2017 DODGE DURANGO steering

▫Windshield Washer Operation ..............145
▫ Mist ............................... .146
▫ Rain Sensing Wipers — If Equipped .........146
 TILT/TELESCOPING STEERING COLUMN .....147
 POWER TILT/TELESCOPING STEERING COLUMN
— IF EQUIPPED ....................... .148
 HEATED STEERING WHEEL — IF EQUIPPED . .149
 ELECTRONIC SPEED CONTROL — IF
EQUIPPED ........................... .150
▫ To Activate .......................... .150
▫ To Set A Desired Speed ..................151
▫ To Deactivate ........................ .151
▫ To Resume Speed ..................... .151
▫ To Vary The Speed Setting ................151
▫ To Accelerate For Passing .................152
 ADAPTIVE CRUISE CONTROL (ACC) —
IF EQUIPPED ......................... .153
▫ Adaptive Cruise Control (ACC) Operation .....155▫
Activating Adaptive Cruise Control (ACC) .....155
▫ To Activate/Deactivate ...................156
▫ To Set A Desired ACC Speed ...............157
▫ To Cancel ........................... .158
▫ ToTurnOff.......................... .158
▫ To Resume .......................... .158
▫ To Vary The Speed Setting ................159
▫ Setting The Following Distance In ACC .......161
▫ Overtake Aid ......................... .163
▫ ACC Operation At Stop ..................164
▫ Adaptive Cruise Control (ACC) Menu ........164
▫ Display

Warnings And Maintenance .........165
▫ Precautions While Driving With ACC .........167
▫ General Information .....................171
▫ Normal (Fixed Speed) Electronic Speed Control
Mode .............................. .171
 FORWARD COLLISION WARNING (FCW) WITH
MITIGATION — IF EQUIPPED ..............174
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91

NOTE:You may experience deformation in the seat cush-
ion from the seat belt buckles if the seats are left folded for
an extended period of time. This is normal and by simply
opening the seats to the open position, over time the seat
cushion will return to its normal shape.
WARNING!
Be certain that the seatback is securely locked into
position. If the seatback is not securely locked into
position the seat will not provide the proper stability
for child seats and/or passengers. An improperly
latched seat could cause serious injury.
DRIVER MEMORY SEAT — IF EQUIPPED
This feature allows the driver to store up to two different
memory profiles for easy recall through a memory switch.
Each memory profile contains desired position settings for
the driver seat, side mirrors, and power tilt and telescopic
steering column (if equipped) and a set of desired radio
station presets. Your Remote Keyless Entry key fob can also
be programmed to recall the same positions when the
UNLOCK button is pushed. NOTE:
Your vehicle is equipped with two key fobs, one
key fob can be linked to memory position 1 and the other
key fob can be linked to memory position 2.
The memory seat switch is located on the driver ’s door
trim panel. The switch consists of three buttons:
• The (S) button, which is used to activate the memory
save function.
• The (1) and (2) buttons which are used to recall either of
two pre-programmed memory profiles.
Memory Seat Switch
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

Programming The Memory Feature
NOTE:To create a new memory profile, perform the
following:
1. Cycle the vehicles ignition to the ON/RUN position (Do not start the engine).
2.
Adjust all memory profile settings to desired preferences
(i.e., seat, side mirror, power tilt and telescopic steering
column [if equipped], and radio station presets).
3. Push and release the S (Set) button on the memory switch.
4. Within five seconds, push and release either of the memory buttons (1) or (2). The Instrument Cluster
Display will show which memory position has been set.
NOTE:
•
Memory profiles can be set without the vehicle in PARK,
but the vehicle must be in PARK to recall a memory profile.
• To set a memory profile to your key fob, refer to
“Linking And Unlinking The Remote Keyless Entry Key
Fob To Memory” in this section.
Linking And Unlinking The Remote Keyless Entry
Key Fob To Memory
Your key fobs can be programmed to recall one of two
pre-programmed memory profiles by pushing the UN-
LOCK button on the key fob.
NOTE: Before programming your key fobs you must select
the “Memory Linked To FOB” feature through the
Uconnect system screen. Refer to “Uconnect Settings ” in
“Understanding Your Instrument Panel” for further infor-
mation.
To program your key fobs, perform the following:
1. Cycle the vehicles ignition to the OFF position.
2. Select a desired memory profile (1) or (2).
NOTE: If a memory profile has not already been set, refer
to Programming The Memory Feature in this section for
instructions on how to set a memory profile.
3. Once the profile has been recalled, push and release the SET (S) button on the memory switch.
4. Within five seconds, push and release button (1) or (2) accordingly. “Memory Profile Set” (1 or 2) will display
in the instrument cluster.
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131

5. Within 10 seconds, Push and release the LOCK buttonon the key fob.
NOTE: Your key fobs can be unlinked to your memory
settings by pushing the SET (S) button, and within 10
seconds, followed by pushing the UNLOCK button on the
key fob.
Memory Position Recall
NOTE: The vehicle must be in PARK to recall memory
positions. If a recall is attempted when the vehicle is not in
PARK, a message will be displayed in the Instrument
Cluster Display.
Driver One Memory Position Recall
• To recall the memory settings for driver one using the
memory switch, push MEMORY button number 1 on the
memory switch.
• To recall the memory settings for driver one using the
key fob, push the UNLOCK button on the key fob linked
to memory position 1. Driver Two Memory Position Recall
•
To recall the memory setting for driver two using the
memory switch, push MEMORY button number 2 on the
memory switch.
• To recall the memory settings for driver two using the
key fob, push the UNLOCK button on the key fob linked
to memory position 2.
A recall can be cancelled by pushing any of the MEMORY
buttons during a recall (S, 1, or 2). When a recall is
cancelled, the driver’s seat and steering column (if
equipped) stop moving. A delay of one second will occur
before another recall can be selected.
Easy Entry/Exit Seat
This feature provides automatic driver seat positioning to
enhance driver mobility when entering and exiting the
vehicle.
The distance the driver seat moves depends on where you
have the driver seat positioned when you cycle the vehi-
cle’s ignition to the OFF position.
• When you cycle the vehicle’s ignition to the OFF posi-
tion, the driver seat will move about 2.4 inches (60 mm)
rearward if the driver seat position is greater than or
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

LIGHTS
Headlight Switch
The headlight switch is located on the left side of the
instrument panel, next to the steering wheel. The headlight
switch controls the operation of the headlights, parking
lights, instrument panel lights, cargo lights and fog lights
(if equipped).To turn on the headlights, rotate the headlight
switch clockwise. When the headlight switch is
on the parking lights, taillights, license plate light
and instrument panel lights are also turned on.
To turn off the headlights, rotate the headlight switch back
to the O (OFF) position.
NOTE:
• Your vehicle is equipped with plastic headlight and fog
light (if equipped) lenses that are lighter and less sus-
ceptible to stone breakage than glass lights. Plastic is not
as scratch resistant as glass and therefore different lens
cleaning procedures must be followed.
• To minimize the possibility of scratching the lenses and
reducing light output, avoid wiping with a dry cloth. To
remove road dirt, wash with a mild soap solution
followed by rinsing.
CAUTION!
Do not use abrasive cleaning components, solvents, steel
wool or other abrasive materials to clean the lenses.
Headlight Switch
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135

Multifunction Lever
The multifunction lever is located on the left side of the
steering column.
Turn Signals
Move the multifunction lever up or down and the arrows
on each side of the Instrument Cluster Display will flash to
show proper operation of the front and rear turn signal
lights.NOTE:
If either light remains on and does not flash, or
there is a very fast flash rate, check for a defective outside
light bulb. If an indicator fails to light when the lever is
moved, it would suggest that the indicator bulb is defec-
tive.
When the Daytime Running Lights are on and a turn signal
is activated, the Daytime Running Lamp will turn off on
the side of the vehicle in which the turn signal is flashing.
The Daytime Running Lamp will turn back on when the
turn signal is turned off.
Lane Change Assist
Tap the lever up or down once, without moving beyond
the detent, and the turn signal (right or left) will flash three
times then automatically turn off.
Flash-To-Pass
You can signal another vehicle with your headlights by
partially pulling the multifunction lever toward the steer-
ing wheel. This will cause the high beam headlights to turn
on until the lever is released.
Multifunction Lever
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

High/Low Beam Switch
Push the multifunction lever toward the instrument panel
to switch the headlights to high beams. Pulling the multi-
function back toward the steering wheel will turn the low
beams back on, or shut the high beams off.
WINDSHIELD WIPERS AND WASHERS
The windshield wiper/washer controls are located on the
multifunction lever on the left side of the steering column.
The front wipers are operated by rotating a switch, located
on the end of the lever. For information on the rear
wiper/washer, refer to “Rear Window Features” in “Un-
derstanding The Features Of Your Vehicle”.
Windshield Wiper Operation
Rotate the end of the lever to one of the first four detent
positions for intermittent settings, the fifth detent for low
wiper operation and the sixth detent for high wiper
operation.
Multifunction Lever
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143

Windshield Washer Operation
To use the washer, push on the end of the lever (toward the
steering wheel) and hold while spray is desired. If the lever
is pushed while in the intermittent setting, the wipers will
turn on and operate for several wipe cycles after the end of
the lever is released, and then resume the intermittent
interval previously selected.If the end of the lever is pushed while the wipers are in the
off position, the wipers will operate for several wipe cycles,
then turn off.
WARNING!
Sudden loss of visibility through the windshield could
lead to a collision. You might not see other vehicles or
other obstacles. To avoid sudden icing of the wind-
shield during freezing weather, warm the windshield
with the defroster before and during windshield
washer use.
Windshield Washer Operation
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145
