2017 VOLKSWAGEN TOUAREG Owner´s Manual

Connectable data media Requirements for playback via the
Infotainment System
– USB flash drives (USB sticks).
– USB data media that do not
need special drivers.
– External USB flash drives.
– External USB hard drives (HDD)
- 1'', 1,8'', 2,5'' with maximum
peak and continuous current
500 mA.
– iPods® and iPhones® of various
generations7.
– USB 2.0 enabled media.
– Subclass 1 and 6 USB devices (note
manufacturer's information).
– Data media in the FAT or FAT32 file
systems.
– Limit of 4 partitions and 4000 files on
the data medium.
– Limit of 1000 files per directory.

Connecting and operating

Fig. 162 Selection menu of available media sources.

x In the Audio menu, press the Source function key ⇒ fig. 162.
x In the pop-up window, press the / AUX feature key.
Further operation of the external data medium (changing track, selecting tracks and playback modes)
is described in the appropriate chapters of this manual ⇒ page 277.
iPod® and iPhone®
When an iPod® or iPhone® is connected, a special iPod selection menu is displayed at the top selec-
tion level similar to the Media center selection menu ⇒ page 277. There you can select list views specific to the iPod ( Playlists,  Artists,  Albums,  Songs,  Podcasts etc.).
The iPod selection menu is used as normal.
The music control of a connected iPod® or iPhone® is disabled.
The output volume of some iPods® or iPhones® can be adjusted to the volume of the other audio sources
Files cannot be imported from an iPod® or iPhone®. The setting for the Repeat feature cannot be changed.
Possible error messages after connecting an external data medium

Error message Cause Remedy
Device is not
supported.
Playback of the external
data medium or commu-
nication via the adapter
cable is not possible.
Check the adapter cable.
Update software of the
MEDIA-IN multimedia jack
via the Volkswagen dealer.
If possible, update the soft-
ware of the external data
medium.
Device not
functional
Communication malfunc-
tioning.
Verify the connection and
functionality of external data
medium.


Due to the large number of different types of data media and several iPod®
and iPhone® generations, no guarantee can be made that all functions
described can be executed without errors.

Media mode (video DVDs)

Starting video DVD mode and operating the DVD film menu

Fig. 163 Video DVD menu.

Fig. 164 DVD menu options of the inserted film.

Opening the DVD film menu manually
The DVD film menu must be opened manually if the DVD film menu does not open automatically with the unit's own menu control, or if the video DVD is already being played.
x In the video DVD menu, press the Menu function key to open the unit's own menu control
⇒ fig. 163.
x If an introduction is playing, it can be skipped by pressing the Menu function key in the unit's own
menu control ⇒ fig. 164 (B).
The DVD film menu is displayed (A).
DVD does not start!
Note that an inserted DVD cannot start automatically if the volume is set to “0” (display: ). A played media source is always stopped (paused) in this case.
The visual appearance of the DVD film menus and the menu options which it offers are the responsibility of the DVD manufacturer.
The language of a video DVD for voice output can be changed
The DVD manufacturer is responsible for the different ways in which individual films respond to identical commands.
Video DVD menu: controlling playback and changing display settings

Fig. 165 Video DVD menu.

Chapter selection
x In the Video DVD menu, press the Chapter function key ⇒ fig. 165.
x Press the desired chapter to select it from the list.
Film playback continues from the beginning of the selected chapter.
Changing aspect ratio
The aspect ratio, in which a film is played, can be adapted to the aspect ratio of the screen.
x In the Video DVD menu, press the Extras function key.
x In the pop-up window, press the function key with the set aspect ratio to switch through the availa-ble aspect ratios one after the other.
For further information on possible aspect ratios
DVD settings

Fig. 166 Menu: Video settings.

Introduction to navigation

Navigation data
All navigation data required for navigation is stored in the unit navigation data memory.
Street routing is subject to ongoing changes like, for example, new streets, street names or street numbers. The route guidance may be inaccurate or incorrect if the navigation data is no longer up to date. You should therefore have the unit navigation data memory updated by a Volkswagen dealer-ship on a regular basis. The updates are subject to a fee.
Possible errors in navigation
When the navigation system cannot receive any data from GPS satellites (dense canopy of trees, tunnel, underground car park), navigation can still continue using the vehicle sensors.
In areas that are not or only incompletely digitized on the data medium (such as one-way streets and street type not sufficiently captured), the navigation system also tries to enable route guidance.
Please remember that the navigation may sometimes not be so accurate as usual if the precise vehi-cle position cannot be determined.
Navigation main menu

Fig. 167 Navigation main menu: Destination mode.

Fig. 168 Navigation main menu: Tour mode.
