Vehicle Security Indicator Light
Yellow TelltaleLight What It Means
Vehicle Security Indicator Light
This indicator will illuminate when the vehicle security alarm system has detected an attempt
was made to break into the vehicle.
Wait To Start Light — If Equipped
Yellow Telltale
Light What It Means
Wait To Start Light
The “Wait To Start” telltale will illuminate for approximately two seconds when the ignition is
turned to the RUN position. It’s duration may be longer based on colder operating conditions.
Vehicle will not initiate start until telltale is no longer displayed. Refer to “Starting Procedures”
in “Starting And Operating” for further information.
NOTE:
The “Wait To Start” telltale may not illuminate if the intake manifold temperature is
warm enough.
158 GETTING TO KNOW YOUR INSTRUMENT PANEL
Set Speed Warning Light — If Equipped
White WarningLight What It Means
Set Speed Warning Light
When Set Speed Warning is turned on the speed warning telltale will illuminate in the instru-
ment cluster, with a number matching the set speed. Each time the set speed is exceeded, an au-
dible chime will sound for up to 10 seconds, or until the speed is no longer exceeded. The telltale
in the instrument cluster will also change from white to yellow, and a pop up warning message
will pop up on the instrument cluster display screen. Speed Warning can be turned on and off in
the instrument cluster display, for further information refer to “Instrument Cluster Display Menu
Items” in “Getting To Know Your Instrument Panel.”
NOTE:
The number “120” is only an example of a speed that can be set.
Gray Telltale Lights
Cruise Control Cancelled Light
White Telltale
Light What It Means
Cruise Control Cancelled Light
This light will turn on when the cruise control has been cancelled by the driver. Refer to “Speed
Control — If Equipped” in “Starting and Operating” for further information.
4
GETTING TO KNOW YOUR INSTRUMENT PANEL 163
Full Off – Four-Wheel Drive Vehicles In 4WD High And
4WD Low Range
The “Full Off” mode is intended for off-highway and
off-road use when ESC stability features could inhibit
vehicle maneuverability due to trail conditions. The “ESC
Off” button is located in the lower switch bank above the
climate control panel. To enter “Full Off” mode, push and
hold the “ESC Off” button for five seconds while the
vehicle is stopped with the engine running. After five
seconds, the ESC Off indicator light will illuminate and an
“ESC Off” message will appear in the odometer.
In this mode, ESC and TCS are turned off (except for the
“limited slip” feature described in the TCS section) until
the vehicle reaches a speed of 40 mph (64 km/h). At speeds
over 40 mph (64 km/h), the system automatically switches
to “Partial Off” mode, described above. When the vehicle
speed returns to less than 35 mph (56 km/h), the ESC
system will return to “Full Off” mode. The ESC OFF
indicator light is always illuminated when ESC is off. To
turn ESC on again, momentarily push the “ESC Off”
button. This will restore the normal “ESC On” mode of
operation.NOTE:
With the ESC switched off, the enhanced vehicle
stability offered by ESC is unavailable. In an emergency
evasive maneuver, the ESC system will not engage to assist
in maintaining stability. “Full Off” mode is only intended
for off-highway or off-road use.
NOTE:
• “Full Off” is the only operating mode for ESC in 4WD
LOW range. The ESC system will be in this mode
whenever the vehicle is started in 4WD LOW range or
the power transfer unit is shifted into 4WD LOW range.
• The “ESC OFF” message will display and a chime will
sound when the gear selector is moved from any posi-
tion to the PARK position and then moved out of the
PARK position. This will occur even if the message was
cleared previously.
Selec-Terrain — If Equipped
On models equipped with Selec-Terrain, the activation of
some driving modes provide partial off or full off of some
active safety systems in order to optimize performance in
specific modes.
Partial or full off of the active safety systems will be
indicated by a light in the instrument cluster.
5
SAFETY 175
Modes Of Operation
Three selectable modes of operation are available in the
Uconnect System. Refer to “Uconnect Settings” in “Multi-
media” for further information.
Blind Spot Alert Lights Only
When operating in Blind Spot Alert mode, the BSM system
will provide a visual alert in the appropriate side view
mirror based on a detected object. However, when the
system is operating in Rear Cross Path (RCP) mode, the
system will respond with both visual and audible alerts
when a detected object is present. Whenever an audible
alert is requested, the radio is muted.
Blind Spot Alert Lights/Chime
When operating in Blind Spot Alert Lights/Chime mode,
the BSM system will provide a visual alert in the appro-
priate side view mirror based on a detected object. If the
turn signal is then activated, and it corresponds to an alert
present on that side of the vehicle, an audible chime will
also be sounded. Whenever a turn signal and detected
object are present on the same side at the same time, both
the visual and audible alerts will be issued. In addition to
the audible alert, the radio (if on) will also be muted.NOTE:
Whenever an audible alert is requested by the BSM
system, the radio is also muted.
When the system is in RCP, the system will respond with
both visual and audible alerts when a detected object is
present. Whenever an audible alert is requested, the radio
is also muted. Turn/hazard signal status is ignored; the
RCP state always requests the chime.
Blind Spot Alert Off
When the BSM system is turned off, there will be a related
message on instrument cluster display. If BSM system is
off, this message will be visualized every time the vehicle
is restarted.
NOTE: The BSM system will store the current operating
mode when the vehicle is shut off. Each time the vehicle is
started the previously stored mode will be recalled and
used.
Blind Spot Monitoring Fault Warnings
Sensor Blinded
In the case of a sensor blinded:
• BSM Mirror Warning Lights are turned on continuously.
• A instrument cluster dedicated message will display.
5
SAFETY 187
NOTE:The rear bumper must be clean and free of any
obstructing debris.
System Not Available
In the case of the system being temporary unavailable:
• BSM Mirror Warning Lights are turned on continuously.
• A instrument cluster dedicated message will display.
In the case of the system being completely unavailable:
• A chime will turn on.
• A instrument cluster dedicated message will display.
NOTE: Vehicle must be taken to the nearest authorized
dealer for service.
General Information
This vehicle has systems that operate on radio frequency
that comply with Part 15 of the Federal Communications
Commission (FCC) rules and with Industry Canada Stan-
dards RSS- GEN/210/220/310.
Operation is subject to the following two conditions:
1. The device may not cause harmful interference. 2. The device must accept any interference received, in-
cluding interference that may cause undesired operation
of the device.
Changes or modifications to any of these systems by other
than an authorized service facility could void authorization
to use this equipment.
Forward Collision Warning (FCW) With Mitigation
Operation — If Equipped
The Forward Collision Warning (FCW) System with Miti-
gation provides the driver with audible warnings, visual
warnings (within the instrument cluster display), and may
apply a brake jerk to warn the driver when it detects a
potential frontal collision. The warnings and limited brak-
ing are intended to provide the driver with enough time to
react, avoid or mitigate the potential collision.
188 SAFETY
•Changing the FCW status to “Only warning” prevents
the system from providing limited active braking, or
additional brake support if the driver is not braking
adequately in the event of a potential frontal collision,
but maintains the audible and visual warnings.
Changing the status of the system is only possible with the
vehicle at a complete stop.
NOTE: The FCW system state is not kept in memory from
one ignition position to the next. If the system is turned off,
it will turn on when the vehicle is restarted.
Changing FCW Sensitivity
By changing the settings on the menu of the Uconnect
system, you can change the sensitivity of the system by
choosing one of the following three options: Near,Me-
dium orFar. Refer to “Uconnect Settings” in “Multime-
dia” for further information.
The default option is Medium. This setting provides that
the system notify the driver of a possible accident with the
vehicle ahead of it when the latter is at a standard distance,
intermediate between the other two possible settings.
By setting the sensitivity of the system to Far, the system
will warn the driver of a possible accident with the vehicle
in front when the latter is at a greater distance, giving you the chance to act on the brakes in a more limited and
gradual. This setting gives the driver the maximum pos-
sible time of reaction to prevent a possible accident.
By changing the option to
Near, the system will warn the
driver of a possible accident with the vehicle ahead of it
when the latter is a reduced distance. This setting offers a
reaction time to the driver lower than the settings Me-
dium andFar, in the case of a potential accident, while a
more dynamic driving of the vehicle.
The setting of the sensitivity of the system is maintained in
memory when the engine is switched off.FCW Limited Warning
If the instrument cluster display reads “FCW Limited
Functionality” or “FCW Limited Functionality Wipe Front
Windshield” momentarily, there may be a condition that
limits FCW functionality. Although the vehicle is still
drivable under normal conditions, the active braking may
not be fully available. Once the condition that limited the
system performance is no longer present, the system will
return to its full performance state. If the problem persists,
see your authorized dealer.
5
SAFETY 191
Service FCW Warning
If the system turns off, and the instrument cluster display
reads:
•FCW Unavailable Service Required
This indicates there is an internal system fault. Although
the vehicle is still drivable under normal conditions, have
the system checked by an authorized dealer.
“Wipe Front Radar Sensor In Front Of Vehicle” Warning
The “FCW Front Radar Sensor Temporarily Blocked”
warning will display when conditions temporarily limit
system performance. This most often occurs at times of
poor visibility, such as in snow or heavy rain. The system
may also become temporarily blinded due to obstructions,
such as mud, dirt or ice. In these cases, the instrument
cluster display will read “FCW Front Radar Sensor Tem-
porarily Blocked” and the system will deactivate.
The “FCW Front Radar Sensor Temporarily Blocked” mes-
sage can sometimes be displayed while driving in highly
reflective areas (i.e. tunnels with reflective tiles, or ice and
snow). The system will recover after the vehicle has left
these areas. Under rare conditions, when the radar is not
tracking any vehicles or objects in its path this warning
may temporarily occur. If weather conditions are not a factor, the driver should
examine the sensor. It may require cleaning or removal of
an obstruction. The sensor is located behind the lower
grille. In absence of visible obstructions on the bumper, it
could be necessary to wipe off the radar directly on the
surface, after having the radar cover removed. It’s recom-
mended that your authorized dealer perform this opera-
tion.
NOTE:
•
If the “FCW Front Radar Sensor Temporarily Blocked”
message occurs frequently (e.g. more than once on every
trip) without any snow, rain, mud, or other obstruction,
have the radar sensor realigned at your authorized
dealer.
• Installing a snow plow, front-end protector, an aftermar-
ket grille or modifying the grille is not recommended.
Doing so may block the sensor and inhibit FCW opera-
tion.
192 SAFETY
Base System
The Tire Pressure Monitor System (TPMS) uses wireless
technology with wheel rim mounted electronic sensors to
monitor tire pressure levels. Sensors, mounted to each
wheel as part of the valve stem, transmit tire pressure
readings to the receiver module.
NOTE:It is particularly important for you to check the tire
pressure in all of the tires on your vehicle monthly and to
maintain the proper pressure.
The TPMS consists of the following components:
• Receiver Module.
• Four Tire Pressure Monitoring Sensors.
• Tire Pressure Monitoring Telltale Light.
Tire Pressure Monitoring Low Pressure Warnings
The “Tire Pressure Monitoring Telltale Light” will
illuminate in the instrument cluster, a “LOW TIRE
PRESSURE” message will display in the instrument cluster,
an Inflate to XX message will be displayed and a chime
will sound when tire pressure is low in one or more of the
four active road tires. Should this occur, you should stop as
soon as possible, check the inflation pressure of each tire on your vehicle, and inflate each tire to the vehicle’s recom-
mended cold placard pressure value as shown in the
Inflate to XX
message. Once the system receives the
updated tire pressures, the system will automatically up-
date and the “Tire Pressure Monitoring Telltale Light” will
turn off.
NOTE: When filling warm tires, the tire pressure may need
to be increased up to an additional 4 psi (30 kPa) above the
recommended cold placard pressure in order to turn the
Tire Pressure Monitoring Telltale Light off. The vehicle may
need to be driven for up to 20 minutes above 15.5 mph
(25 km/h) in order for the TPMS to receive this informa-
tion.
Service TPMS Warning
When a system fault is detected, the “Tire Pressure Moni-
toring Telltale Light” will flash on and off for 75 seconds
and then remain on solid. The system fault will also sound
a chime. If the ignition is cycled, this sequence will repeat,
providing the system fault still exists. The “Tire Pressure
Monitoring Telltale Light” will turn off when the fault
condition no longer exists. A system fault can occur due to
any of the following:
198 SAFETY
