2017 INFINITI QX30 Quick Reference Guide

14
Mobile Apps are a limited selection of popular smartphone-based apps
that have been customized for in-vehicle use. Mobile Apps can be
accessed by connecting your compatible smartphone to the vehicle.
•

To use Mobile Apps, the Infiniti InTouch™ Apps must be installed
and running on the compatible smartphone. This app can be
downloaded from the application store.
•


Mobile Apps also require an active subscription and valid Infiniti
Owner Portal account.
INFINITI INTOUCH
™ MOBILE APPS ENROLLMENT AND ACTIVATION
1.


Create Infiniti Owner Portal account.

(http://owners.infinitiusa.com/iowners/)
2.


From within your Infiniti Owner Portal account, enroll in Infiniti
InTouch Mobile Apps.
3.


Download the Infiniti InTouch companion app from the App store
and login using your Infiniti Owner Portal ID and Password.
4.


Connect your Android device by Bluetooth® and your Apple device
by USB cable to your vehicle.
Infiniti InTouch™ Mobile Apps
(if so equipped)
If you have a compatible Bluetooth® device with streaming audio (A2DP and AVRCP
profiles), you can set up a wireless connection between your Bluetooth® device and
the in-vehicle audio system, enabling you to listen to the audio from yo\
ur device
through the vehicle’s audio system.
After connecting your Bluetooth
® device, press the MEDIA button on the control
panel to switch to Bluetooth® Streaming Audio.
Bluetooth® Streaming Audio
Connecting your Cellular Phone or
Device via Bluetooth
®,1,2
Using Bluetooth® technology, you can connect
(pair) your cellular phone with the in-vehicle
system for hands-free use of your cellular phone
3.
1.


Press the

MENU button on the
Infiniti controller.
2.


Touch the “Settings” key on the


center display.
3

.



Touch the “Phone/Mail” key.
4.


Touch “Connect Device”.
5.


Touch “Add New (X/ 5
Free)”.
6.


When a PIN appears on the screen, operate
the Bluetooth® device to enter/confirm
the PIN.
1,2,3 For disclaimer, refer to page 18 of this guide.
For more information, refer to your Owner

15
Infiniti InTouch™ Services4 (if so equipped)
Infiniti InTouch ™ Services combine personalized convenience settings and personal
security features to compliment the Total Ownership Experience®. For more details on
Infiniti InTouch Services or to enroll your vehicle, please visit usa.infinitiintouch.com or call
1-855-444-7244. Available services include, but are not limited to: •
Automatic Collision Notification
•

Alarm Notification
•

Maintenance Alert
•


Scheduled Maintenance Notification
•


Report Stolen Vehicle
•

Emergency Call
•


Enhanced Roadside Assistance
•

My Schedule
•

Destination Assistance
•

Destination Send-to-Vehicle
•

Connected Search
•

Drive Zone
•


Maximum Speed Alert
•


Mobile Information Service
•

Valet Alert
INFINITI INTOUCH SERVICES ENROLLMENT
1.


Create Infiniti Owner Portal account.

(https://owners.infinitiusa.com/iowners/)
2.


From within your Infiniti Owner Portal account,
enroll in Infiniti InTouch Services.
3.


Download the Infiniti InTouch Services companion
app from the App store and login using your Infiniti
Owner Portal ID and Password.
To access Infiniti InTouch Services:

1 Press the MENU button on the Infiniti controller.
2 Select the “Information” key on the display.
3 Select the “InTouch Services” key on the display.
1
2 3
In case of an emergency, press
and release the SOS button lid
4, located above the rearview
mirror and press the in-vehicle
telematics SOS button
5.

4 5
4 For disclaimer, refer to page 18 of this guide.
For more information, refer to your Owner

16
Navigation System (if so equipped)
Use the Infiniti controller 1 and OK button 2 to navigate
through the center display screens.
•


Press the
button 3 to return to the previous screen.
•


Press the MAP/VOICE button
4 to display the map.
SETTING A ROUTE
To set a route, first ensure that the correct region is selected
on the touch-screen.
1.


Press the

MENU button
5 on the Infiniti controller.
2.


Touch the “Navigation” key on the display.
3.


Touch the “Destination Menu” key 6 on the display.
4.


Select the preferred destination setting method.
5.


Enter the address number, street name, and city as
prompted by the screen.
CANCELING A ROUTE
1.


Press

the MENU button
5 on the Infiniti controller.
2.


Touch the “Navigation” key on the display.
3.


Touch the “Cancel Route” key 7.

4
5
1
2
3
6
7
For more information, refer to your Owner

17
Cruise Control
CONVENTIONAL CRUISE CONTROL
Cruise control maintains a constant set speed for you. The system is ope\
rational only at speeds
above 19 mph (30 km/h).
1 Pull the lever toward you to recall the previous speed.
2 Lift the lever upward up to the pressure point and release the lever to increase the speed by 1
mph (1.6 km/h).
3 Push the lever downward up to the pressure point and release the lever t\
o decrease the speed by
1 mph (1.6 km/h).
4 Lift the lever upward beyond the pressure point and release the lever to increase the speed to
the nearest multiple of 5 mph (8 km/h).
5 Push the lever downward beyond the pressure point and release the lev er to decrease the speed
to the nearest multiple of 5 mph (8 km/h).
To override the current stored speed with your current real speed, quick\
ly move the stalk
up
4 or down 5 .
To deactivate cruise control, push the lever
6 away from you or push the brake pedal.
INTELLIGENT CRUISE CONTROL (ICC) (IF SO EQUIPPED)
The ICC system is designed to maintain a selected distance from the vehi\
cle in front of you and
reduce the speed to match a slower vehicle ahead.
To increase the distance to the vehicle ahead to be maintained by the IC\
C system, turn the knob
7
clockwise. To reduce the distance, turn the knob counterclockwise.
4
2
3
5
7
6
1
Cruise Control Stalk
For more information, refer to your Owner

18
1 Availability of specific features is dependent upon the phone’s Bluet\
ooth® support. Please refer to your phone owner’s manual for details. Blue\
tooth® word mark and logos are owned by Bluetooth SIG, Inc.
2 Some jurisdictions prohibit the use of cellular telephones while driving\
.
Compatible smartphone required. Text rates and/or data usage may apply.
3 Laws in some jurisdictions may restrict the use of “Text-to-Speech”\
. Some of the applications and features, such as social networking and t\
exting, may also be restricted. Check local regulations for any
requirements before using these features.
4 Driving is serious business. Only use Infiniti InTouch Services and Infi\
niti InTouch Services Premier when safe to do so. Never program while dr\
iving. GPS mapping may not be detailed in all areas or reflect
current road status. Services, including automatic crash notification an\
d SOS, require an active subscription, and are dependent upon the telema\
tics device being in an operative condition, its ability to co nnect
to a wireless network, compatible wireless network availability, navigat\
ion map data, and GPS satellite signal receptions, the absence of which \
can limit or prevent the ability to reach Infiniti InTouch Ser vices
Customer Care or receive support. Services require compatible 3G GSM/GPR\
S cellular network provided by AT&T. 3G cellular network not available i\
n all areas and/or available at all times. Cellular technol ogy
is evolving, and changes to cellular networks provided by independent co\
mpanies are not within Infiniti’s or Sirius XM Connected Vehicle Serv\
ice’s Inc.’s control. Certain vehicle services, including Googl e
®
compatible services, provided by independent companies are not within In\
finiti’s or SiriusXM’s control and are subject to change without n\
otice or liability to Infiniti, its affiliates and agents or SiriusXM. Like
other devices that rely on network coverage, once the network service is\
discontinued, Infiniti InTouch services will not function unless equipm\
ent replacements, upgrades, or alternative network coverage are
available at that time, which neither Infiniti nor Sirius XM can guarant\
ee. Infiniti and Sirius XM are not responsible for associated costs that\
may be required for continued operation due to cellular netwo rk
turndown or discontinuation (including equipment upgrades, if available\
, or roaming charges on alternative networks). 6 month trial subscripti\
on begins on your date of purchase or lease of your new Infiniti.
Subsequently, your credit card (if on file) will be charged at the the\
n current subscription rate and your service will renew automatically un\
der the terms of your subscription. Standard text rates and/or da ta
usage may apply. Terms and Conditions of Subscription Agreement apply. S\
ee www.infinitiusa.com/intouch for more information.
Disclaimers
For more information, refer to your Owner

Memo

Memo

Printing June 2016 (01)
QR17EA 0H15U0 • Printed in USA
To view detailed instructional videos, go to
www.infinitiownersinfo.mobi/2017/qx30 or snap this barcode with an appropriate barcode reader.
I N SPIRED PER F O R MAN C E
This Quick Reference Guide is intended to provide an overview of some of
the unique features of your new vehicle. Please see your Owner’s Manu\
al for
important safety information and system operation limitations. Features \
and
equipment in your vehicle may vary depending on model, trim level, optio\
ns
selected, order, date of production, region or availability. Therefore, \
you
may find information about features or equipment that are not included o\
r
installed on your vehicle.
All information, specifications and illustrations in this Quick Referenc\
e Guide
are those in effect at the time of printing. INFINITI reserves the right to change
specifications, performance, design or component suppliers without notice
and without obligation. From time to time, INFINITI may update or revise\
this
Quick Reference Guide to provide owners with the most accurate informati\
on
currently available. Please carefully read and retain, with this Quick
Reference Guide, all revision updates sent to you by INFINITI to ensure \
you
have access to accurate and up-to-date information regarding your vehicl\
e.
Current versions of vehicle Quick Reference Guides, Owner’s Manuals a\
nd
any updates can also be found in the Owner section of the INFINITI website
at https://owners.infinitiusa.com/iowners/navigation/manualsAndGuides.
If you have questions concerning any information in your Owner’s Manual,
contact INFINITI Client Support (see contact information listed above)\
.
