result in temperatures in the vehicle that are
much higher than the outside temperatures, particularly in
summer. Temperatures can quickly reach levels that can cause
unconsciousness and death, particularly to small children.
Never remove the key from the ignition switch while the vehi-
cle is moving or rolling to a stop. The steering wheel will lock
and you will not be able to steer or control the vehicle.
Leaving the key in the ignition for a long time when the engine is
not running will drain the vehicle battery.
Leaving the selector lever for a long period of time in any position
other than Park (P) when the ignition is switched off can drain the
vehicle battery.
On automatic transmission vehicles, the vehicle key can be
removed from the ignition switch only when the transmission is in
Park (P). You may have to press the release button on the transmis-
sion selector lever to put the lever into Park (P).

Starter button

Fig. 134 In the center console: Starter button for the Keyless Access
locking and starting system.

The engine switches off automatically.
Engine restart feature
If no authorized remote control vehicle key is identified in the passen-
ger compartment after the engine has been switched off, the engine
can be restarted within about 5 seconds. A related message is shown
in the instrument cluster display.
After the 5 seconds have passed, the engine can no longer be started
without an authorized vehicle key in the passenger compartment.
WARNING
Unintended vehicle movement can cause serious personal inju-
ry.
Do not depress the brake or clutch pedals when switching on
the ignition, as the engine could otherwise start immediately.
WARNING
Improper use of vehicle keys can result in serious personal in-
jury.
Always take the key with you when you leave the vehicle.
Children or unauthorized persons may use it to lock the vehi-
cle, start the engine, and operate vehicle systems such as the
power windows, leading to serious personal injury.
Never leave children, disabled persons, or anyone who can-
not help themselves in the vehicle. The doors can be locked
using the remote control vehicle key. This could result in peo-
ple being trapped in the vehicle in an emergency. For example,
depending on the time of year, people trapped in the vehicle
can be exposed to very high or very low temperatures.
Heat buildup in the passenger and luggage compartment of a
parked vehicle can result in temperatures in the vehicle that are
much higher than the outside temperatures, particularly in
summer. Temperatures can quickly reach levels that can cause
unconsciousness and death, particularly to small children.
If the ignition is switched on or the engine is running and the driv-
er door is opened, a chime sounds. The chime is also a reminder to

switch off the engine and turn off the ignition before leaving and lock-
ing the vehicle from the outside.
Starting the engine

WARNING
Never leave the vehicle unattended while the engine is running.
The vehicle could move suddenly, especially when the vehicle
is in gear, resulting in accidents and personal injury.
WARNING
“Starting fluids” can explode and can cause a “run-away” vehi-
cle condition.
Never use starting assist fluids.
NOTICE
You can damage the starter or the engine if you try to start the
engine when the vehicle is still moving, or if you try to restart the
engine right after switching it off.
Avoid high engine speeds, full throttle acceleration, and heavy
engine loads when the engine is cold.
Do not try to start the engine by pushing or towing the vehicle.
Unburned fuel can get into the catalytic converter and damage it.
The steering column may also be locked.
Do not let your vehicle warm up while standing; instead, start
driving right away after making sure that you have good visibility
through all windows. This will help the engine reach operating tem-
perature faster and keep down emissions.
If the remote control vehicle key battery is weak or dead, the
starter button will not start the engine. In this case, start the engine by
inserting the vehicle key in the ignition switch ⇒ Vehicle key positions
in the ignition switch.
Major consumers of electricity are temporarily switched off when
the engine is being started.
After starting a cold engine, there may be increased operating
noises for a few seconds. This is normal and harmless.

WARNING
Never stop the engine before the vehicle has come to a com-
plete stop. You can lose control of the vehicle, crash, and be
seriously injured.
The airbags and safety belt pretensioners will not work when
the ignition is switched off.
The brake booster does not work when the engine is not run-
ning. More brake pedal pressure will be needed to stop the ve-
hicle.
The power steering system does not work when the engine is
not running, and you will need more force to steer the vehicle.
When the key is removed from the ignition switch, the steer-
ing will lock and you will not be able to steer the vehicle.
NOTICE
If the vehicle has been driven hard for a long time, the engine
could overheat when it is stopped. To reduce the risk of engine
damage, let the engine idle in Neutral for about 2 minutes before
you switch off the ignition.
If the ignition is switched on or the engine is running and the driv-
er door is opened, a chime sounds. The chime is also a reminder to
switch off the engine and turn off the ignition before leaving and lock-
ing the vehicle from the outside.
On vehicles with automatic transmissions, the vehicle key can
only be removed from the ignition when the transmission is in Park
(P).
After the engine has been switched off, the radiator fan in the
engine compartment may keep running for several minutes, or may
start running after the vehicle has been parked for a while, even if the
ignition is switched off and the vehicle key has been removed. The
radiator fan shuts off automatically when the engine has cooled down
enough.

Selector
lever
position
Designation Meaning ⇒ 
. Neutral Transmission is in Neutral position. No
power is transmitted to the wheels and no
engine braking is available.
$ Drive
(standard
driving
position)
All forward gears shift up and down auto-
matically. The transmission shifts as need-
ed depending on engine load, individual
driving style, and vehicle speed.
3 Sport Drive
(sport driving
position)
All forward gears automatically upshift later
and downshift earlier than in the D (Drive)
position, to take full advantage of the en-
gine's power reserves. The transmission
shifts as needed depending on engine
load, individual driving style, and vehicle
speed.

Automatic Shift Lock (ASL)
The Automatic Shift Lock (ASL) in Park (P) and Neutral (N) prevents
drive positions from being engaged inadvertently, which would cause
the vehicle to move.
To release the ASL, depress and hold the brake pedal with the igni-
tion switched on. Press the release button on the selector lever at the
same time.
The ASL is not engaged if the selector lever is moved quickly through
Neutral (N) (e.g., when shifting from Reverse (R) to Drive (D)). This
makes it possible to “rock” the vehicle backwards and forwards if it is
stuck in snow or mud. The ASL engages automatically if the brake
pedal is not depressed and the lever is in Neutral (N) for more than
about 1 second and the vehicle is traveling no faster than about
3 mph (5 km/h).
In rare cases, the ASL may not engage on vehicles with DSG® Direct
Shift Gearbox. If this happens, power to the drive wheels will be inter-
rupted to prevent the vehicle from moving unexpectedly. The green
