2018 VOLKSWAGEN CC engine

WARNING
Hot steam and hot engine coolant can cause serious burns.
Never open the hood if you see steam or coolant escaping
from the engine compartment. Always wait until you no longer
see or hear steam or coolant escaping from the engine.
Always let the engine cool down completely before carefully
opening the hood. Hot components will burn skin on contact.
When the engine has cooled down and you are ready to open
the hood:
– Apply the electronic parking brake and shift the transmis-
sion into Park (P) (automatic) or Neutral (manual only).
– Take the vehicle key out of the ignition.
– On vehicles with Keyless Access, make sure that the re-
mote control vehicle key is out of range of the vehicle and
that the vehicle cannot be started by depressing the starter
button
– Always keep children and others away from the engine
compartment and never leave them unsupervised.
The engine coolant system is under pressure when the en-
gine is hot. Never unscrew the coolant expansion tank cap
when the engine is hot. Hot coolant can spray out and cause
severe burns and other serious injuries.
– Turn the cap slowly and very carefully in a counterclock-
wise direction while applying light downward pressure on the
top of the cap.
– Always protect your face, hands, and arms from hot escap-
ing coolant or steam by covering the cap with a large, thick
rag.
Never spill fluids on the engine or exhaust system when re-
filling. Spilling fluids onto hot parts of the engine or exhaust
system can cause a fire. Under some conditions, the ethylene
glycol in engine coolant can catch fire.
NOTICE
Use distilled water only when adding coolant! All other types
of water contain chemical compounds that can cause extensive
corrosion damage to the engine. This can even lead to engine

failure. If you have added non-distilled water, take the vehicle
immediately to an authorized Volkswagen dealer or an author-
ized Volkswagen Service Facility to have the coolant system
drained, flushed, and refilled completely with the proper coolant.
Refill engine coolant only up to the top edge of the marked fill
range ⇒ fig. 168. Excess engine coolant may be forced out of the
engine cooling system when it gets hot and cause damage.
In the case of significant engine coolant loss, refill engine
coolant only when the engine is completely cooled down. Signif-
icant engine coolant loss is a sign of leaks in the cooling sys-
tem. Have the engine cooling system checked immediately by an
authorized Volkswagen dealer or an authorized Volkswagen Ser-
vice Facility. Otherwise the engine may be damaged!
When changing or topping off operating fluids, make sure that
you pour the fluids into the correct reservoirs. Serious malfunc-
tions and engine damage can result if you pour operating fluids
into the wrong reservoir.

Never use or attempt to charge a damaged or frozen battery,
or a battery that was frozen but has thawed. Charging a frozen
or thawed battery could cause explosions and chemical burns!
Replace damaged or frozen vehicle batteries immediately. A
dead battery can freeze at temperatures around +32 °F (0 °C).
If the battery has a vent line or tube, make sure that it is
properly connected to the battery.
Always make sure that the vent line is securely attached to a
vehicle battery that is located in the luggage compartment.
WARNING
California Proposition 65 Warning
Battery posts, terminals, and related accessories contain
lead and lead components, chemicals known to the State of
California to cause cancer and reproductive harm. Wash your
hands after handling.
NOTICE
Do not expose the vehicle battery to direct sunlight for an ex-
tended period of time as ultraviolet rays may damage the battery
housing.
If the vehicle is left standing in the cold for a long time, protect
the vehicle battery from freezing. A battery will be permanently
damaged by freezing.
Undeployed battery isolator modules are classified as Perchlo-
rate Material. Special handling may apply – see
http://www.dtsc.ca.gov/hazardouswaste/perchlorate. Obey all appli-
cable legal requirements regarding handling and disposal of the vehi-
cle or parts of its restraint system, including airbag modules and safe-
ty belts with pretensioners. Authorized Volkswagen dealers and au-
thorized Volkswagen Service Facilities are familiar with the require-
ments, and we recommend that you have them perform this service
for you.
Emergency starting and starting the engine with a very weak ve-
hicle battery or after the vehicle battery has been replaced may

Checking the vehicle battery electrolyte level

Fig. 170 In the engine compartment: On vehicles with a 2.0 liter en-
gine, the vehicle battery is in the engine compartment.

Fig. 171 In the luggage compartment: On vehicles with a 3.6 liter en-
gine, the vehicle battery is on the left side of the luggage compart-
ment.

Vehicles with 3.6 liter engines: Open the luggage compartment lid
⇒  Luggage compartment lid.
Opening the battery cover
Depending on the engine type, there are different kinds of battery
covers:
Vehicles with 2.0 liter engines: Press on the clip in direction of the
arrow ⇒ fig. 170 (1) and remove the cover upward.
Vehicles with 3.6 liter engines: Remove the trim panel to access
the vehicle battery ⇒ fig. 171.
Checking the vehicle battery acid level
If the lighting conditions are poor, use a flashlight so that you can
clearly see the battery acid level indicator and tell what color it is.
Never use an open flame or an unprotected light source.
The round battery window (“acid level indicator”) on the top of the
battery changes color, depending on the battery's electrolyte level.

Color Action
Light yellow
or colorless
Battery electrolyte level is too low.
The vehicle battery may need to be
replaced. Have it checked by an
authorized Volkswagen dealer or an
authorized Volkswagen Service Fa-
cility.
Black Battery electrolyte level is satisfacto-
ry.

Automatic electrical load deactivation
If the vehicle battery drain is high, the intelligent onboard electrical
system management automatically takes steps to help prevent bat-
tery drain.
The idle speed is increased so that the alternator provides more
power.
The power to devices that consume a lot of electricity is cut back or
switched off completely.
When the engine is started, the power supply to the 12 Volt sockets
is temporarily interrupted.
The onboard electrical system management cannot always keep the
battery from being drained. For example, the battery will drain if the
engine is not running, but the ignition is switched on or the parking
lights are left on for a long time when parked.
Battery disconnection in an accident with airbag deployment
In vehicles with a battery in the luggage compartment, the electrical
connection to the battery is disconnected automatically in a collision
with airbag deployment. This helps to prevent a short-circuit.
What drains the vehicle battery?
Long periods when the engine is not running, especially when the
ignition is on.
Using electrical systems or devices when the engine is switched
off.
Leaving the vehicle unlocked for several days when not in use.
The selector lever is left for a long period of time in any position
other than P when the ignition is switched off ⇒  Automatic transmis-
sion: Selector lever.
WARNING
Failure to use the proper battery with proper mounting and
connections may cause short circuits, fires, and serious per-
sonal injuries.
Always use only maintenance-free or cycle-free, leak-proof
batteries with the same specifications and dimensions as the
original equipment battery. Specifications are listed on the bat-
tery housing.

WARNING
Vehicle care products can be dangerous. Improper use can
cause accidents, burns, poisoning, or other serious personal
injuries.
Always store vehicle care products only in original contain-
ers that are securely closed.
Always read and heed all the instructions and all WARNINGS
on the package.
To reduce the risk of poisoning, never use empty food or
beverage containers that might mislead someone into drinking
from them.
Always keep vehicle care products out of the reach of chil-
dren.
Always use such products outdoors or in well-ventilated are-
as, because harmful vapors may be released when these prod-
ucts are used.
Never use fuel, turpentine, engine oil, nail polish remover or
other volatile fluids for vehicle care. They are poisonous and
highly flammable.
WARNING
Improper care and cleaning of vehicle components can impact
the safety features of the vehicle and cause severe injuries.
Always clean and maintain vehicle components according to
manufacturer's instructions.
Only use approved or recommended cleaners.
NOTICE
Vehicle care products containing solvents can damage plastics
and other vehicle the materials.
Wash the vehicle only at specifically designated wash locations
to help prevent water contaminated with oil, grease and fuel from en-
tering the storm drain sewer system. In some areas it is against the
law to wash motor vehicles anywhere than other than at specified
designated car washing locations.

NOTICE
To help prevent vehicle damage in a car wash:
Compare the vehicle track width with the dimensions of the
guide rails in the car wash to help prevent damage to wheel rims
and tires!
Switch off the rain sensor before driving the vehicle through a
car wash ⇒  Rain sensor.
Make sure there is enough clearance for the height and width
of the vehicle.
To help prevent paint damage to the engine hood, place wiper
blades against the windshield after they have dried. Do not let
them snap back into place.
Fold the outside mirrors toward the vehicle body. Do not fold
power folding mirrors manually!
Lock the luggage compartment lid to help prevent uninten-
tional opening in the car wash.
Washing with a power washer
