Folding the rear seat backrest forward and back into place

Fig. 100 Rear seat backrest: Release button 1; red mark 2; emergen-
cy key in lock 3.

Fig. 101 In the luggage compartment: Release lever for the left 1 and
right 2 sections of the rear seat backrest.

Pull the release button (1) forward while folding the rear seat
backrest forward.
The rear seat backrest is unlocked when the red mark on the but-
ton (2) is visible.
The rear seat backrest is released and can be folded forward.
If the rear backrest is folded down, no one, including children, may
ride on the rear seat.
Folding the rear seat backrest forward with the release lever in
the luggage compartment
Push the head restraint all the way down ⇒  Adjusting the seating
position.
Open the luggage compartment lid ⇒  Luggage compartment lid.
Pull the remote release lever for the left ⇒ fig. 101 (1) or right (2)
rear seat backrest in the direction of the arrow. The unlocked section
of the rear seat folds forward automatically.
Close the luggage compartment lid, if necessary ⇒  Luggage com-
partment lid.
The rear seat backrest is unlocked when the red mark on the but-
ton ⇒ fig. 100 (2) is visible.
If the rear backrest is folded down, no one, including children, may
ride on the rear seat.
Folding the rear seat backrest back into place
Fold the rear seat backrest back until it engages securely ⇒ .
The red mark on the release button (2) should no longer be visible.
The rear seat backrest must be securely latched into place in order
for the safety belts on the rear seats to provide optimal protection.

If the pass-through is equipped with a lock, use the emergency key
⇒  Vehicle key set to unlock the luggage compartment pass-through.
Pull the release lever ⇒ fig. 102 and fold the pass-through cover all
the way forward.
Open the luggage compartment lid.
Slide long objects from the luggage compartment through the pass-
through.
Secure objects with the safety belt.
Close the luggage compartment lid.
Closing the pass-through
Fold the pass-through cover back until it engages securely. The red
marking on the luggage compartment side ⇒ fig. 103 (1) should not
be visible.
Close the luggage compartment lid.
If the pass-through is equipped with a lock, use the emergency key
⇒  Vehicle key set to lock the luggage compartment pass-through.
If necessary, fold the center armrest up.
The pass-through can also be opened from the luggage com-
partment. Press the release lever (1) down and push the cover for-
ward.
Tie-downs

Fig. 104 In the luggage compartment: Tie-downs.

NOTICE
Never attach a trailer to the vehicle or leave it attached to the
vehicle when the trailer is supported by a trailer jack or blocks.
Various things (such as a change in trailer or vehicle load or a
flat tire) can lower or raise the vehicle. This subjects the trailer
hitch and the trailer to strong forces that can damage the vehicle
or the trailer.
If the engine is switched off and accessories in the trailer are on
and use electricity from the vehicle, the vehicle battery will be drained
as long as the electrical systems of the vehicle and the trailer are
connected.
Loading the trailer

CAUTION
The ball mount sticks out behind the rear bumper and can
cause injury to pedestrians and cyclists.
To reduce the risk of injury in rear-end collisions, and the risk
to pedestrians and cyclists when the vehicle is parked, always
remove the ball carrier when you are not towing a trailer.
NOTICE
Never use a ball larger than 11/4 inches (32 mm) on your vehi-
cle. The vehicle was not designed to tow heavier trailers with a
receiver larger than the specified ball. The increased loads can
damage the attachment points for the trailer hitch.
Never use an adapter to increase the size of the trailer hitch
receiver from 11/4 inches (32 mm) to 2 inches (50.8 mm) or more
to tow a trailer that is heavier than the maximum permissible
trailer weight that your vehicle can tow.
You can use an adapter if required for the proper installation
of a bicycle rack or other similar carrier as long as the maximum
weight limits are observed. When using bicycle racks or similar
carriers, make sure that the rear lights are not blocked.
Only use trailer hitches that are approved by the hitch manu-
facturer for your vehicle and model.

Damaged wheel rims must be replaced, and you must never take
them apart or try to repair them yourself. Have an authorized
Volkswagen dealer or an authorized Volkswagen Service Facility re-
pair them for you ⇒ .
Wheel rims with bolted decorative covers
Light-alloy wheels may have interchangeable decorative covers at-
tached to the rim with self-locking screws. If you want to replace
damaged wheel covers, contact your authorized Volkswagen dealer
or authorized Volkswagen Service Facility.
WARNING
Using improper or damaged wheel rims can affect driving safe-
ty, cause accidents and severe personal injury.
Use only wheel rims approved for the vehicle.
Regularly check wheel rims for damage and replace them if
necessary.
WARNING
Improper loosening and tightening of the bolts on wheel rims
with bolted rim rings can cause accidents and severe personal
injury.
Never loosen bolted connections on wheel rims with bolted
rim rings.
Have all work on wheel rims with bolted rim rings performed
by an authorized Volkswagen dealer or authorized Volkswagen
Service Facility.
New and replacement tires

Put the wheel you took off the vehicle into the spare wheel well so
that the center hole of the rim is aligned with the threaded pin.
Turn the handwheel clockwise until the wheel is securely in place.
If necessary, return the vehicle tool kit to its location in the luggage
compartment.
Unhook the floor covering and fold it back down onto the floor of
the luggage compartment.
Close the luggage compartment lid.
If the spare wheel is different from the road wheels
If the spare is different from the road wheels, a compact spare wheel,
for example, or if the road wheels are winter tires, the spare wheel
must be used only in the event of a flat tire, only for a brief time, and
only when driving with extra caution ⇒ .
Replace it with a tire matching the others on your vehicle as soon as
possible.
Please heed the following:
Do not drive faster than 50 mph (80 km/h)!
Avoid full-throttle acceleration, hard braking, and fast cornering!
Do not use snow chains on the compact spare wheel ⇒Snow
chains.
After installing the spare wheel or compact spare wheel, check the
tire pressure as soon as possible ⇒ Tire inflation pressure.
Check the tire inflation pressure of the spare or compact spare when-
ever you check the tire pressure of the road wheels, at least once a
month. Inflate a spare wheel to the cold tire pressure specified for
the vehicle's road wheels on the tire pressure label; inflate a compact
spare wheel to the cold tire pressure specified for the compact spare
on the tire pressure label or on a separate label for the compact
spare, if there is one.

Things that are made of transparent materials (such as eye-
glasses, magnifying glasses, or transparent suction cups on the
windows) can magnify sunlight and damage the vehicle.
The ventilation slots between the rear window and the shelf be-
hind the rear seat backrest must not be blocked so that stale air can
escape from the vehicle.
Storage compartment in the doors

Fig. 118 In the driver door: Storage compartment.
