2017 JEEP RENEGADE display

NOTE:
•The vehicle must be equipped with an automatic trans-
mission to be equipped with Remote Start.
• Obstructions between the vehicle and key fob may
reduce this range.
Remote Start Cancel Message — If Equipped
The following messages will display in the instrument
cluster if the vehicle fails to remote start or exits remote
start prematurely:
• Remote Start Cancelled — Door Open
• Remote Start Cancelled — Hood Open
• Remote Start Cancelled — Fuel Low
• Remote Start Cancelled — Liftgate Open
• Remote Start Cancelled — Too Cold
• Remote Start Cancelled — Time Expired
• Remote Start Disabled — Start Vehicle To Reset
The message will stay active until the ignition is placed in
the ON/RUN position.
How To Use Remote Start
• Push Remote Start buttonon the key fob twice
within five seconds. Pushing the Remote Start button
a third time shuts the engine off.
• To drive the vehicle, push unlock button, insert the key
in the ignition and turn to the ON/RUN position.
• With remote start, the engine will only run for 15
minutes (timeout) unless the ignition key is placed in the
ON/RUN position.
• The vehicle must be started with the key after two
consecutive timeouts.
All of the following conditions must be met before the
engine will remote start:
• Gear Selector in PARK
• Doors closed
• Hood closed
• Liftgate closed
• Hazard switch off
• Brake switch inactive (brake pedal not pushed)
• Battery at an acceptable charge level
24 GETTING TO KNOW YOUR VEHICLE

the door handles, and disarm the Vehicle Security Alarm (if
equipped). Then, prior to the end of the 15-minute cycle,
push and release the START/STOP button.
NOTE:For vehicles equipped with the Keyless Enter-
N-Go — Passive Entry feature, the message “Remote Start
Active — Push Start Button” will display in the instrument
cluster display until you push the ignition START button.
Remote Start Comfort Systems — If Equipped
When Remote Start is activated, the heated steering wheel
and driver heated seat features will automatically turn on
in cold weather. These features will stay on through the
duration of Remote Start or until the ignition switch is
cycled to the RUN position.
NOTE: The Remote Start Comfort System can be activated
and deactivated through the Uconnect Settings. For more
information on Remote Start Comfort System operation,
refer to “Uconnect Settings” in “Multimedia.”
Remote Start Windshield Wiper De–Icer Activation
— If Equipped
When remote start is active and the outside ambient
temperature is less than 40°F (4.4°C), the Windshield Wiper
De-Icer will be enabled. Exiting remote start will resume previous operation, except if the Windshield Wiper De-Icer
is active. The Windshield Wiper De-Icer timer and opera-
tion will continue.
General Information
The following regulatory statement applies to all Radio
Frequency (RF) devices equipped in this vehicle:
This device complies with Part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, in-
cluding interference that may cause undesired opera-
tion.
NOTE: Changes or modifications not expressly approved
by the party responsible for compliance could void the
user ’s authority to operate the equipment.
SENTRY KEY
The Sentry Key Immobilizer system prevents unauthorized
vehicle operation by disabling the engine. The system does
not need to be armed or activated. Operation is automatic,
regardless of whether the vehicle is locked or unlocked.
26 GETTING TO KNOW YOUR VEHICLE

To Unlock/Enter The Liftgate
The liftgate Passive Entry unlock feature is built into the
electronic liftgate release. With a valid Passive Entry key
fob within 5 ft (1.5 m) of the liftgate, push the Electronic
Liftgate release to open with one fluid motion.
To Lock The Liftgate
With a valid Passive Entry key fob within 5ft (1.5 m) of the
liftgate, push the Passive Entry lock button located to the
right of electronic liftgate release.
NOTE:
•The liftgate Passive Entry lock button will lock the
liftgate and the doors. The liftgate unlock feature is built
into the Electronic Liftgate release.
• If “Unlock All Doors 1st Press” is programmed in the
instrument cluster display, if equipped, only the liftgate
will unlock when you push the Electronic Release. If
Unlock Driver Door 1st Press is programmed in
Uconnect, the liftgate will unlock when you push the
electronic unlock/lock button on the liftgate. For further
information, refer to “Uconnect Touch Settings” in
“Multimedia.” Emergency Unlocking Driver Door
If the key fob battery is low or dead, the emergency key can
be used to unlock the driver side door lock cylinder.
To release the emergency key, proceed as follows:
1. Slide the emergency key release button to the side.
Liftgate Release/Passive Entry
1 — Electronic Liftgate Release
2 — Liftgate Passive Lock Location
3
GETTING TO KNOW YOUR VEHICLE 35

WARNING!(Continued)
•Seats should be adjusted before fastening the seat
belts and while the vehicle is parked. Serious injury
or death could result from a poorly adjusted seat belt.
• Do not ride with the seatback reclined so that the
shoulder belt is no longer resting against your chest.
In a collision you could slide under the seat belt,
which could result in serious injury or death.
CAUTION!
Do not place any article under a power seat or impede
its ability to move as it may cause damage to the seat
controls. Seat travel may become limited if movement
is stopped by an obstruction in the seat’s path.
Power Lumbar Adjustment— If Equipped
Push the switch forward or rearward to increase or de-
crease the lumbar support. Push the switch upward or
downward to raise or lower the lumbar support. NOTE:
Power seat adjustments are only allowed when the
ignition device is turned to ON, and for about 30 minutes
after it is turned to OFF. The seats can also be moved after
opening/closing the doors for about 30 minutes, locking or
unlocking the doors, or switching on of the front courtesy
lights.
Heated Seats — If Equipped
The heated seat switches are located on the instrument
panel.
You can choose between two heating levels:
• Push the heated seat button
once to turn the HI
setting on.
• Push the heated seat buttona second time to turn
the LO setting on.
• Push the heated seat buttona third time to turn the
heating elements off.
If the HI-level setting is selected, the system will automati-
cally switch to LO-level after approximately 145 minutes of
continuous operation. At that time, the display will change
from HI to LO, indicating the change. The LO-level setting
will turn off automatically after approximately 60 minutes.
3
GETTING TO KNOW YOUR VEHICLE 41

NOTE:The headlights must be on for the high beams to
activate.
Flash-To-Pass
You can signal another vehicle with your headlights by
lightly pulling the multifunction lever toward you. This
will cause the headlights to turn on at high beam and
remain on until the lever is released.
Automatic Lighting — If Equipped
Turn the headlight switch to the AUTO position.
When the automatic headlights are enabled, the headlight
time delay is active. After the ignition is placed in the OFF
position, the headlights will automatically turn off after the
time is set by Uconnect Settings.
Refer to “Headlight Delay” in this section for more infor-
mation.
NOTE: The engine must be running before the headlights
will come on in the automatic mode.
Light Sensor
The light sensor is equipped with an infrared LED, located
on the windshield. It detects changes in light intensity
outside the vehicle, based on the sensitivity of light set by
using the menu on the display or on the Uconnect system.
The higher the sensitivity, the lesser the amount of external
light required for controlling the lighting.
High Beam And Turn Signal Controls
3
GETTING TO KNOW YOUR VEHICLE 53

IconDescription
MAX Defrost Button
Push the MAX Defrost button to change the current airflow setting to Defrost mode. The indica-
tor illuminates when this feature is on. Performing this function will cause the automatic climate
controls to change to manual mode. The blower speed increases to full (all LEDs on) when
MAX Defrost mode is selected, the air conditioning compressor is turned on (LED on), both
driver and passenger temperature controls are set to (HI), defrost mode is selected (LED on),
rear defroster is turned on (LED on) and the air recirculation is turned off (LED off). If the MAX
Defrost mode is turned off, the climate system will return to the previous setting.
Rear Defrost Button
Push the Rear Defrost button to turn on the rear window defroster and the heated outside mir-
rors (if equipped). An indicator will illuminate when the rear window defroster is on. The rear
window defroster automatically turns OFF after 20 minutes.
Passenger Temperature Knob
Provides the passenger with independent temperature control. Rotate the adjustment knob to set
desired temperature shown in the Temperature Display. The set temperature is shown on the
display. Turning the control knob completely in one direction or the other activates the HI
(maximum heating) or LO (maximum cooling) functions shown in the display, respectively. To
deactivate these functions, turn the temperature knob to the desired temperature.
NOTE:Rotating the Passenger Temperature Control knob while in Sync mode will automati-
cally exit Sync.
74 GETTING TO KNOW YOUR VEHICLE

IconDescription
Bi-Level Mode
Bi-Level Mode
Bi-Level Mode is obtained by pressing both the Panel Mode button and the Floor Mode button,
activating them both. Air comes from the instrument panel outlets and floor outlets. A slight
amount of air is directed through the defrost and side window demister outlets.
NOTE: Bi-Level Mode is designed under comfort conditions to provide cooler air out of the
panel outlets and warmer air from the floor outlets.
Mix Mode
Mix Mode
Mix Mode is obtained by pressing both the Windshield Mode button and the Floor Mode but-
ton, activating them both. Air is directed through the floor, defrost, and side window demister
outlets. This setting works best in cold or snowy conditions that require extra heat to the wind-
shield. This setting is good for maintaining comfort while reducing moisture on the windshield.
Climate Control Power Button
Press and release this button to turn the Climate Control on/off.
Driver Temperature Knob
Provides the driver with independent temperature control. Rotate the adjustment knob to set
desired temperature shown in the Temperature Display. Rotate fully counterclockwise for maxi-
mum A/C (LO). The set temperature is shown on the display. Turning the control knob com-
pletely in one direction or the other activates the HI (maximum heating) or LO (maximum cool-
ing) functions shown in the display, respectively. To deactivate these functions, turn the
temperature knob to the desired temperature.
76 GETTING TO KNOW YOUR VEHICLE

CAUTION!
Failure to follow these cautions can cause damage to
the heating elements:
•Use care when washing the inside of the rear win-
dow. Do not use abrasive window cleaners on the
interior surface of the window. Use a soft cloth and a
mild washing solution, wiping parallel to the heat-
ing elements. Labels can be peeled off after soaking
with warm water.
• Do not use scrapers, sharp instruments, or abrasive
window cleaners on the interior surface of the win-
dow.
• Keep all objects a safe distance from the window.
Climate Control System Compressor
Push the A/C Control button to activate/deactivate the
compressor (activation is indicated by the LED on the
button turning on).
The system remembers that the compressor has been
turned off, even after the engine has stopped.
Pushing the A/C button will stop AUTO MODE (AUTO
LED will turn off). To restore automatic control of compres-
sor, push the AUTO button again. NOTE:
With the compressor off, air cannot be introduced
to the passenger compartment with a temperature lower
than the outside temperature. Under certain environmental
conditions, windows could fog rapidly since the air is not
dehumidified.
MAX A/C
MAX A/C sets the system for maximum cooling perfor-
mance.
Rotate the driver temperature control adjust knob counter-
clockwise for MAX A/C. Both driver and passenger tem-
perature displays will show MAX A/C LO.
In MAX A/C, the blower speed and mode position can be
adjusted to desired user settings. Pressing other settings
will cause the MAX A/C operation to switch to the selected
setting and MAX A/C to exit.
Rapid Window Demisting (MAX-Defrost Function)
Push the MAX-defrost button to activate (LED on) the
windshield and side window demisting function.
The Climate Control system carries out the following
operations:
• Turns on the air conditioning compressor when environ-
mental conditions are suitable.
3
GETTING TO KNOW YOUR VEHICLE 77
