2018 VOLKSWAGEN CC lock

WARNING
Improper use of the steering column adjustment feature can
result in serious personal injury and even death.
Always pull the lever (1) firmly upward after adjusting the
steering column so that the steering wheel does not change
position suddenly while the vehicle is moving.
Never adjust the steering column while the vehicle is moving.
If you find that you need to adjust the steering wheel while driv-
ing, stop the vehicle in a safe place and make the proper ad-
justment.
Never adjust the steering wheel so that it points toward your
face. Always make sure that the steering wheel points toward
your chest. Otherwise, the airbag system cannot protect you
properly in the event of a crash.
Always hold the steering wheel on the outside of the steering
wheel rim with your hands at the 9 o'clock and 3 o'clock posi-
tions to help reduce the risk of serious personal injury if the
driver's airbag inflates.
Never hold the steering wheel at the 12 o'clock position or
with your hands anywhere inside the steering wheel or on the
steering wheel hub. Holding the steering wheel the wrong way
increases the risk of severe injury to the arms, hands, and head
if the driver airbag deploys.
Center armrest

Fig. 53 Front center armrest.

Memory buttons
Personal settings for the front seats and outside mirrors can be as-
signed to each memory button.
These settings can be assigned to individual remote control vehicle
keys. The settings are applied after unlocking the vehicle and opening
the driver door.
Storing driver seat settings and forward driving settings for
outside mirrors
Switch on the ignition.
Manual transmission: Shift the transmission to Neutral (N) and set
the electronic parking brake.
Automatic transmission: Shift the transmission to Park (P).
Adjust the driver seat and outside mirrors.
Press the 3%4 button for at least 1 second ⇒ fig. 57.
Press the desired memory button 1 , 2 , or 3 within 10 seconds. A
chime sounds to confirm that the setting has been stored.
Storing front passenger seat settings to the front passenger seat
memory buttons
Switch on the ignition.
Adjust the passenger seat.
Press the 3%4 button for at least 1 second ⇒ fig. 57.
Press the desired memory button 1 , 2 , or 3 within 10 seconds. A
chime sounds to confirm that the setting has been stored.
Storing passenger-side outside mirror settings for backing up
Set the electronic parking brake.
Switch on the ignition.
Shift the transmission to Neutral (N).
Briefly press the desired memory button 1 , 2 , or 3 on the outside
of the driver seat.
Shift the transmission into Reverse (R).
Adjust the passenger outside mirror to provide good visibility of the
curb, for example.
The adjusted mirror position is automatically stored and assigned
to the vehicle key used to unlock the vehicle. The preselected posi-

tion will be recalled when the key assigned to that mirror adjustment
position is used again.
The passenger-side outside mirror automatically adjusts back from
the position stored for backing up when the vehicle moves forward at
about 10 mph (15 km/h) or more or when the rotary knob is rotated
from R into a different position.
Recalling stored seat memory settings
Briefly press the appropriate memory button when the vehicle is not
moving, the ignition is switched off, and the vehicle door is open.
OR: If the ignition is switched on and the door is closed, press and
hold the appropriate memory button until the stored position is
reached.
Assigning driver seat and outside mirror settings to a vehicle
key
The memory function of all vehicle keys is disabled when the vehicle
is first delivered from the factory.
To enable vehicle key memory function:
Unlock the driver door.
Press and hold a memory button ⇒ fig. 57 until memory position is
reached.
Press and hold the unlock button 0 on the vehicle key and then
press the desired memory button at the same time within about
3 seconds. A chime sounds to confirm activation.
To disable vehicle key memory function:
Press and hold the 3%4 button.
Press and hold the unlock button 0 on the vehicle key and the de-
sired memory button at the same time within about 10 seconds. A
chime sounds to confirm deactivation.
Assigning settings to an additional vehicle key
Follow the instructions ⇒  Assigning driver seat and outside mirror
settings to a vehicle key to assign the driver seat and outside mirror
settings to the vehicle key.
Unlock the vehicle with the same vehicle key.
Adjust driver seat and outside mirrors.

Lock the vehicle with locking button 1 in the vehicle key to store
the settings.
Once the settings are stored, the driver seat and the outside mirrors
move to the stored positions whenever the vehicle is unlocked with
the 0 button on the vehicle key (or unlocked with the door handle
sensor on vehicles with Keyless Access) and the driver door is
opened. If 2 people use the vehicle, each of them should always use
the key in which his or her personal settings have been stored.
Initializing the memory seats
The memory system must be initialized by an authorized Volkswagen
dealer, an authorized Volkswagen Service Facility, or another quali-
fied workshop in certain situations, for instance, if a new driver seat is
installed.
Initializing clears all memories and assignments of the memory seats.
After that, memory buttons can be reprogrammed and assigned to a
vehicle key.
Open the driver door but do not enter the vehicle.
Adjust the seats from the outside.
Move the angle of the backrest forward as far as it will go.
Release the backrest adjustment switch and press it again until you
hear a chime sound.
Cancellation conditions when storing settings for the memory
buttons
When one of the following conditions is met, the storing process will
be cancelled:
The vehicle battery is weak or dead.
The 3%4 button is pressed again within about 10 seconds.
The seat position is readjusted within about 10 seconds after
pressing the 3%4 button.

d Check the condition of all safety belts regularly.
d Keep safety belts clean.
d Keep objects and liquids away from safety belt webbing, the safety
belt buckle tongue, and the safety belt buckle latch and opening.
d Do not pinch or damage the safety belt or buckle tongue (for in-
stance, when closing a door).
d Never modify, disassemble or try to repair safety belts and safety
belt anchorages.
d Always fasten your safety belt properly before driving and keep it
fastened whenever the vehicle is moving.
Twisted safety belt
If it is difficult to pull the safety belt out of the belt guide, the belt may
be twisted inside the side trim because the belt retracted too quickly
when it was taken off.
Hold the safety belt tongue, slowly and carefully pull safety belt all
the way out.
Untwist the safety belt and slowly return the belt by hand.
If you cannot untwist the safety belt, wear it anyway. Make sure that
the safety belt is twisted in a spot where it does not come in direct
contact with your body. Have the safety belt untwisted immediately by
an authorized Volkswagen dealer or authorized Volkswagen Service
Facility.
Lockable safety belt
The retractors for the rear seat safety belts and the front passenger
safety belt have a switchable locking feature for child restraints in
addition to the emergency locking feature. Whenever a child restraint
is installed with a safety belt, the safety belt must be locked so that
the safety belt webbing cannot unreel. The switchable locking feature
lets you lock the belt so that a child restraint can be properly installed
and, for example, so that it can't tip to the side when the vehicle goes
around a corner ⇒  Child safety and child restraints.
To see whether a safety belt is lockable, pull the safety belt all the
way out of the safety belt retractor. You should then hear a “clicking”
sound as the belt winds back into the retractor reel. Test the switcha-
ble locking feature by pulling on the belt. When the switchable locking

feature is active, you should no longer be able to pull the belt out of
the retractor.
The locking feature must be deactivated when a vehicle occupant
uses the safety belt.
WARNING
Improper use and care of safety belts increases the risk of se-
vere personal injury or death.
Regularly check safety belts and related parts for damage.
Damaged safety belts must be replaced; they cannot be re-
paired.
Always keep safety belts clean.
Never catch, damage or chafe safety belt webbing on sharp
edges.
Always keep objects and liquids away from the belt buckle
and buckle opening.
Fastening and unfastening safety belts

Fig. 65 Inserting the buckle tongue into the belt buckle.

Key to fig. 70:
(1) Vehicle safety belt buckle.
(2) Buckle tongue on the safety belt extender.
(3) Safety belt buckle on the safety belt extender.
(4) Safety belt buckle tongue on the factory-installed safety belt.
Key to fig. 71:
(A) Safety belt buckle on the safety belt extender.
(B) Distance between the safety belt buckle on the safety belt ex-
tender and the centerline of the person using the safety belt ex-
tender. The distance must be more than 6 inches (15 cm)!
(C) Centerline of the person using the safety belt extender.
Using a safety belt extender
Adjust both the seat and the head restraint properly ⇒ Adjusting the
seating position.
Insert the buckle tongue on the safety belt extender ⇒ fig. 70 (2)
into the vehicle belt buckle for the seat where the safety belt extender
is being used (1).
Fastening or unfastening the vehicle safety belt ⇒ Fastening and
unfastening safety belts.
Pull the belt to make sure that the tongues are securely locked in
the buckles.
Make sure that the safety belt is positioned properly ⇒ Safety belt
position.
Properly using safety belt extenders:
Use a safety belt extender only when the factory installed safety
belt is too short when worn properly by a person in proper seating
position.
Only use 1 safety belt extender per seat and vehicle safety belt.
Always remove the safety belt extender when it is not needed.
Never leave a safety belt extender attached to the vehicle safety
belt buckle when the extender is not needed and being used with the
safety belt. Otherwise, the airbag control module will receive an incor-
rect signal from the safety belt buckle and this will prevent the airbag
from working properly for a person who is not using the safety belt.
Leaving the extender attached to the safety belt buckle when the front
seat is occupied and the safety belt is not being used will signal the
airbag control unit during a collision that the front passenger seat is

“Coming home” Action
Switch on: – Switch off the ignition.
– Operate the headlight flasher for about
1 second
The “Coming home” lighting is switched on when
the driver door is open.
The delay period starts once the last vehicle door
or the luggage compartment lid is closed.
Switch off: – Automatically after delay period is over.
– Automatically, if a vehicle door or the luggage
compartment lid is still open about 30 seconds
after activation.
– Turn light switch to the / position.
– Switch the ignition on.


“Leaving
home”
Action
Switch on: – Unlock the vehicle if the light switch is in the !54/
position and the low-light sensor registers darkness.
Switch off: – Automatically after preset delay period is over.
– Lock the vehicle.
– Turn the light switch to the / position.
– Switch the ignition on.

Background lighting in the outside mirrors
The background lighting in the outside mirrors illuminates the area
near the doors when entering and exiting the vehicle. It is switched on
when the vehicle is unlocked, a vehicle door is opened, or the “Com-
ing home” or “Leaving home” feature is activated. If the vehicle is
equipped with a light sensor, the background lighting in the outside
mirrors is only switched on in darkness.
