2017 VOLKSWAGEN TOUAREG Owner´s Manual

Contents

Fig. 334 Contents of the vehicle tool kit.

Wheel trim

Wheel bolt caps

Fig. 336 Pulling cover caps off wheel bolts.

Tire mobility set

WARNING
Using the tire mobility set on the side of the road can be dangerous. To help reduce the risk of serious personal injury:
x Always stop the vehicle as soon as it is safe to do so and move the vehicle a safe distance off the road where it is safe to use the tire mobility set.
x Make sure that the ground is level and firm.
x All passengers and especially children must stay a safe distance away from you while you are working and keep out of the area you are working in.
x Turn on the emergency flasher and set up another warning device about 25 yards (25 meters) behind the vehicle to warn approaching traffic.
x Use the tire mobility set only if you are familiar with the necessary steps. Otherwise, get expert assistance.
x Use the tire mobility set only in emergencies and only until you can get professional help.
x Immediately replace a tire repaired with the tire mobility set.
x Sealant is harmful and must immediately be removed in case of skin contact.
x Always store the tire mobility set out of reach of children.
x Never use a vehicle jack, even if the jack is approved for use with your vehicle.
x Always switch off the engine, engage the electronic parking brake, and shift the transmis-sion into Park (P) to reduce the risk that the vehicle will move unexpectedly.
WARNING
Improper use of the tire mobility set can cause a temporary tire to fail and lead to loss of vehicle control and serious personal injuries.
x Always remember that a tire filled with sealant does not handle as well as an undamaged tire without sealant.
x Never drive faster than 50 mph (80 km/h) with a sealed tire.
x Never use the tire mobility set if the outside temperature is below –4 °F (–20 °C).
x Never drive with a tire that has cuts or punctures, especially when they are larger than 3/16 in (4 mm).
x Use the tire mobility set only for emergencies until you can get professional help.
x If the tire cannot be inflated to at least 36 psi (2.5 bar), do not drive the vehicle. Contact the nearest authorized Volkswagen dealer, authorized Volkswagen Service Facility, or other qual-ified workshop.
x If the tire inflation pressure drops below 26 psi (1.8 bar) after driving for 10 minutes, do not drive the vehicle any farther. Contact the nearest authorized Volkswagen dealer, author-ized Volkswagen Service Facility, or other qualified workshop.
x Always replace a tire repaired with the tire mobility set immediately. Do not drive a tire that has been repaired with the tire mobility set longer or farther than is absolutely necessary.
x Avoid full throttle acceleration, hard, braking, and fast cornering.
x Drive at slow speed for 10 minutes. Then get out and check the air pressure and condition of the sealed tire.
Obey all legal requirements when disposing of used or expired sealant.
New tire inflation cylinders are available from authorized Volkswagen dealers and authorized Volkswagen Service Facilities.

Read the separate user manual of the manufacturer of the tire mobility set.
Contents of the tire mobility set

Fig. 343 Basic diagram: Contents of the tire mobility set.

Checklist
Carry out the following steps in the order listed before starting to inflate a tire ⇒ :
1. If you have a flat tire, move it as far away from traffic as possible. Park the vehicle on a flat, level surface at a safe spot.
2. Apply the electronic parking brake
3. Automatic transmission: Shift the transmission into Park (P).
4. Stop the engine and remove the key from the ignition switch
5. Have all passengers exit and go to a safe place, such as behind the guard rail.
6. Switch on emergency flashers and put up the warning triangle. Observe all legal requirements.
7. Check whether a repair with the tire mobility set is possible
8. If towing a trailer: Unhitch the trailer from the vehicle and park the trailer properly.
9. If the luggage compartment is loaded: Remove the luggage.
10. Remove the tire mobility set from the luggage compartment.
11. Affix the label ⇒ fig. 343 (2) from the tire mobility set on the dashboard in the driver's field of vision.
12. The foreign object (screw or nail, for example) should not be removed from the tire!
WARNING
Disregarding the safety-related checklist may lead to accidents and serious injuries.
x Always review and follow the checklist. Follow accepted safety practices and use common sense.
Sealing and inflating the tire

Fig. 344 In the engine compartment: Compressor connection terminals.
