2018 VOLKSWAGEN CC lock

The luggage compartment lid can also be locked manually with the
emergency key via the key switch in the driver door ⇒ Driver door
overview. When the luggage compartment lid has been locked manu-
ally with the emergency key, it cannot be opened using the q button
on the remote control vehicle key or the q switch inside the driver
door.
WARNING
Improper or unsupervised closing of the luggage compartment
lid can cause severe injuries. Never close the luggage com-
partment lid when someone is in the way.
Never leave your vehicle unattended or let children play
around your vehicle, especially with the luggage compartment
lid left open. A child could crawl into the vehicle and pull the
luggage compartment lid shut, becoming trapped and unable to
get out. A closed vehicle can become very hot or very cold de-
pending on the season. Temperatures can quickly reach levels
that can cause unconsciousness or death, particularly to small
children.
Make sure that the remote control vehicle key is not in the lug-
gage compartment before closing the luggage compartment lid.
Sensor-controlled luggage compartment lid opener (Easy Open)

Fig. 38 Keyless Access locking and starting system: Opening the
sensor-controlled luggage compartment lid (Easy Open), if equipped.

For one-touch closing: Pull the switch for the window up briefly as
far as it goes.
Stopping automatic movement: Pull/press the switch again.
Reactivating the one-touch feature
If the vehicle battery is disconnected or dead and the windows are not
completely closed, the one-touch feature will not work and must be
reactivated:
Switch on the ignition.
Close all windows and doors.
Pull up the switch for the respective window and hold it for at least
2 seconds in this position.
Release the switch, pull up and hold again. The one-touch feature
is now reactivated.
The one-touch feature can be reactivated for one or more windows at
the same time.
Convenience closing
The convenience closing feature lets you close the windows and the
power sunroof as follows:
On vehicles with Keyless Access, using the door handle sensors ⇒ 
Power locking and closing system.
From inside the vehicle, pull up and hold the switch for the driver
window until all windows and the sunroof are closed ⇒ Power locking
and closing system.
Convenience closing first closes the windows and then the power
sunroof. All turn signals blink once to confirm that the windows and
power sunroof are closed.

WARNING
Improper use of power windows can result in serious personal
injury.
Never let anyone get in the way of a power window when
closing it.
When locking the vehicle from the outside, make sure that no
one, especially children, remains in the vehicle. The windows
will not open in case of an emergency.
Always take the key with you when you leave the vehicle. You
can still use the power windows for several minutes after the
ignition is switched off as long as the driver or front passenger
door has not been opened.
Always use the safety switch when children are in the back
seat to disable the rear power windows and keep them from be-
ing opened and closed.
NOTICE
The windows must go down slightly when you unlock the vehi-
cle. Otherwise the windows and seals could be damaged when
opening the doors.
If the power windows malfunction, the one-touch feature, as well
as pinch protection may not work properly. See an authorized
Volkswagen dealer or authorized Volkswagen Service Facility right
away.
Power window pinch protection

resistance or there is something in the way, the power sunroof opens
again immediately.
Check why the power sunroof did not close.
Try to close the power sunroof again by pulling the h switch brief-
ly.
If the power sunroof still cannot close, the power sunroof will stop
where the resistance is located. The power sunroof will close the next
time without pinch protection.
Closing the power sunroof without pinch protection
Within 5 seconds after the pinch protection was triggered, pull the
switch ⇒ fig. 40 until the power sunroof closes completely.
The power sunroof will now close without pinch protection!
If the power sunroof still will not close, please see an authorized
Volkswagen dealer or an authorized Volkswagen Service Facility.
WARNING
Careless or unsupervised use of the sunroof can cause serious
injuries.
Always make sure that no one is in the way of the power sun-
roof when it is closing.
Always take all vehicle keys with you when leaving the vehi-
cle.
Never leave children or persons requiring assistance unat-
tended in the vehicle, especially if they have access to the ve-
hicle key. Unsupervised use of the remote control vehicle key
can lock the vehicle, start the engine, switch on the ignition and
operate the sunroof.
The sunroof can still be opened or closed for a short period
after the ignition has been switched off, as long as the driver or
passenger door is not opened.

WARNING
Always adjust seat, safety belts, and head restraints properly
before driving and make sure that all passengers are properly
restrained.
Push the passenger seat as far back as possible. Always be
sure that there are at least 10 inches (25 cm) between the front
passenger's breastbone and the instrument panel.
Always adjust the driver's seat and the steering wheel so that
there are at least 10 inches (25 cm) between your breastbone
and the steering wheel.
Adjust the driver's seat so that you can easily push the ped-
als all the way to the floor while keeping your knee(s) slightly
bent. The distance to the instrument panel in the knee area
must be at least 4 inches (10 cm).
If these requirements cannot be met for physical reasons,
contact an authorized Volkswagen dealer or an authorized
Volkswagen Service Facility to see whether adaptive equipment
is available.
Always hold the steering wheel on the outside of the steering
wheel rim with your hands at the 9 o'clock and 3 o'clock posi-
tions to help reduce the risk of personal injury if the driver's
airbag inflates.
Never hold the steering wheel at the 12 o'clock position or
with your hands at other places inside the steering wheel rim or
on the steering wheel hub. Holding the steering wheel the
wrong way can cause serious injuries to the hands, arms, and
head if the driver's airbag inflates.
Pointing the steering wheel toward your face decreases the
ability of the driver's airbag to help protect you in a collision.
Never drive with backrests reclined or tilted back farther than
necessary to drive comfortably. The farther back the backrests
are tilted, the greater the risk of injury caused by incorrect posi-
tioning of the safety belts and improper seating position.
Never drive with the front seat passenger backrest tilted for-
ward. If the front airbag deploys, the front backrest can be
forced backward and injure passengers on the rear seat.
Sit as far back as possible from the steering wheel and the
instrument panel.

Never hold the steering wheel at the 12 o'clock position or with your
hands at other places inside the steering wheel rim or on the steering
wheel hub. Holding the steering wheel the wrong way can cause seri-
ous injuries to the hands, arms, and head if the driver's airbag in-
flates.
Adjust the steering wheel so that the steering wheel cover points at
your chest and not at your face. Pointing the steering wheel toward
your face decreases the ability of the driver's airbag to help protect
you in a collision.
Adjust the driver's seat so that you can easily push the pedals all
the way to the floor while keeping your knee(s) slightly bent.
Adjust the seat height so that the top point of the steering wheel
can be reached.
Always keep both feet in the footwell so that you are in control of
the vehicle at all times.
Passenger - front seat adjustment:
Push the passenger seat as far back as possible in order to ensure
optimum protection if the airbag is deployed.
Manual controls on the driver and front passenger seats

Fig. 45 Controls on the left front seat.

fig. 45 Function Action
(1) Move the front seat
forward or back.
Pull the lever up and move the
front seat. The front seat must lock
in place after the lever is released!
(2) Lumbar support
control.
Pull the lever up or push it down.
(3) Adjust the backrest
angle.
Lean forward and turn the adjuster
wheel forward or backward.
(4) Adjust the seat height. Move the lever several times up or
down.

Electrical controls on the driver and front passenger seats

Fig. 46 Driver seat: Controls to adjust the seat backward and forward,
adjust seat cushion height and angle, and backrest angle.

Fig. 47 Lumbar support control.

Removing the rear head restraint
Unlock the backrest of the rear seat bench and fold it forward ⇒ 
Luggage compartment.
Pull the head restraint all the way up ⇒ .
If necessary, press the flat blade of the screwdriver from the vehi-
cle tool kit into the slit of the trim cap ⇒ fig. 51 (1) in the direction of
the arrow and hold it in this position.
At the same time press button (2) while a second person pulls out
the head restraint completely.
Fold the backrest of the rear seat bench back so that it locks se-
curely.
Reinstalling the rear head restraint
Unlock the backrest of the rear seat bench and fold it forward ⇒ 
Luggage compartment.
Position head restraint properly over the head restraint guides of
the respective seat backrest and insert the head restraint into the
guides.
Push the head restraint down while pressing button (2).
Fold the backrest of the rear seat bench back so that it locks se-
curely.
Adjust the head restraint according to the occupant's size ⇒  Ad-
justing the front and rear head restraints.
WARNING
Driving without head restraints or with improperly adjusted
head restraints increases the risk of serious injuries in a colli-
sion.
Always drive with the head restraints in place and properly
adjusted to help minimize the risk of neck injury in a crash.
Always reinstall head restraints as soon as possible so that
vehicle occupants are properly protected.
NOTICE
When removing or reinstalling the head restraint, take care that
the head restraint does not strike the headliner or other parts of
