2017 NISSAN JUKE Quick Reference Guide

7
USB (Universal Serial Bus) CONNECTION PORT/AUX JACK AND
iPod® INTERFACE
The USB port/Aux jack 1 is located
underneath the climate controls.
When a c ompatible USB memory device, iPod®
or auxiliary device is plugged into
the USB port/Aux jack, compatible
audio files stored on the device can
be played through the vehicle’s
audio system.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Heater, air conditioner, audio and phone systems
(section 4)” of your Owner’s Manual.
1
CLOCK SET/ADJUSTMENT
FM/AM RADIO WITH COMPACT DISC (CD) PLAYER (if so equipped) AND FM/AM/SAT
RADIO WITH COMPACT DISC (CD) PLAYER (if so equipped)



1.

Pr
ess the ENTER/SETTING button
1 to
show the “Settings” screen on the display.



2.




Turn the TUNE/SCROLL knob
2 to
highlight “Clock Adjust”.



3.



Pr

ess the ENTER/SETTING button
1 to
highlight the hours or minutes and use the
TUNE/SCROLL knob
2 to adjust the value.



4.



Pr

ess the ENTER/SETTING button
1 to
set the value.
Press the BACK button 3 to return to the previous screen.
SETTING DISPLAY BRIGHTNESS AND BUTTON BRIGHTNESS
To adjust the Display Brightness and
Button Brightness:



1.
Press the D-MODE Select button.



2.
Press the SETUP button.



3.

T
urn the Selection dial to “ Display Brightness”
or “Button Brightness” then press the
ENTER button.



4.

T
urn the Selection dial to “+ ” to increase
brightness or to “- ” to decrease brightness
then press the ENTER button to apply
the selection.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and feature information.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
1
3
2
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

8
WITH NAVIGATION (if so equipped)
To adjust the time and the appearance of the clock on the display:



1.
Press the
button
4.



2.

Touch the “Settings” key.



3.

Touch the “System” key.



4.

Touch the “Clock” key.
The following settings can be adjusted:



• Time F
ormat: The clock can be set to 12 hours or 24 hours.



•

Date F
ormat: The date can be changed to one of five different formats.



•

Clock Mode:
From here, the clock mode options are:



·

Manual
: Allows for the option “Set Clock
Manually”. Touch this to begin setting the
clock manually using the “+” or “–” to
adjust the hours, minutes, day and month
up or down.



· Time Z
one: Touch the “Time Zone” key
5
to choose from the applicable time zone
list and/or touch “Daylight Savings Time”
to switch between ON and OFF.



·


A

uto: Automatically sets the clock to the vehicle’s current location.
Press the B ACK button 6 to return to the previous screen.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Heater, air conditioner, audio and phone systems (section 4)” of your
Owner’s Manual.
6
4
5
ESSENTIAL INFORMATION
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

9
FIRST DRIVE FEATURES
NISSAN INTELLIGENT KEY® SYSTEM
The Nissan Intelligent Key® system allows you to
lock or unlock the vehicle, open your lif tgate and
start the engine. It is important to make sure the
Intelligent Key is with you (that is, in your pocket
or purse).
The operating range of the Intelligent Key is
within 31.5 in (80 cm) from each
request switch.
To lock the vehicle, push either door handle request switch
1, push the lif tgate request
switch
2 or press the button 3 on
the key fob.
To unlock the vehicle, perform one of the following procedures:



•

Push an
y door handle request switch
1
once; the corresponding door will unlock.
Push the request switch
1 again within 1
minute; all other doors will unlock, or



•


Pr

ess the
button 4 on the key fob to
unlock the driver’s side door. Press the

button
4 again; all other doors will unlock.
The Intel ligent Key can also be used to
activate the panic alarm by pressing and
holding the
button 5 for more than 1
second. Once activated, the panic alarm and
headlights will stay on for a period of time.
INTELLIGENT KEY BATTERY DISCHARGE
If the bat tery of the Intelligent Key is
discharged or environmental conditions
interfere with the Intelligent Key operation,
start the engine according to the
following procedure:



1.

Mo
ve the shif t lever to the P (PARK) position
(Continuously Variable Transmission) or to
the N (NEUTRAL) position
(manual transmission).



2.
Firmly apply the foot brake.



3.

Push the ignition switch with the Intel
ligent Key, and a chime will sound.



4.

Within 10 sec
onds af ter the chime sounds, push the ignition switch while
depressing the brake pedal and the engine will start.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Pre-driving checks and adjustments (section 3)”, the “Starting and
driving (section 5)” and the “Do-it-yourself (section 8)” of your Owner’s Manual.
1
3
4
5
2
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

10
LIFTGATE RELEASE
It is important to make sure the Intelligent Key
is with you (that is, in your pocket or purse).
To open the lif tgate, first unlock the lif tgate using one of the following methods:


• Pr
ess the
button 1 on the key fob twice.



• Push the lif

tgate request switch
2.
Then push the lif tgate release switch 3 and
pull the lif tgate up.
Please see your Owner’s Manual for
important safety information, system
limitations, and additional operating and
feature information.
For more information, refer to the
“Pre-driving checks and adjustments
(section 3)” of your Owner’s Manual.
HEATED SEATS (if so equipped)
The seats are warmed by built-in heaters. The switches 1, located on the center console,
can be operated independently of each other.
Push the HI (high) side of the switch for high
heat. Push the LO (low) side of the switch for
low heat.
The indic ator light on the switch will
illuminate when the heater is on. The
indicator light will remain on as long as the switch is on.
To turn off the heater, return the switch to the level position. Be certain the indicator light extinguishes.
The heater is controlled by a thermostat, automatically turning the heating element on and off.
When the v ehicle’s interior is warmed or before you leave the vehicle, be sure to
turn the switch off.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
1
23
FIRST DRIVE FEATURES
1
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

11
STARTING/STOPPING THE ENGINE
CONTINUOUSLY VARIABLE TRANSMISSION
(if so equipped)

It is impor tant to make sure the Nissan
Intelligent Key® is with you (that is, in your
pocket or purse).
Depress the brake pedal.
Move the shif t lever to the P (PARK) position.
Press the ignition switch START/STOP button to start the engine.
MANUAL TRANSMISSION (if so equipped)
Depress the brake pedal.
Move the shif t lever to the N (NEUTRAL) position.
Depress the clutch pedal to the floor while pressing the ignition switch START/STOP button to start the engine.
TURNING THE ENGINE OFF
For a Continuously Variable Transmission, move the shif t lever to the P (PARK) position, apply the parking brake and press the ignition switch
START/STOP button
For a manual transmission, apply the foot brake and place the vehicle in 1st (FIRST) gear, then apply the parking brake and press the ignition switch
START/STOP button.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
2
1
OUTSIDE MIRROR CONTROL SWITCH
The outside mirr or control switch is located
on the lef t side of the instrument panel.
To select the lef t or right mirror, move the switch
1.
Adjust each mirror to the desired position using the control switch
2.
To prevent accidentally moving the mirror, move the switch
1 to the center
(neutral) position.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your
Owner’s Manual.
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

12
HEADLIGHT CONTROL SWITCH
HEADLIGHT CONTROL
Turn the headlight control switch to the
position
1 to turn on the front parking, side
marker, tail, license plate and instrument
panel lights. Turn the switch to the

position 2 to turn on the headlights.
AUTOLIGHT SYSTEM (if so equipped)
The autolight system wil l automatically turn the headlights on when it is dark
and off when it is light. The system will keep the headlights on for a period of
time af ter you turn the ignition off and all doors are closed.
To activate the autolight system, turn the headlight control switch to the AUTO
position
3 then push the ignition switch to ON. To deactivate the autolight
system, turn the headlight control switch to the OFF position,
position 1
or position 2.
HIGH BEAM SELECT
With the he adlights ON (either in the AUTO
or
position), push the headlight control
switch forward
4 to select the high beam
function. The blue indicator light
will
illuminate in the instrument panel. Pull the
headlight switch back to the original position
to select the low beam. The blue indicator
light will extinguish.
Pull and release the headlight control switch
5 to flash the headlight high beams
on and off.
FOG LIGHT SWITCH (if so equipped)
The headlights must be on and the low beams
selected for the fog lights to operate.
Turn the switch (inside collar) to the position 6 to turn the fog lights on.
Turn the switch (inside collar) to the OFF position to turn the fog lights off.
LANE CHANGE SIGNAL
Move the lever up or down until the turn signal begins to flash but the lever does not latch to signal a lane change. Hold the lever until the lane change
is completed.
Move the lever up or down until the turn signal begins to flash but the lever does not latch and release the lever. The turn signal will automatically flash three times.
Choose the appr opriate method to signal a lane change based on the road and
traffic conditions.
Please see your Owner’s Manual for important safety information, system limitations, and additional
operating and feature information.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
3
1
2
5
6
FIRST DRIVE FEATURES
4
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

13
WIPER AND WASHER SWITCH
Move the lever to one of the following positions to operate the windshield wipers:
1 Mist (MIST) - One sweep operation of the
front wipers.
2 Intermittent (INT) - Wipers operate
intermittently. The intermittent speed can
be adjusted by rotating the control ring
3 to increase or decrease wiper speed.
4 Low (LO) - Front wipers operate at a
continuous low-speed.
5 High (HI) - Front wipers operate at a
continuous high-speed.
6 Pull the lever toward you to activate the front washer. The front wipers will
operate several times.
REAR WIPER AND WASHER
7 Intermittent (INT) - Rear wiper
operates intermittently.
8 Low (ON) - Rear wiper operates at a
continuous low-speed.
9 Push the lev er forward to activate the
rear washer. The rear wiper will operate
several times.
WIPER BLADE REPLACEMENT PROCEDURE
The windshield wipers must be in the service position in order to replace the wiper
blades. To move the wiper blades to the service position, follow this procedure:
When the ignition switch is in the ON position or within 60 sec onds of placing
the ignition switch in the OFF position, lif t the windshield wiper and washer
lever up to the MIST
position 1 two times in less than 0.5 seconds. The
windshield wipers will move to the service position automatically, and the wiper
blades can now be replaced.
To move the wiper blades back to the original position:
Lift the windshield wiper and washer lever up or lower the lever down to operate at any
wiper speed.
Please see your Owner’s Manual for important safety
information, system limitations, and additional operating and
feature information.
For more information, refer to the “Instruments and controls
(section 2)” and the “Do-it-yourself (section 8)” of your
Owner’s Manual.
69
1
2
4
5
MIST
OFF
INT
LO
HI3
INT
ON7
8
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.

14
HEATER AND AIR CONDITIONER (automatic)
(with Integrated Control System) (if so equipped)
1 CLIMATE BUTTON
Press the CLIMATE button to access the Climate Control mode.
When in Climate Control mode, the selected temperature, air flow and
automatic mode or manual mode are indicated on the display.
2 AUTO BUTTON/TEMPERATURE CONTROL DIAL
The automatic mode c an be used year-round. Press the AUTO button to turn
the system on, and the fan speed, air flow distribution and temperature will
be automatically maintained.
Turn the temperature control dial lef t for cooler air or right for warmer air.
3 FAN SPEED CONTROL DIAL
Turn the fan speed control dial to the lef t to decrease fan speed or to the
right to increase fan speed.
4 AIR FLOW CONTROL BUTTONS
Press the preferred air flow control button to select one of the following air flow outlets:



Air flows from the center and side vents.



Air flows from the center, side and foot vents.



Air flows mainly from the foot vents.



Air flows from the front defroster and foot vents.
5 DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS
Press the front defroster button to turn the system on. The A/C
automatically turns on when the front defroster mode is selected. This
feature removes humidity from the air.
Use the temper ature control dial 2 to set the desired temperature.
To set the front defroster on high, turn the fan speed control dial 3 to
increase the fan speed to the maximum setting.
6 REAR WINDOW AND OUTSIDE MIRROR (if so equipped) DEFROSTER SWITCH
Push the r ear window and outside mirror (if so equipped) defroster switch
to turn the system on or off.
The rear window and outside mirror defroster automatically turns off af ter approximately 15 minutes.
32
1
8
9
756
4
FIRST DRIVE FEATURES
To view detailed instructional videos regarding these and other features, please go to www.nissanownersinfo.mobi.
