The vehicle may only be lifted by a jack positioned at one of the four
jack lift points ⇒ .
Checklist
For your own safety and that of your passengers, carry out the follow-
ing steps in the order listed ⇒ .
1. Find a level spot on firm ground for lifting the vehicle.
2. Switch off the engine. Automatic transmission: shift the transmis-
sion into Park (P)) ⇒  Automatic transmission: Selector lever. Man-
ual transmission: shift into a gear ⇒  Manual transmission: Gear-
shift lever. Then set the electronic parking brake ⇒  Braking and
parking to help prevent the vehicle from moving.
3. If towing a trailer: Unhitch the trailer from the vehicle and park the
trailer properly.
4. Straighten the steering wheel so that the front wheels point straight
forward.
5. Block the diagonally opposite wheel with chocks or other suitable
things.
6. Loosen the wheel bolts of the wheel to be changed ⇒ Wheel bolts.
7. Find the jack lift point on the vehicle frame that is closest to the
wheel to be changed.
8. Remove the cover panel in the side sill. To do so, pull forcefully but
carefully in the direction of the arrow ⇒ fig. 193. Secure the cover
panel with the retaining strap.
9. Crank up the vehicle jack so that it still just fits underneath the lift
point.
10. Position the jack so that its base is directly underneath the lift
point ⇒ fig. 194, making sure that the entire base of the jack rests
securely on the ground.
11. Align the jack and wind up the jack claw at the same time, until
the claw cradles the vertical rib underneath the vehicle ⇒ fig. 194.
12. Continue raising the vehicle jack until the wheel is lifted off the
ground.

WARNING
Improper use of your vehicle jack can cause the vehicle to fall
off the jack leading to serious personal injury. To help reduce
the risk of serious personal injury:
Use only jacks approved by Volkswagen for the vehicle. Oth-
er jacks might slip, even those approved for other Volkswagen
models, but not for your vehicle.
Always set up the jack on firm and level ground. The vehicle
may slip off the jack if the jack is resting on soft or sloping
ground. If necessary, place a sturdy board under the jack.
On a hard, slippery surface (such as a tiled floor), use an anti-
skid rubber mat or something similar to help prevent the jack
from slipping.
Position the jack only at the described vehicle lift points. Be-
fore you raise your vehicle, always make sure the jack claw
properly grips the vertical rib under the sill so that the jack
does not slip off when you are raising the vehicle ⇒ fig. 194.
Never have any part of your body (such as your arm or leg)
under the vehicle when it is supported by the jack. Never let
other persons have any part of their body under the vehicle,
either!
If you must work under a vehicle raised on a floor jack, al-
ways make sure that the vehicle is safely supported on safety
stands intended for that purpose that are strong enough to
support the weight of the vehicle.
Never lift the vehicle when it is tilted or inclined to one side
or the engine is running.
Never lift the vehicle when more than 1 tire is flat or dam-
aged.
Do not start the engine while the vehicle is supported by a
jack. Engine vibrations may cause the vehicle to slip off the
jack.

Fig. 197 In the engine compartment: Fuse box cover.

Opening the fuse box in the instrument panel
Insert a flat object, such as a screwdriver from the vehicle tool kit,
into the opening ⇒ fig. 196 (arrow) and carefully lift off the cover.
On the inside of the cover there are plastic tweezers for removing
and inserting fuses.
To install, guide the cover from the bottom into the instrument
panel and push until you can hear it latch into place.
Opening the fuse box in the engine compartment
Open the engine hood

WARNING
Improper replacement of burned out headlights and other light
bulbs can cause serious personal injury.
Stop! Always read and heed the WARNINGS before doing any
work in the engine compartment ⇒  Working in the engine com-
partment. The engine compartment of any motor vehicle is a
potentially dangerous area, and work in this area can lead to
serious personal injury.
HID – High Intensity Discharge (Xenon) headlights get power
from a high voltage source that can cause severe personal inju-
ry and even death if handled improperly.
H7 bulbs and HID – High Intensity Discharge (Xenon) head-
lights are under high pressure and can explode if handled im-
properly.
Always let a burned out light bulb cool down before replacing
it.
Never replace a light bulb unless you are familiar with all of
the necessary procedures. In particular, never remove a head-
light unless you know exactly how to carry out the job and have
the correct tools and light bulbs.
If you are uncertain about what to do, have the work per-
formed by an authorized Volkswagen dealer, an authorized
Volkswagen Service Facility, or another qualified workshop.
Serious personal injury may result from improperly performed
work.
We strongly recommend that you always have HID – High In-
tensity Discharge (Xenon) headlights and H7 bulbs replaced by
a qualified technician.
Do not touch the glass of light bulbs with your bare hands.
Fingerprints left on the bulb evaporate due to the heat when the
bulb is switched on and cause the reflector to “cloud.”
There are sharp edges on and around the headlight housing
in the engine compartment and the rear light housing. Wear
hand protection if you replace bulbs.

WARNING
Disregarding the safety-related checklist may lead to accidents
and serious personal injuries.
Always review and follow the checklist. Follow accepted safe-
ty practices and use common sense.
NOTICE
Always insert and remove lamps carefully to help prevent dam-
age to the vehicle paint or to other parts of the vehicle.
Replacing headlight bulbs

Fig. 200 In the engine compartment: Cover for cornering light, day-
time running light, parking light and turn signal 1, HID headlights 2.

WARNING
Improper use of jumper cables when jump-starting a vehicle
with a dead battery can cause the battery to explode, leading to
serious personal injury. To help reduce the risk of battery ex-
plosion:
All work on the batteries or the electrical system in your ve-
hicle can cause serious acid burns, fires, or electrical shocks.
Always read and heed the following WARNINGS and safety pre-
cautions before working on the batteries or the electrical sys-
tem ⇒  Vehicle battery.
Always make sure that the battery providing starting assis-
tance (the booster battery) has the same voltage as the dead
battery (12 V) and about the same amperage capacity (see bat-
tery label).
Never jump-start a vehicle with a thawed or frozen vehicle
battery. The battery can explode. A dead battery can freeze at
temperatures around +32 °F (0 °C).
A battery that is frozen or was frozen, but has since thawed,
must be replaced.
When the vehicle battery is jump-started, it gives off hydro-
gen gas, which is highly explosive! Always keep fire, sparks,
open flame, and smoking materials far away from vehicle bat-
teries. Never use a mobile telephone while connecting or dis-
connecting jumper cables.
Jump-start batteries only in well-ventilated areas. Batteries
give off highly explosive hydrogen gas during jump-starting.
Always route the jumper cables so that they cannot get
caught in any moving parts in the engine compartment.
Never short out the battery terminals by connecting the posi-
tive (+) and negative (-) terminals with each other.
Never connect the negative cable from the other vehicle di-
rectly to the negative terminal of the dead battery, as this may
cause the hydrogen gas given off by the dead battery to ex-
plode.
Never attach the negative cable from the vehicle providing
starting assistance to any part of the fuel system or to the
brake hoses or brake lines.

Never allow the non-insulated parts of the battery clamps to
touch.
Never allow the jumper cable attached to the positive battery
terminal to contact metal parts of the vehicle.
Always follow the instructions of the jumper cable manufac-
turer.
NOTICE
To help prevent extensive damage to the vehicle electrical sys-
tem, read and heed the following:
Connecting jumper cables improperly can cause a short cir-
cuit and do expensive damage to the vehicle's electrical system.
Do not let the vehicles touch each other while the jumper ca-
bles are connected. If they do, electrical current may flow be-
tween the vehicles when the positive (+) terminals are connect-
ed, causing electrical system damage.
Positive jump start terminal, 3.6 liter engine

Fig. 210 In the engine compartment: Positive jump start terminal +.
