2017 VOLKSWAGEN TOUAREG Owner´s Manual

x Press the NAV Infotainment button twice in quick succession. After changing to the map display, the main menu Navigation is displayed.
x Press the E function key to switch menu by menu from a navigation submenu to the Navigation main menu.
x You can switch back and forth between the map view and the Navigation main menu by pressing the NAV Infotainment button.
The Navigation main menu is displayed either in “normal” Destination mode or in Tour mode or as the
Waypoint navigation menu ⇒ fig. 208.
If Tour mode ⇒ fig. 168 is displayed
If the Waypoint navigation menu is displayed
Display of the last destination
In the upper third of the screen, the destination last used as route guidance is displayed.
x Briefly touch the display box to show the displayed destination in the detailed view.
x Press the New destination function key followed by the + Address function key to show the displayed destination in the Address entry menu and edit it
If no destination is displayed, this means no route guidance has been started or that the destina-tion memory has been deleted manually
Function keys in the Navigation main menu

Function key: Effect
Options : Defines route options for calculating a route
Position : Opens the current position in the detailed view and displays the
coordinates.
Store : Stores the displayed position in the destination memory
$: Stores the current position as a “Flagged destination” in the destination
memory
: Enter home address or show home address in the Navigation main
menu
New destination : Opens the selection menu for entry of destination
Memory : Opens a pop-up window for storing the current destination, load-
ing stored destinations or managing destinations
Route : Opens options for route guidance

Function key: Effect

Route list : Shows street names or street designations of the route
section to be driven.
Remove area to avoid : Removes an entered route exclusion.
Avoid area : To enter a route exclusion.
Extras : Opens a pop-up window.

New stopover : For entering a stopover
Tour mode : For switching to tour mode in order to drive to several
destinations during route guidance
Waypoint mode : For navigation in off-road areas (waypoint naviga-
tion)
Start : Starts route guidance to the displayed destination

Destination entry

Destination entry menu: defining destination selection

Fig. 169 Menu: Destination entry.

Function key: Type of destination selection
( Last destinations : Select a destination from the list of recent destina-
tions for which route guidance was started
) Favorites : Select the destination from the list of destinations stored as
favorite destinations
* Directory : Select the destination from the list of manually stored desti-
nations

Address: selecting a destination address

Fig. 170 Selecting addresses.

Fig. 171 Country and town selected: Narrowing down the address.

For further functions in the Address entry menu and if a destination is already displayed
Selecting destination parameters for the destination address
A new destination address must always be selected in the displayed sequence, first the country, then the town, etc. A “town” can be a small village or a zip code area.
The individual destination parameters (country, town, etc.) are selected using input windows
x Press the Country function key and select the desired country.
x Press the City/zip function key and select the town or zip code.
Once a town has been selected, it is already possible to start route guidance to the town center
⇒ fig. 171.
The destination address can be narrowed down further by entering a street and, following that, a house number or intersection.
x Press the Enter/show destination on map function key to select the destination in the map view When narrowing down the destination address, please note that every entry restricts the available range of subsequent selections. For instance, if the street you are looking for is not in the zip code area you have selected in a previous window, you will not be able to find the street at the street selec-tion stage.
Finishing destination input
x Press the Start route guidance function key to start route guidance to the entered destination
x OR: Press the Store in directory function key to store the destination in the destination memory
Address entry menu

Fig. 172 Navigation main menu with destination.

Fig. 173 Address input menu with destination address.

Search for points of interest using point of interest categories

Fig. 174 Selection for point of interest search.

Fig. 175 Special destination detailed view.
