202
3008-2_en_Chap06_conduite_ed01-2016
Key not detected
Back-up starting
A back-up reader is fitted to the steering
column to allow the engine to be started if
the system does not detect the key in the
recognition zone, or when the battery in the
electronic key is discharged.
F
P
lace and hold the remote control against
the reader.
F

I
f your vehicle has a manual gearbox, place
the gear lever in neutral then fully depress
the clutch pedal.
F

I
f your vehicle has an automatic gearbox,
select position P then press the brake
pedal firmly.
F

P
ress the " START/STOP " button.
The engine starts.
Emergency switch-off
In the event of an emergency only, the engine
can be switched off without conditions (even
when driving).
Press the " START/STOP " button for about
five


seconds.
In this case, the steering column locks as soon
as the vehicle stops.
F

T

o confirm the instruction to switch off the
engine, press the " START/STOP" button
for about five seconds.
In the event of a fault with the electronic key,
contact a PEUGEOT dealer or a qualified
workshop.
Back-up switch off
When the electronic key is not detected or is
no longer in the recognition zone, a message
appears in the instrument panel when closing a
door or trying to switch off the engine.
Driving

306
3008-2_en_Chap07_infos-pratiques_ed01-2016
To p - u p
F Obtain a bottle of AdBlue®. After first
checking the use-by date, read carefully
the instructions on use on the label before
pouring the contents of the bottle into your
vehicle's AdBlue
® tank. F
A
fter emptying the bottle, wipe away any
spillage around the tank filler using a damp
cloth.
Refit the filler cap
F Refit the blue cap and turn it a 6th of a turn
clockwise, to its stop.
F

C

lose the filler flap.
Important
: if your vehicle's AdBlue
®
tank is completely empty - which is
confirmed by the alert messages and
the impossibility of starting the engine
-
you must add at least 4 litres and no
more than 10 litres. If any fluid is spilt or splashed, wash
immediately with cold water or wipe with
a damp cloth.
If the fluid has crystallised, clean it off
using a sponge and hot water.
Important: when topping-up after
running out of AdBlue
, signalled
by the message " Top-up AdBlue:
starting impossible ", you must wait for
about 5 minutes before switching the
ignition on again, without opening the
driver's door, unlocking the vehicle,
introducing the remote control key
into the ignition switch, or placing
the Keyless Entr y and Star ting
electronic key inside the vehicle.
Switch on the ignition, then wait for
10

seconds before starting the engine.
Practical information

332
3008-2_en_Chap08_en cas-de-panne_ed01-2016
12 V battery
Procedure for starting the engine using another battery or charging a discharged battery.
General points
Protect your eyes and face before
handling the battery.
All operations on the battery must be
carried out in a well ventilated area and
away from naked flames and sources
of sparks, so as to avoid the risk of
explosion or fire.
Wash your hands afterwards.
If your vehicle has an automatic
gearbox, do not try to start the engine
by pushing the vehicle.
Batteries contain harmful substances
such as sulphuric acid and lead.
They must be disposed of in
accordance with regulations and must
not, in any circumstances, be discarded
with household waste.
Take used remote control batteries and
vehicle batteries to a special collection
point.
Lead-acid starter batteries
Access to the battery
The battery is located under the bonnet.
For access to the (+) terminal:
F

r
elease the bonnet using the interior lever,
then the exterior safety catch,
F

r
aise the bonnet and secure it with its stay.
(+) Positive terminal.
It has a quick-release clamp.
(-) Negative terminal.
As the battery negative terminal is not
accessible, a remote earth point is located
close to the battery.
In the event of a breakdown

335
3008-2_en_Chap08_en cas-de-panne_ed01-2016
Disconnecting the battery
The Stop & Start system may not be
operational during the trip following the
first engine start.
In this case, the system will only be
available again after a continuous
period of immobilisation of the vehicle,
a period which depends on the ambient
temperature and the state of charge of
the battery (up to about 8 hours).
In order to maintain an adequate state of charge
for starting the engine, it is recommended that
the battery be disconnected if the vehicle is
taken out of service for a long period.
Before disconnecting the battery:
F
c

lose all openings (doors, tailgate, windows,
sunroof),
F
s

witch off all electrical consumers (audio
system, wipers, lighting, ...),
F
s

witch off the ignition and wait for
four


minutes.
At the battery, it is only necessary to disconnect
the (+) terminal.
Following reconnection of the
battery
After reconnecting the battery, switch on the
ignition and wait 1 minute before starting to
allow initialisation of the electronic systems.
However, if minor problems persist following
this operation, contact a PEUGEOT dealer or a
qualified workshop.
Referring to the corresponding section, you
must yourself initialise or reset certain systems,
such as:
-

t
he remote control or electronic key
(depending on version),
-

t
he sunroof and its electric blind,
-

t
he electric windows,
-

t
he date and time,
-

t
he radio preset stations.
Quick-release terminal clamp
Disconnecting the (+) terminal
F Ra ise the lever A fully to release the
clamp


B.
F

R
emove the clamp B by lifting it off. Reconnecting the (+) terminal
F

Ra
ise the lever A fully.
F
R
efit the open clamp B on the (+) terminal.
F
P
ush the clamp B fully down.
F
L
ower the lever A to lock the clamp B
.
Do not force the lever as locking will
not be possible if the clamp is not
positioned correctly; start the procedure
again.
8
In the event of a breakdown

348
3008-2_en_Chap11_index-alpha_ed01-2016
Headlamps, automatic dipping ...............17, 149
Headlamps, automatic illumination


.................................. 141, 146 , 147
Headlamps, dipped beam


................17, 323-325
Headlamps, halogen


..................................... 324
Headlamps, main beam
................... 17,

323-325
Head restraints, front
...................................... 93
Head restraints, rear
..................................... 13 0
Heating


.................................... 10, 104 , 10 6 , 108
Hi-Fi system
.................................................. 12 2
Hill Assist Descent Control
.................................................. 20,

166
Hill start assist

............................................... 2

16
Horn ............................................................... 157Inflating tyres
..........................................
10, 345
Inflating tyres and accessories (using the kit)
..........................312
Instrument panel
..................... 12,

13, 40 , 42, 43
Intelligent Traction Control
........................................................ 16

1
ISOFIX


..........................................................187
Isofix mountings
...............................

.............18 6
i- Cockpit amplify function


................................. 98, 102 , 125, 217
Ignition
................

................................... 19 9, 201
Immobiliser, electronic


............................63, 197
Indicator, AdBlue
®
range
....................................................... 30, 37
Indicator, coolant temperature


.................................................. 32
Indicator, engine oil level


.................................................... 36, 40
Indicator lamps, operation


........................................... 17, 19 , 21
Indicator lamps, status


............................................................ 19
Indicators, direction


.............................. 14 4, 324 Jack
........

.......................................................
310
Jump starting
..............................
..................
333
I
J
Key ..................................................... 54, 63 , 64
Key, electronic ..................................... 58, 60-62
Keyless Entry and Starting


......................58, 61- 63 , 197, 200
Key not recognised
....................................... 202
Key with remote control
......................................................... 19

7
Kit, temporary puncture repair


................................................... 309, 312
K
Fuel .......................................................... 10, 283
Fuel consumption ............................................ 10
Fu
el tank ................................................ 281, 282
Fuses


............................................................. 331
Gauge, fuel .................................................... 281
Gearbox, automatic
....... 10,

2 11, 216 , 217, 219 , 302 , 332
Gearbox, manual


....10, 210 , 216 , 217, 219 , 302
Gear lever
..............................

.........................10
Gear lever, automatic gearbox
................

....................................... 2 11
Gear lever, manual gearbox
................

....................................... 210
Gear shift indicator


....................................... 218
Glove box
...................................................... 120
Grab handles
................................................ 11

9
G
Hands-free access ..........................................78
H ands-free tailgate ............................. 76,
78, 79
Hazard warning lamps


..........................157, 307
Headlamp adjustment


...................................145
H
Alphabetical index

350
3008-2_en_Chap11_index-alpha_ed01-2016
Range, AdBlue .................................... 30, 37 , 38
Rear screen, demisting .................................118
Recharging the battery
................................. 33

4
Reduction of electrical load


..........................290
Regeneration of the particle filter
.......................................... 301
Reinitialisation of the under-inflation detection system
.................................224 , 225
Reinitialising the remote control
........................................................... 67
R

eminder, key in ignition ...............................19 9
Remote control
........................ 5

4-56, 60, 62, 63
Removing a wheel
........................................ 319
Removing the mat


......................................... 127
Replacing bulbs


........................... 323, 328 , 330
Replacing fuses
..............................

..............331
Replacing the air filter


...................................301
Replacing the oil filter
................................... 3

01
Replacing the passenger compartment filter


...................................... 301
Reservoir, screenwash
................................. 29

9
Resetting the service indicator


.......................35
Resetting the trip recorder


..............................41
Reset trip

......................................................... 43
R

ev counter

..................................................... 12
Reversing lamps


........................................... 328
Roof bars
....................................................... 2

93
Running out of fuel (Diesel)

..........................3

08 Table of weights

....................................339,

342
Table position


..................................................92
Tables of engines


.................................338, 340
Tailgate
................

............................................75
Ta n k , f u e l


...............................................281, 282
Technical data


...............................338-340, 342
Telephone


.....................................................12 2
Temperature, coolant


......................................32
Third brake lamp


...........................................330
Three flashes (direction indicators)


...................................14 4
T
Starting using another
battery ................................................ 2
02, 333
Stay, bonnet


.................................................. 294
Steering wheel, adjustment
.................................................... 99
S

topping the vehicle

.....................197, 200 , 2 11
Stop & Start


........................ 18, 21 , 44 , 105 , 11 6,
219 , 281 , 294 , 301, 335
Storage


.......................... 11 9, 120 , 124, 13 4 , 13 5
Storage box
................................................... 13

9
Storage compartments
................................. 11

9
Storage wells


........................................ 13 5, 13 9
Storing driving positions


.................................96
Stowing rings


................................................ 13 5
Sunroof, panoramic


........................................ 84
Sun visor


....................................................... 120
Switching off the engine
............................... 19

7
Synchronising the remote control
........................................................... 67
S

aturation of the particle
filter (Diesel)
............................................... 301
Scented air freshener
........................... 12

5 , 126
Screen, monochrome


..................................... 45
Screens, very cold conditions

.................................................. 291
Screenwash, front


......................................... 153
Screenwash, rear


.......................................... 153
SCR (Selective Catalytic Reduction)
............................................ 31,

303
SCR system

............................................ 31, 303
Seat belts
....................................... 1

6 8 -171 , 183
Seat belts, rear


...................................... 169, 170
Seats, electric


................................................. 96
Seats, front
...............................

................. 90, 96
Seats, heated


.................................................. 97
Seats, rear


..................................................... 13 0
Selector, gear


................................................ 2 11
Serial number, vehicle
.................................. 3

45
Service indicator


....................................... 33, 40
Servicing
...............................

.................... 10, 33
Settings, equipment


........................... 45, 48 , 50
Sidelamps


.................... 143, 14 4 , 323 , 324, 328
Side repeater
..............................

.................. 327
Ski flap
..............................

............................ 13 4
Snow chains
......................................... 2

23 , 292
Snow screen


................................................. 291
Socket, 12V


................................................... 314
Socket, 12 V accessory

........ 12

0 , 13 3 , 13 6 , 314
Socket, 230 V

...............................

................. 13 3
Speakers


....................................................... 12 2
Speed limiter


................................ 226, 229 , 231
Speed limit recognition


................................. 227
Speedometer


.................................................. 12
Spotlamps, side


.................................... 148, 327
Stability control (ESC)................... 160, 163 , 16 4
Starting the vehicle


....................... 197, 200 , 2 11
R
Safety, children ..................... 17 3, 17 7 , 178 , 182 ,
18 4 , 18 6 -188 , 19 0
S
Alphabetical index

6
The programmable heating operates independently from the engine.
With the engine off, it preheats the coolant circuit to ensure optimal engine operating temperature
as soon as it is started up.
The programmable heating is switched on by the long range remote control. It may be immediate or
deferred thanks to a programming function.
Programmable heating
Always switch off the programmable heating when refuelling to avoid any risk of fire or
explosion.
The programmable heating is powered by the vehicle fuel tank. Before use, ensure that
the remaining quantity of fuel is sufficient. If the fuel tank is in its reser ve, we strongly
recommend you do not programme the heating.
To avoid the risks of intoxication or asphyxia, the programmable heating must not be used,
even for short periods, in a closed environment such as a garage or workshop which are not
equipped with an exhaust gas extraction system.
Do not park the vehicle on a flammable sur face (dry grass, dead leaves, paper, etc.) - risk of
fire!
The volumetric alarm movement detector
may be disrupted by the programmable
heating air flows when it is operating.
To avoid any untimely triggering of the
alarm when using the programmable
heating, it is advisable that the volumetric
monitoring is deactivated. Adapting the programmable heating
enables you to use it to preheat the
passenger compartment of your vehicle.
Contact a PEUGEOT dealer or a qualified
workshop.
Presentation
The heating programming remote control has
the following buttons and displays:
Remote control
1.
Buttons for functions scroll-down menu.
2. Function symbols:
clock, temperature, operating time,
programmed time, heater operation,
heating management.
3. Digital displays:
time, temperature, operating time,
programmed time or heating level.
4. Off button.
5. On button.
Ease of use and comfort

11
Operating fault
In the event of a fault with the programmable
heating, contact a PEUGEOT dealer or a
qualified workshop.Changing the battery
F Unclip the case.
F Replace the battery observing the
polarities.
F Reset the remote control.
The remote control is powered by a 6V-28L
battery which is provided.
Information on the screen indicates when this
battery needs to be changed.
Resetting the remote control
If the battery is disconnected or when changing
the battery, the remote control must be reset.
F
After turning on the power, within the next
5 seconds, press button 4 for 1 second.
If the operation is successful, the message
"OK " will be displayed on the remote
control's screen.
If there is a fault, the message " FA I L" will
appear.
F Start the operation again.
Do not throw away used batteries, take
them to an approved collection point.
3
Ease of use and comfort
