2018 FIAT 500 engine

181
Fuel tank (litres): 35 35
Including a reserve of (litres): 5 5
Engine cooling system
(litres): 6.3 6.3
Engine sump (litres): 2.8 3.7
Engine sump and filter (litres): 3.0 3.9
Gearbox
casing/differential: 1.55 (kg) 1.55 (kg)
Hydraulic brake circuit (kg): 0.55 0.55
Hydraulic clutch controls
(RH drive versions): – –
Hydraulic clutch controls
(RH drive versions): 2.5 2.5
When the vehicle is used in particularly harsh weather conditions, we recommend using a 60% mixture of PARAFLUUPand 40% of
demineralised water.
Diesel versions1.3 16V Multijet
95 HP EURO 51.3 16V 78 HP / 95 HP
EURO 6Prescribed fuels and
original lubricants
Diesel for motor vehicles (EN590
specifications)
Mixture of distilled water and
PARAFLU
UPat 50%
SELENIA WR P.E.
TUTELA TRANSMISSION GEARFORCE
TUTELA TOP 4 or TUTELA TOP 4/S
Mixture of water and
PETRONAS DURANCE SC35
Maximum refuelling capacity (including reserve): 30.5 litres of LPG
The figure already takes into account the 80% tank filling limit and the residual fluid required for priming; this figure
represents the maximum permitted capacity. There may be slight variations to this figure as a result of:
differences between the network pump supply pressures, pumps having different supply/locking features,
tank not completely run out of fuel.
LPG versions

TECHNICAL DATA
182
Replacement
frequency
FLUIDS AND LUBRICANTS 39) 22) 3)
Your vehicle is equipped with an engine oil that has been thoroughly developed and tested in order to meet the requirements
of the Scheduled Servicing Plan. Constant use of the prescribed lubricants guarantees the fuel consumption and emission
specifications. Lubricant quality is crucial for engine operation and duration.
If lubricants conforming to the specific request are not available, products that meet the indicated specifications can be used
to top up; in this case optimal performance of the engine is not guaranteed.
PRODUCT SPECIFICATIONS
Lubricants for petrol
engines
(versioni 1.2 8v e 1.4 16V)
Lubricants for
petrol engines
(TwinAir versions only)
Lubricants for
Euro 5 diesel engines
Lubricants for
Euro 6 diesel engines
Lubricant for
petrol/LPG engines
Protective agent for
radiators
9.55535-S2
specifications
9.55535-GS1
9.55535-S1
9.55535-DSI or
MS.90047
9.55535-T2
9.55523 or MS.90032SELENIA K P.E.
Contractual Technical
Reference No. F603.C07
SELENIA DIGITEK P.E.
Contractual Technical
Reference No. F020.B12
SELENIA WR P.E.
Contractual Technical
Reference No. F510.D07
SELENIA WR FORWARD
Contractual Technical
Reference No. F842.F13
SELENIA MULTIPOWER
GAS 5W-40
Contractual Technical
Reference No. F922.E09
PARAFLU
UPContractual Technical
Reference No. F101.M01According to Scheduled
Servicing Plan
According to Scheduled
Servicing Plan
According to Scheduled
Servicing Plan
According to Scheduled
Servicing Plan
According to Scheduled
Servicing Plan
Cooling circuits proportions
of use:
50% demineralised water
50% PARAFLU
UP
UseFeaturesSpecificationsGenuine fluids and
lubricants
SAE 5W-40
ACEA C3 / API SN.
SAE 0W-30
ACEA C2 / API SN.
SAE 5W-30 ACEA C2.
SAE 0W-30 ACEA C2.
SAE 5W-40
ACEA C3 / API SN.
Protective agent with antifreeze
action with organic formulation.
CUNA NC 956-16,
ASTM D 3306.
IMPORTANT Do not top up or mix with other fluids which have different specifications from those described.When the vehicle is used in particularly harsh weather conditions, we recommend using a 60% mixture of PARAFLUUPand 40% of demineralised water.

183
Brake fluid
Diesel additive
Windscreen/rear
window washer
fluid
Applications
TUTELA TRANSMISSION
GEARFORCE
Contractual Technical
Reference No. F002.F10
TUTELA CS SPEED
Contractual Technical
Reference No. F005.F98
TUTELA ALL STAR
Contractual Technical
Reference No. F702.G07
TUTELA STAR 700
Contractual Technical
Reference No. F701.C07
TUTELA STAR 325
Contractual Technical
Reference No. F301.D03
TUTELA TOP 4
Contractual Technical
Reference N° F001.A93
or
TUTELA TOP 4/S
Contractual Technical
Reference N° F005.F15
TUTELA DIESEL ART Contractual
Technical Reference No. F601.L06
PETRONAS DURANCE SC 35
Contractual Technical
ReferenceNo. F001.D16Mechanical gearbox
and differential
Hydraulic actuation
system lubricant
Dualogic gearbox
Wheel side HP joints
Differential side HP joints
(excluding 1.4 16V
100 HP versions)
Differential side HP joints
(1.4 16V 100
HP versions)
Hydraulic brakes and
hydraulic clutch controls
To be mixed with diesel
25 cc per 10 litres
To be used diluted or
undiluted in windscreen
washer/wiper systems
UseFeaturesSpecificationsGenuine fluids and
lubricants
Oils and greases
for drivelineSAE 75W API GL4
grade synthetic lubricant
Specific fluid for electro-hydraulic
actuators
“ATF DEXRON III” type oil
Molybdenum disulphide grease,
for use at high temperatures.
N.L.G.I. consistency 1-2
Grease for constant velocity joints
with low friction coefficient.
N.L.G.I. consistency 0-1
Polyurea synthetic-based grease
suitable for high temperatures.
NL.G.I. consistency 2
Synthetic fluid for brake and clutch
systems. Exceeds specifications
F.M.V.S.S. no. 116 DOT 4,
ISO 4925 SAE J1704
Antifreeze additive for diesel,
with protective action for diesel engines
Mixture of alcohol, water and
surfactants CUNA NC 956-II9.55550-MZ6
9.55550-SA1
9.55580-GRAS II
9.55580-GRAS II
9.55580-GRAS II
9.55597
or
MS.90039
–
9.55522
or
MS.90043
