2017 KIA OPTIMA PHEV Features and Functions Guide

MAINTENANCE
* And, if necessary, adjust, correct, clean, or replace .
1 . If TOP TIER detergent gasoline is not available, one bottle of additive is recommended . Additives
are available from your authorized Kia dealer along with information on how to use them . Do not
mix other additives .
2 . Inspect HSG belt for evidence of cuts, cracks, excessive wear or oil saturation and replace if
necessary . If HSG belt noise occurred, readjust HSG belt tension before replacing .* And, if necessary, adjust, correct, clean, or replace
.
1 . If TOP TIER detergent gasoline is not available, one bottle of additive is recommended . Additives are available from your authorized Kia dealer along
with information on how to use them . Do not mix other additives .
2 . Inspect HSG belt for evidence of cuts, cracks, excessive wear or oil saturation and replace if necessary . If HSG belt noise occurred, readjust HSG belt
tension before replacing .
47*IF EQUIPPED
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPER ATING INFORMATION AND SAFET Y WARNINGS .
37,500 miles
PERFORM:

• Add fuel additive
1

• Rotate tire position
REPLACE:
• Engine oil and filter
INSPECT*:
• Air cleaner filter

• HSG belt
2

• Vacuum hose 45,000 miles
PERFORM:

• Fuel additive
1

• Rotate tire position
REPLACE:
• Climate control air filter (for evaporator and blower unit)

• Engine oil and filter
INSPECT*:
• Air cleaner filter

• Air conditioning refrigerant

• Brake hoses and lines

• Drive shafts and boots

• Exhaust pipe and muffler

• Front brake disc/pads and calipers

• HSG belt
2

• Rear brake disc/pads

• Steering gear box, linkage & boots/lower arm ball joint, upper arm ball joint

• Suspension mounting bolts

• Vacuum hose
Normal Maintenance Schedule (Continued)

MAINTENANCE
* And, if necessary, adjust, correct, clean, or replace .
** If equipped
1 . If TOP TIER detergent gasoline is not available, one bottle of additive is recommended . Additives are available from your authorized Kia dealer along with information on
how to use them . Do not mix other additives .
2 . Fuel filter & fuel tank air filter are considered to be maintenance free but periodic inspection is recommended for this maintenance schedule depends on fuel quality .
If there are some important safety matters like fuel flow restriction, surging, loss of power, hard starting problem etc ., replace the fuel filter immediately regardless of
maintenance schedule and consult an authorized Kia dealer for details .
* And, if necessary, adjust, correct, clean, or replace
.
1 . If TOP TIER detergent gasoline is not available, one bottle of additive is recommended . Additives
are available from your authorized Kia dealer along with information on how to use them . Do not
mix other additives .
2 . Inspect HSG belt for evidence of cuts, cracks, excessive wear or oil saturation and replace if
necessary . If HSG belt noise occurred, readjust HSG belt tension before replacing .
48*IF EQUIPPED OPTIMA PLUG-IN HYBRID FEATURES & FUNCTIONS GUIDE
52,500 miles
PERFORM:

• Add fuel additive
1

• Rotate tire position
REPLACE:
• Engine oil and filter
INSPECT*:
• Air cleaner filter

• HSG belt
2

• Vacuum hose 60,000 miles
PERFORM:

• Add fuel additive
1

• Rotate tire position
REPLACE:
• Air cleaner filter

• Climate control air filter (for evaporator and blower unit)

• Engine oil and filter

• HSG belt
INSPECT*:
• Air conditioning refrigerant

• Brake hoses and lines

• Drive shafts and boots

• Exhaust pipe and muffler

• Front brake disc/pads and calipers

• Rear brake disc/pads

• Steering gear box, linkage & boots/lower
arm ball joint, upper arm ball joint
• Suspension mounting bolts

• Brake fluid

• Fuel cap, fuel lines, fuel hoses and
connections

• Fuel tank air filter**
2

• Parking brake

• Vacuum hose

• Vapor hose and fuel filler cap
Normal Maintenance Schedule (Continued)

Sales Consultant: ______________________________________________________________ Date: ____________________
Sales Manager: ________________________________________________________________ Date: ____________________
Customer: _____________________________________________________________________ Date: ____________________LEGAL DISCLAIMERS
Driving while distracted is dangerous and should be avoided. Drivers should remain attentive to driving and always exercise caution when using the steering-wheel-mounted controls while dri\
ving.
Driving while distracted can result in a loss of vehicle control that may lead to an accident, severe personal injury and death. The driver’s primary responsibility is in the safe and legal operation of a vehicle, and use of any handheld
devices, other equipment or vehicle systems which take the driver’s eyes, attention and focus away from the safe operation of a vehicle or that are not permissible by law should never be used during operation of the vehicle.
Safety Features: No system, no matter how advanced, can compensate for all driver error and/or driving conditions. Always drive responsibly.
Airbags: For maximum protection, always wear your seat belt.
Android Auto: Android Auto is a trademark of Google, Inc.. Android™ is a registered trademark of Google, Inc. Distracted
driving can result in a loss of vehicle control. Never use a handheld device or vehicle system that takes your focus away
from safe vehicle operation. Navigation is for information purposes only, and Kia does not make any warranties about the
accuracy of the information.
Apple CarPlay
®: Apple CarPlay® a registered trademark of Apple Inc. Distracted driving can result in a loss of vehicle
control. Never use a handheld device or vehicle system that takes your focus away from safe vehicle operation.
Navigation is for information purposes only, and Kia does not make any warranties about the accuracy of the information.
Apps: All information contained herein was based upon the latest available information at the time of appstore
registration. Descriptions are believed to be correct, and Kia Motors Corporation (KMC) makes every effort to ensure
accuracy, however, accuracy cannot be guaranteed. From time to time, KMC may need to update or make changes to
the vehicle features and other vehicle information reported in this app. KMC, by the publication and dissemination of this
material, does not create any warranties, either express or implied, to any Kia products. Contact your local Kia dealer for
the most current information.
Autonomous Emergency Braking System (AEB) / Forward Collision Warning System: These systems are not
substitutes for safe driving, and may not detect all objects in front of vehicle. Always drive safely and use caution.
Bluetooth
® Wireless Technology: A compatible Bluetooth® wireless technology-enabled cell phone is required to use
Bluetooth® wireless technology. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG,
Inc. and any use of such marks by Kia is under license. Other trademarks and trade names are those of their respective
owners. A Bluetooth
® enabled cell phone is required to use Bluetooth® wireless technology.
Driver Assist Features - Advanced Smart Cruise Control (ASCC), Rear Parking Assist System, Blind Spot Detection
(BSD) with Lane Change Assist, Rear Cross Traffic Alert (RCTA), Lane Departure Warning System, Rear-Camera
Display: These features are not substitutes for safe driving, and may not detect all objects surrounding vehicle. Always drive
safely and use caution.
Electronic Stability Control, Hill-start Assist Control (HAC): No system, no matter how advanced, can compensate for
all driver error and/or driving conditions. Always drive responsibly.
Engine Start/Stop Button with Smart Key: Always come to a complete stop before turning the engine on or off.
However, if you have an emergency while the vehicle is in motion and must turn the engine off, you can turn the engine
off to the ACC position by pressing the Start/Stop button for more than 3 seconds o\
r 3 times in succession. If the vehicle
is still moving, you can restart the engine by pressing the Start/Stop button with the s\
hift lever in Neutral (N). With the
engine off, power assist for steering and braking will be disabled, and the vehicle will be more difficult to control.
Front Seat Headrest Adjustment: Never attempt to adjust headrests when vehicle is in motion.
Google Play
™ Store is a trademark of Google, Inc. © 2016 Google Inc. All rights reserved. Google and the Google Logo
are registered trademarks of Google Inc.
iPod
®/iPhone® is a registered trademark of Apple Inc. iPod® mobile digital device sold separately, and connectivity
requires the Kia accessory cable.
Navigation: Distracted driving can result in a loss of vehicle control. When operating a vehicle, never use a handheld
device or vehicle system that takes your focus away from safe vehicle operation. Navigation is for information purposes
only, and Kia does not make any warranties about the accuracy of the information.
Occupant Detection System (ODS): Kia vehicles use a number of different ODS types that vary by model.
Pandora® internet radio: Pandora® is a registered trademark of Pandora Media, Inc.
Power Trunk / Smart Trunk: Driving with the trunk open may be unlawful and can draw dangerous exhaust fumes into
your vehicle; if you choose to do so, keep air vents and all windows open for proper ventilation.
Seat adjustments: Reclining the passenger seats can reduce the effectiveness of the safety restraint system and may
lead to additional injury in an accident.
Seat Belts / Airbags: For maximum protection, always wear your seatbelt.
Seat warmers: Use extreme caution when using the seat warmers to avoid burns. Refer to the Owner’s Manual for more
information.
SiriusXM
®: SiriusXM Satellite Radio, SiriusXM Traffic and SiriusXM Travel Link each require a subscription sold
separately, or as a package, by SiriusXM Radio Inc. If you decide to continue your service at the end of your
trial subscription, the plan you choose will automatically renew and bill at then-current r\
ates until you call
1-866-635-2349 to cancel. See SiriusXM Customer Agreement for complete terms at www.siriusxm.com. Other
fees and taxes will apply. All fees and programming are subject to change. Not all vehicles or devices are capable of
receiving all services offered by SiriusXM. Data displays and individual product availability vary by vehicle hardware.
Current information and features may not be available in all locations, or on all receivers. Weather Forecast, Current
Conditions may not be available in all locations. Images above are for representative purposes only and are not real
products. For actual features and images of real products, consult the vehicle manufacturer. SiriusXM is not responsible
for any errors or inaccuracies in the data services or their use in the vehicle. Travel Link Stocks displays current price
and daily delta of around 7,000 actively reported securities traded on t\
he NYSE
®, NASDAQ® and AMEX®. The service is
delayed approximately 20 minutes. SiriusXM satellite service is available only to those at least 18 years of age in the 48
contiguous USA, DC, and Puerto Rico (with coverage limitations). SiriusXM Internet Radio service is available throughout
our satellite service area and in AK and HI. © 2016 SiriusXM Radio Inc. Sirius, XM and all related marks and logos are
trademarks of SiriusXM Radio Inc.
Sportmatic
® is a registered trademark of Kia Motors America.
Steering Wheel Controls: Driving while distracted is dangerous and should be avoided. Remain attentive to driving and
be cautious when using steering-wheel-mounted controls while driving.
Sunvisor: Sunvisor may not shield all direct light. Do not operate the vehicle if Sunvisor is impairing your visibility.
Tilt/Telescoping Steering Wheel: Never attempt to adjust steering wheel position when vehicle is in motion.
TPMS: Even with the Tire-Pressure Monitoring System (TPMS), always check your tire pressure on a regular basis.
UVO eServices: Distracted driving can result in a loss of vehicle control. Never use a handheld device or vehicle system
that takes your focus away from safe vehicle operation.
UVO eServices app: App uses your smartphone data service. Normal cellular service rates will apply.
UVO eServices with Premium Navigation: Distracted driving can result in a loss of vehicle control. Never use a
handheld device or vehicle system that takes your focus away from safe vehicle operation. Navigation is for information
purposes only, and Kia does not make any warranties about the accuracy of the information.

*IF EQUIPPED
© 2016 Kia Motors America, Inc. All rights reserved.Part Number: UP170-PS-004
Consumer - Roadside Assistance: 1-800-333-4KIA (4542)

*IF EQUIPPED
BEFORE DELIVERYOwner

Sales Consultant: ______________________________________________________________ Date: ____________________
Sales Manager: ________________________________________________________________ Date: ____________________
Customer: _____________________________________________________________________ Date: ____________________ Explain first service process and schedule first service appointment Tour Parts & Service departments, introduce staff & explain value of Kia Parts and Service Review recommended maintenance schedule and maintenance requirements to validate warranty Review business hours & Customer 360° Care Review the Kia 10-year/100,000-mile warranty program Ensure 100% satisfaction with sales and delivery process and no problems with the vehicle Confirm time and best contact number for initial dealer follow-up
OPTIMA PLUG-IN HYBRID CUSTOMER DELIVERY CHECKLIST
...continued
KEY FEATURE WALKTHROUGHDURING DELIVERY Tire Pressure Monitoring System ( TPMS) – page 5 Trip Modes / Trip Computer – page 7 Fuel Economy – page 8 ECO Mode (Active ECO) – page 10 Engine Start /Stop Button – page 19 Audio Controls – page 23 Digital Clock – page 30 Seat Warmers/ Ventilated Seats* – page 33
Smart Key – page 37 Panoramic Sunroof Operation* – page 39 Sunvisor – page 40 Back-up Warning System* – page 41 Rear-Camera Display* – page 41 Tire Mobility Kit – page 43 Passenger Airbag Off Indicator – page 44
*IF EQUIPPED
Aux/USB/iPod
® Port – page 30

Cruise Control – page 23 Demonstrate operation
UVO eServices Setup – page 28Walk customer through the registration/activation
process for UVO eServices.
UVO eServices with Premium -
Navigation* – page 29

For further operational information, refer to
the Car Multimedia System User’s Manual.
Bluetooth
® Wireless
Technology – page 24

Demonstrate operation, and pair
customer’s phone.
