WARNING
Improper trailer towing can cause loss of vehicle control and
serious personal injury.
Driving with a trailer and carrying heavy or bulky items
changes the way the vehicle handles and increases the dis-
tance it needs to stop safely.
Always watch what is happening up ahead and around you.
Brake earlier than you would if you were not towing a trailer.
Always adapt your speed and driving to the heavier load and
the weight distribution in the vehicle. Take road, weather, traf-
fic, and visibility conditions into account as well.
Reduce your speed even more than you otherwise would
when going downhill and under unfavorable load, weather, or
wind conditions.
Drive especially carefully and accelerate gently. Always avoid
sudden maneuvers and hard braking.
Be especially careful when passing other vehicles.
Reduce speed immediately if the trailer shows even the
slightest sign of swaying.
Never try to stop the swaying by accelerating.
Always obey speed limits. In some areas speed limits for ve-
hicles towing trailers are lower than for vehicles without trail-
ers.
Ball mount

Fig. 108 Dimensions of the ball mount support.

Retrofitting a trailer hitch

Fig. 109 Dimensions and attachment points for retrofitting a trailer
hitch.

from the center of the hitch ball to the surface of the road ⇒ fig. 109
(D) be less than the specified minimum. This minimum height must be
present even when the vehicle is fully loaded and subject to the max-
imum tongue weight.
Distance dimensions ⇒ fig. 109:
(A) Attachment points.
(B) 46 inches (1170 mm)
(C) at least 3 inches (79 mm)
(D) 14–16 inches (350 – 420 mm)
(E) 10 inches (251 mm)
(F) 21 inches (546 mm)
(G) 41 inches (1031 mm)
(H) 41 inches (1036 mm)
WARNING
Improper or incorrect connections to the vehicle electrical sys-
tem can cause malfunctions that affect the entire vehicle elec-
trical system and cause accidents and serious personal injury.
Never connect the electrical system of the trailer directly to
the electrical connections of the rear lights or other unsuitable
power sources. Use only a suitable connector to provide power
to the trailer.
Have any trailer hitch retrofit or other work on a trailer hitch
done by a qualified workshop.
WARNING
An improperly installed or unsuitable trailer hitch can cause the
trailer to separate from the towing vehicle and result in a major
accident with serious personal injuries.
Maximum permissible trailer weight

Install only radial tires only of the same make, the same dimen-
sions (tread circumference), and similar tread profile on all 4 wheels.
The tread depth of new tires can differ between tire models and
manufacturers because of different design features and tread design.
Replacing tires
Tires should be replaced in pairs and not individually (both front
tires or both rear tires at the same time) ⇒ .
Replace tires only with tires that have the same specifications, in-
cluding width and diameter, load and top speed rating as the tires
approved by Volkswagen for your vehicle and model.
Never use tires that are larger or wider than the dimensions of the
tires approved by Volkswagen for your vehicle and model. Larger
tires could scrape and rub on the vehicle body or other parts of the
vehicle.
Tire Pressure Monitoring System (TPMS) considerations
Factory-installed wheels are equipped with a sensor that constantly
monitors tire pressure, then transmits this information to the TPMS ⇒ 
Tire Pressure Monitoring System (TPMS). If you are going to replace
the wheels, make sure that the new wheels also have sensors that
are compatible with the TPMS on your vehicle. New wheels with sen-
sors have to be recognized and integrated into the system. The new
wheels and sensors are recognized and integrated when driving off
the first time.
If you install wheels that do not have sensors, or have sensors that
are not compatible, the TPMS will not work properly. In this case, the
TPMS will not be able to monitor tire pressure or warn you if pressure
is low. An error message may appear in the instrument cluster display
or the TPMS will switch itself off.
Whenever you change sensors, you have to install new valves and
seals. Please see an authorized Volkswagen dealer of an authorized
Volkswagen Service Facility.
Always drive with the valve caps securely installed. We recom-
mend using factory-supplied valve caps. Ask an authorized
Volkswagen dealer or an authorized Volkswagen Service Facility to
replace lost caps.
If you install new tires that differ the original Volkswagen specifica-
tions, for your vehicle and model, the benchmark tire inflation pres-

Engine Tire dimensions Tire pressure
bar psi kPa
3.6 L / 280 hp (206 kW)
4MOTION
235/45 R 17 2.3 34 230
235/40 R 18 xl 2.6 38 260
xl = reinforced sidewall.
The Tire Pressure Monitoring System is configured at the factory
with the correct tire inflation pressure applicable for the vehicle
model, engine and factory-installed tires. The tire inflation pressure
is listed on the tire inflation pressure label on the driver door jamb⇒ ,
Tire inflation pressure. The tire inflation pressures for the road tires
are listed on this label. The inflation pressure for the compact spare
is as specified on the tire pressure label or on a separate label for
the compact spare, if there is one. In the event of a discrepancy be-
tween the above figures and the tire pressures listed on the tire infla-
tion pressure label, the pressures listed on the label are the ones
you should use. The listed pressure applies to all road tires. If differ-
ent tires are installed that do not have the same cold tire inflation
pressure as the tires originally installed on your vehicle, the Tire
Pressure Monitoring System cannot properly monitor tire inflation
pressures unless the TPMS is reset to the new tire pressures
⇒ page 295. Authorized Volkswagen dealers and authorized
Volkswagen Service Facilities have the necessary special tools and
can reset the TPMS for the new tires on your vehicle.

Tire labeling
(example)
Meaning
Brand, Logo Manufacturer
Tire name Individual tire designation of the manufac-
turer.
P255 / 55 R 18
Dimensions:
P Tire application: Passenger car
255 Nominal sidewall-to-sidewall width of
tire in millimeters.
55 Ratio of height to width (aspect ratio)
R Tire belt design letter code for radial.
18 Rim diameter (in inches)
109 H Load rating code and speed rating code
XL Indicates “reinforced” tire (heavy-duty)
M+S or M/S Indicates Mud and Snow capability (also
M/S) ⇒  Winter tires.
RADIAL TUBELESS Tubeless radial tire.
E4 ... Labeling according to international regula-
tions (E) including number of the approving
country. The multi-digit approval number is
listed next.
DOT BT RA TY5 1709
Tire identification number (TIN)3 – In some
cases the manufacturing date is only on one
side of the tire:
3 TIN represents the serial number of the tire.

Tire labeling
(example)
Meaning
DOT
The tire complies with the require-
ments of the United States Depart-
ment of Transportation, responsible
for issuing safety standards.
BT Identification letter of the manufactur-
ing site.
RA Manufacturer information regarding
tire dimensions.
TY5 Tire characteristics provided by the
manufacturer.
1709 Manufacturing date: 17th week in
2009.
TWI Marks the position of the treadwear indicator
Made in Germany Country of manufacture.
MAX LOAD 615 KG
(1356 LBS)
United States maximum load rating per
wheel.
MAX INFLATION
350 KPA (51 PSI)
United States maximum permissible inflation
pressure.
ROTATION Rotation direction (unidirectional tires)
SIDEWALL 1 PLY
RAYON
Tire ply composition and materials used:
1 layer of rayon.
TREAD 4 PLIES
1 RAYON + 2 STEEL
+ 1 NYLON
Tire tread composition and materials used:
In this example there are 4 layers under the
tread: 1 layer of rayon, 2 layers of steel belt
and 1 layer of nylon.

ter tire performance decreases with age – independent of the tread
profile depth.
When using winter tires:
Obey state and country-specific legal requirements.
Install winter tires on all 4 wheels.
Use winter tires only under wintry road conditions.
Only use winter tires with dimensions approved for the vehicle.
Use only winter tires of the same tire belt design, the same dimen-
sions (tread circumference), and the same tread design.
Follow speed restrictions according to the winter tire's speed rating
code letter ⇒ .
Speed restrictions
Winter tires are certified up to a top speed identified by speed rating
code letters on the side wall ⇒  Tire labeling.
In some vehicle models it is possible to set a speed warning in the
menu in the instrument cluster display ⇒  Volkswagen Information
System.
Top speed rating and tire inflation pressure for V winter tires depend
on the engine installed in your vehicle. Be sure to ask you authorized
Volkswagen dealer or authorized Volkswagen Service Facility about
the maximum permissible speed and the required tire inflation pres-
sure for the winter tires that you plan to use.
WARNING
Driving faster than the maximum speed for which the winter
tires on your vehicle were designed can cause sudden tire fail-
ure including a blowout and sudden deflation, loss of control,
crashes and serious personal injuries.
Winter tires have a maximum speed rating that may be lower
than your vehicle's maximum speed.
Never drive faster than the maximum speed for which the
winter tires installed on your vehicle are rated because tires
that are driven faster than their rated speed can fail suddenly.
Never exceed the maximum load rating for the winter tires
installed on your vehicle.
