2018 Ram 3500 Chassis Cab Owner's Manual

WARNING!
Do not operate this vehicle with a console compart-
ment lid in the open position. Driving with the console
compartment lid open may result in injury in a colli-
sion.The center console is equipped with a front storage bin
located next to the cupholders. This storage bin may be
equipped with a manual sliding top door.
Lower Storage Bin
Front Storage Bin With Door — If Equipped
3
GETTING TO KNOW YOUR VEHICLE 111

Seatback Storage
Located in the back of both the driver and passenger front
seats are pockets that can be used for storage.
Second Row In-Floor Storage Bin — If Equipped
In-floor storage bins are located in front of the second row
seats and can be used for extra storage. The storage bins
have removable liners that can be easily removed for
cleaning.
To open in-floor storage bin, lift upward on the handle of
the latch and open the lid.
Driver ’s Side Seatback Storage
In-Floor Storage Bin And Latch
112 GETTING TO KNOW YOUR VEHICLE

NOTE:The front seat may have to be moved forward to
fully open the lid.
Storage Bin (Regular Cab)
The storage bin is located behind the front seats and runs
the length of the cab.
Fold Flat Load Floor — If Equipped
Quad Cab and Crew Cab models with a 60/40 rear seat
may be equipped with a folding load floor.
WARNING!
Do not operate the vehicle with loose items stored on
the load floor. While driving or in an accident you may
experience abrupt stopping, rapid acceleration, or
sharp turns. Loose objects stored on the load floor may
move around with force and strike occupants, resulting
in serious or fatal injury.
Opened Storage Bin
Storage Bin
3
GETTING TO KNOW YOUR VEHICLE 113

Unfolding The Load Floor/Quad Cab
1. Lift the 60/40 seat cushion(s) to the upward position.2. Grasp the knob on the load floor and lift the knob until
the load floor unfolds into position.
3. Reverse the procedure to store the load floor.
Unfolding The Load FloorLoad Floor In Open Position
114 GETTING TO KNOW YOUR VEHICLE

Unfolding The Load Floor/Crew Cab
1. Lift the 60/40 seat cushion(s) to the upward position.2. Unfold both the legs using the straps.
Load Floor Legs In Stowed Position
Load Floor Legs In Opened Position
3
GETTING TO KNOW YOUR VEHICLE 115

3. Lift the front panel until the load floor unfolds intoposition.
4. Reverse the procedure to store the load floor.
Positioning The Load Floor For Storage Access Under
The Seat
1. Lift the 60/40 seat cushion(s) to the upward position.
2. Unsnap the securing snap located at either side of the load floor. 3. Lift the load floor up to access storage under the load
floor.
WARNING!
Do not drive with the load floor in the up position.
When stopping fast or in an accident, the load floor
could move to the down position causing serious
injury.
Quad Cab — If Equipped
Load Floor In Open Position
Load Floor Securing Straps/Quad Cab
116 GETTING TO KNOW YOUR VEHICLE

Crew Cab — If Equipped
4. Reverse the procedure to put the load floor back in thesecured down position before you operate the vehicle.Below Rear Seat Storage (Crew Cab/Quad Cab)
The Crew Cab and Quad Cab models provide additional
storage under the rear seats. Lift the seats to access the
storage compartment.
To open the storage compartments, unsnap the securing
snap located at either side of the load floor and lift upward
on the fold flat lid.
NOTE: For more information on storage and the fold flat
floor, refer to “Fold Flat Load Floor” in this section.
Load Floor Securing Straps/Crew Cab
Crew Cab Storage
3
GETTING TO KNOW YOUR VEHICLE 117

Cupholders
Front Seat Cupholders
For vehicles equipped with bucket seats, two cupholders
are located next to the center console storage bin.
Vehicles Equipped With 40/20/40 Seats
The cupholders are located on the backside of the center
portion of the front seat (20). Fold down the center section
of the front seat to gain access to the cupholders.
Rear Cupholders — If Equipped
Some vehicles are equipped with rear cupholders located
in the center armrest.
Front Cupholders For Bucket Seats
Rear Armrest Cupholder
118 GETTING TO KNOW YOUR VEHICLE
