2017 FIAT DUCATO BASE CAMPER Owner handbook (in English)

VersionF.C.(*)Consumption
Urban Extra-urban Combined
Maxi M1 2150 6.3 5.2 5.6
Light M1 2270 (I) 6.6 5.3 5.8
Maxi M1 2270 (I) 6.6 5.3 5.8
(*) Flywheel class
247

2.3 130 Multijet 2
VersionF.C.(*)Consumption
Urban Extra-urban Combined
Light 1700 5.6 5.2 5.3
Maxi 1700 5.8 5.2 5.4
Tempo Libero 1700 5.8 5.2 5.4
Light 1810 5.9 5.3 5.5
Maxi 1810 6.1 5.3 5.6
Tempo Libero 1810 6.1 5.3 5.6
Light 1930 6.3 5.4 5.7
Maxi 1930 6.4 5.5 5.8
Tempo Libero 1930 6.4 5.5 5.8
Light 2040 6.5 5.6 5.9
Maxi 2040 6.7 5.6 6.0
Tempo Libero 2040 6.7 5.6 6.0
Light 2150 6.8 5.7 6.1
Maxi 2150 7.0 5.7 6.2
Tempo Libero 2150 7.0 5.7 6.2
Light
-
Maxi
-
Tempo Libero2270 (I) 7.2 5.8 6.3
(*) Flywheel class
248
TECHNICAL DATA

2.3 130 Multijet 2 with Adblue
VersionF.C.(*)Consumption
Urban Extra-urban Combined
Light 2040 6.9 5.4 6.0
Light 2150 7.0 5.5 6.1
Maxi 2150 7.2 5.5 6.1
Light 2270 7.2 5.7 6.3
Maxi 2270 7.6 5.8 6.5
(*) Flywheel class
249

2.3 150 Multijet 2 / 180 Multijet 2 Power
VersionF.C.(*)Consumption
Urban Extra-urban Combined
Light 1700 6.3 5.4 5.7
Maxi 1700 6.4 5.4 5.8
Tempo Libero 1700 6.4 5.4 5.8
Light 1810 6.5 5.5 5.9
Maxi 1810 6.7 5.5 5.9
Tempo Libero 1810 6.7 5.5 5.9
Light 1930 6.9 5.6 6.1
Maxi 1930 7.0 5.7 6.2
Tempo Libero 1930 7.0 5.7 6.2
Light 2040 7.1 5.8 6.3
Maxi 2040 7.3 5.8 6.4
Tempo Libero 2040 7.3 5.8 6.4
Light 2150 7.4 5.9 6.5
Maxi 2150 7.7 5.9 6.6
Tempo Libero 2150 7.7 5.9 6.6
Light
-
Maxi
-
Tempo Libero2270 (I) 7.8 6.0 6.7
2270 (II) 7.9 6.0 6.7
2270 (III) 7.9 6.0 6.7
(*) Flywheel class
250
TECHNICAL DATA

3.0 140 Natural Power
Consumption according to the current European directive
VersionF.C.(*)Methane (m3x100 km)
Methane (kg/100 km)(**)
Urban Extra-urban Combined Urban Extra-urban Combined
Light –
16.3 11.2 13.1 10.6 7.3 8.6 Maxi –
Tempo Libero –
(*) Flywheel class
(**) Consumption in kg x 100 km according to molecular weight calculation
251

CO2EMISSIONS
The CO2emission figures in the table below refer to combined fuel consumption.
These emission values refer to basic vehicles without optionals.
CO
2emissions (according to the European Directive in force g/100 km)
2.0 115 Multijet 2
Version
F.C.(*)CO2emissions
Combined
Light / Tempo libero 1700 147
Light / Tempo libero 1810 152
Light / Tempo libero 1930 152
Light / Tempo libero 2040 162
Light / Tempo libero 2150 167
(*) Flywheel class
252
TECHNICAL DATA

2.3 150 ECOJET
VersionF.C.(*)CO2emissions
Combined
Light 1700 141
Maxi 1700 143
Tempo Libero 1700 143
Light 1810 146
Maxi 1810 148
Tempo Libero 1810 148
Light 1930 151
Maxi 1930 153
Tempo Libero 1930 153
Light 2040 156
Maxi 2040 158
Tempo Libero 2040 158
Light 2150 161
Maxi 2150 163
Tempo Libero 2150 163
Light
-
Maxi
-
Tempo Libero2270 (I) 166
2270 (II) 168
2270 (III) 168
Light M1 2040 144
Light M1 2150 147
(*) Flywheel class
253

VersionF.C.(*)CO2emissions
Combined
Maxi M1 2150 148
Light M1 2270 (I) 152
Maxi M1 2270 (I) 153
(*) Flywheel class
254
TECHNICAL DATA
