2018 TOYOTA COROLLA iM Accessories, Audio & Navigation (in English)

3

Bluetooth® HANDS-FREE SYSTEM

1
BASIC INFORMATION
BEFORE OPERATION

1. QUICK REFERENCE ...... .... ........ 58
2. HANDS -FREE SYSTEM... ........... 60
USING THE PHONE SWITCH OR
MICROPHONE..................................... 61
ABOUT THE PHONE BOOK IN THIS
SYS TEM............................................... 62
WHEN YOU SELL YOUR CAR............ 62
CONNECT A Bluetooth® PHON E....... 63
3. REGISTERING AN ENTRY ...... .... 64
REGISTERING A NEW ENTRY............ 64
DISPLAYING AND EDITING THE
ENTRY INFORMATION...................... 66
SENDING STORED CONTACTS TO A
USB MEMORY ................................... 67

2 PHO NE OP ERATION
1 . CALLING ON A Blu etooth ®
PHONE……………….. .......... . 68
BY DIAL ............................................. 68
BY FAVORITES LIST........................... 69
BY PH ONE BOOK ............................... 69
BY CALL LISTS ................................... 70
BY A SHORT MESSAGE….................. 71
BY POI* ENTRY. ................................... 71
2. RECEIVIN G CALLS ON A
Bluet ooth® PHONE
.... ..... ..... 72
3. TALKING ON A Blueto oth
®
PHONE .. .................................... 73
SEN DING TONES ............................... 74
DIALING A SECOND NUMBER ......... 75
AD JUSTING THE RECEIVER
VOLUME............................................. 76
3 SHORT MESSAGE FUNCTION

1. SHORT MESSAGE FUNCTION . 77
RECEIVING A SHORT MESSAGE ... 77
CHECKING RECEIVED SHORT
MESSA GES........................................ 77
CHECKING SENT SHORT
MESSA GES........................................ 78
SENDING A NEW SHORT
MESSAGE........................................... 79
4
WH AT TO DO IF...

1. TROUBLESHOOT ING. ..... ... ..... ... 82



Some of the functions cannot be operated
while driving.
*: Point of Interest



57

1. BASIC INFORMATION BEFORE OPERATION
1. QUICK REFERENCE



“Phone” MENU SCREEN






















No. Function Page
Select to display the “ Phone book” screen. An entry from the list of contacts can be selected and called. 69
Select to display the “ Dial” screen. A call can be made by dialing the number. 68
Select to display the “ Favorites ” screen listing the contacts stored within the Premium Audio System. 69
Select to display the “ Messages” screen. A list of received and sent short messages and a menu to create new short messages can be displayed. The sender of the message can also be called.
77
Select to display the “ Call lists” screen. An entry from the “ All” “Missed ”, “Received ” or “Dialed ” call lists can be selected and called. 70

Pressing the button allows access to the “Phone” screens.
Each time the button is pressed, the “ Phone” screen that was last
displayed will be shown.
Press from the “ Phone” screen other than the “Phone ” menu screen
to display the “Phone” menu screen.
1
2
3
4
5
58

1.BASICINFORMATIONBEFOREOPERATION
1.BASIC INFORMATION BE FOREOPERATION
“Dial” SCREEN
“Favorites” SCREEN
“Phone boo k”SCRE EN
“Call lists” SCREEN “Mes
sages” SCREEN
59

1. BASIC INFORMATION BEFORE OPER ATION
2. HANDS -FREE SYSTEM

Bluetooth® h
ands -free system al lows
you to make or receive a call without
taking your hands off the steering
wheel by conn ecting your cellular
phone.
This system supports Bluetooth
®.
Bluetooth® is a wire less data system
by which you can call without your
ce llular phone bei ng conn ected with a
ca ble or placed on a cradle.
The operating procedure of the system
is explained in this section.

WARNING

• Us e a ce llular p hone or conn ect the
Bl uet ooth® phone only when sa fe and
le gal to do so.
• Your audio unit is f itte d wi th Bl uet ooth
®
antennas. Pe ople with imp lantabl e
car diac pacemakers , cardiac
resy nchronizat ion t herapy-p acemakers
or imp lant able card iovert er defi brillat ors
shou ld ma intain a reasonable d istance
between themselves and the Bl uetooth
®
antennas. The radio waves may aff ect
th e o peration o f such devic es.
• Be for e us ing
Bluet ooth® devices, users
o f an y electr ica l medi cal device othe r
th an i mplant able cardiac p acemakers,
card iac resynchro niz ation ther apy -
pac emaker s or implan table cardi overter
def ibrillat ors should cons ult the
ma nufa ctur er of the device for
inf orma tion abo ut its operation under
the influence of radio waves. Rad io
wav es could have unex pected eff ects
on the op eratio n of such medica l
dev ices.

NOTICE
INFORMA
TION
•
If your cellular phone does not suppo rt
• Bl uetooth®, this sys tem will not f unction.
• In the follow ing conditions, the system
ma y not funct ion:
• The cellular phone is turned of f.
• Th e cu rrent posi tio n i
s out side t he
c ommun ication ar ea.
• The cellular phone is not connected.

• The cellular phone has a low batter y.
• Whe n us ing Blue tooth® aud io and
hands- free at the same ti me, the
fol lowi ng pr oblems may occur.
• The Blue tooth
® connect ion may be
c ut .
• Noise may be h eard on the Bl uetooth
®

audio playback.

Do not leave your cellular phone in the
veh icle. The tempera tur e in side ma y rise
to a le vel that cou ld dama ge the ph one.
60

1. BASIC INFORMATION BEFORE OPERATION

USING THE PHONE SWITCH/
MICROPHO NE



 Steeri ng switch (IF EQUIPPED)














Volum e control sw itch
 Pr ess the “+ ” side to i ncrease the vo lume.
 Press the “-” side to decrease the volume.
 Microph one
INFORMA
TION
 Th e othe r par ty’s voice will be h eard
fro m the front speak ers. Th e audio
sys tem will be muted during phon e
c al ls.
 Ta lk a lternately with the ot her p arty
on the phone . If you t alk at the same
t im e, yo ur voices may not re ach each
ot her. ( It is not a malfunct ion.)
 Kee p the volume o f rece iving voice
down. Otherw ise, an echo will be
h eard and rece iving voice can be
he ard o utside of the vehicle. When you
ta lk on t he phone, speak cl early
towards the micro phone.
 In th e f o
l lowing situ ations, your vo ice
ma y not reach the ot her party.
• Dr iving on an unpaved road. (Due
to tra ffic noise.)
• Dr ivi ng a t high speed.
• A window is open.
• Turnin g the air-conditioni ng
vents towards the mi crophone.
• Th e sound of the a ir-conditio ning fan
is loud.
• Ther e is an effect from the cellular
phone n etwork.

The micropho ne is used when talking
on the phone.
By pressing the volume buttons
on the steering wheel (where
equipped) during a call, you can
adjust the call volume without
taking your hands off the steering
wheel.
61

1. BASIC INFORMATION BE FORE OPERATION


ABOUT
THE PHONE BOOK IN
THIS SYSTEM
 The following data is st ore d for every
regi stere d phon e. When another p hone is
conn ecting , you cannot read the
re giste red dat a.
• P hone b ook data
• Call hist ory data
INFORMA TION
When you d elete the pho ne, th e above
listed details are also deleted.
WHEN YOU SELL YOUR C AR

A lot of personal data is registered
when you use the Hands-free system.
Wh en you sell your car, erase your
data. (→P.90)
 You can erase the following data from the 3 sy
stem.
• Ph one book dat a
• Call h istor y data
• Volume setting
• Bluet ooth
® setting
• A ll te lepho n e settings
• Sh ort message templa te

INFORMATION
When utilizing the “ Delete all personal
data ” function, all personal da ta will be
erased.
62

1. BASIC INFORMATION BEFORE OPERATION
CONNECTI NG A Bluetooth®

PHONE

In order to us e the hands -free system,
it is necessary to pair the phone and
connect the phone’s profile (HFP) with
the system.
Once the profile has been connected,
hands -free calls can be made.
If you have not yet connected any
Bluetooth
® phone s with phone profile
(HFP), you must first connec t your
phone with phone profile (HFP)
according to the following procedure.
Connect your Bluet ooth
® phone with
phone profile (HFP) after bringing the
vehicle to a complete stop.

1
Pres
s the button.


2 Selec t “Yes” if prompted (if no phone
paired to the Premium Audio System
the following screen will be shown) .

 If there are no paired devices t his
s creen can be d ispla yed by pressing
the
switch on the s teering wheel
(IF EQIUPPED) .

3 Follow the step s “PAI RING A
Bl uetooth
® DEVICE”. ( →P.97, 101)
63

1. BASIC INFORMATION BEFORE OPER ATION
3. REGISTERING AN ENTRY

REGISTERING A NEW ENTRY





6 C heck that the en try is reg istered in the
“Favorites ” list.

REGISTERI NG FROM THE
“Favor ites” SCREEN

1 Display the “Phon e” menu screen and
select “Favorites” . (→P.58)
2 Select “Create n ew e ntry” .

3 Select one of 4 ph one types ( ,
, or ) and en ter
a numb er.


 You can enter one phone number for
ea ch phone type.

4 Select .
5 Enter the entry name a nd then select
“OK” .






 Se lect t o dis pla y an d edi t the
entry inf ormation. (→P.6 9)

REGISTERING FAVOR ITES
FROM THE “ Dial” SC REEN

1 Display the “Pho ne” me nu scree n.
(→P. 58)
2 Select “Dial number ”.
3 Enter the num bers.
4 Select .
5 Follow the step s “REGIS TERING
FROM THE “ Favorites”
SCREEN ” from “STEP 5”. (→ P.64)
INFORMATION

The phone t ype is re gis tere d as .
Up to 200 numbers can be
register ed in the “Favorites” list of
the Premium Audio System.
64
