2017 CHRYSLER 200 Owners Manual

CavityCartridge Fuse Blade Fuse Description
F18 – –Not Used
F19 40 Amp Green –Starter Solenoid
F20 –10 Amp Red A/C Compressor Clutch
F21 – –Not Used
F22 –5 Amp Tan Radiator Fan Enable
F23 –70 Amp Tan Body Controller Module (BCM) –
Feed 2
F23 –50 Amp RedVoltage Stability Module (VSM)
#2 – If Equipped With Engine Stop/Start Option
F24 – –Not Used
F25B –20 Amp Yellow Front Washer Pump – If
Equipped with Engine Stop/Start Option
F26 – –Not Used
F27 – –Not Used
F28 –15 Amp Blue Transmission Control Module
(TCM)
7
MAINTAINING YOUR VEHICLE 479

CavityCartridge Fuse Blade Fuse Description
F29 – –Not Used
F30 –10 Amp Red Engine Control Module (ECM)/
EPS/Fuel Pump Relay Feed
F31 – –Not Used
F32 – –Not Used
F33 – –Not Used
F34 – –Not Used
F35 – –Not Used
F36 – –Not Used
F37 50 Amp Red –Radiator Fan PWM Controller
F38 – –Not Used
F39 40 Amp Green –HVAC Blower Motor
F40 – –Not Used
F41 50 Amp Red –Voltage Stability Module (VSM)
#1 – If Equipped With Engine Stop/Start Option
F41 60 Amp Yellow –Body Controller Module (BCM) –
Feed 1
480 MAINTAINING YOUR VEHICLE

CavityCartridge Fuse Blade Fuse Description
F42 – –Not Used
F43 –20 Amp Yellow Fuel Pump Motor
F44 – –Not Used
F45 30 Amp Pink –Passenger Door Module (PDM) –
If Equipped
F46 25 Amp Clear –Sunroof – If Equipped
F47 – –Not Used
F48 30 Amp Pink –Driver Door Module (DDM)
F49 30 Amp Pink –Power Inverter (115V A/C) – If
Equipped
F50 30 Amp Pink –Windshield Wiper Smart Motor
(WWSM)
F51 – –Not Used
F52 – –Not Used
F53 30 Amp Pink –Brake System Module BSM &
Valves
F54 30 Amp Pink –Body Controller Module (BCM) –
Feed 3
7
MAINTAINING YOUR VEHICLE 481

CavityCartridge Fuse Blade Fuse Description
F55 –10 Amp Red Blind Spot Sensors/Compass/
Rearview Camera – If Equipped
F56 –15 Amp Blue Ignition Node Module
(IGNM)/RF Hub
F57 – –Not Used
F58 –10 Amp Red Occupant Classification Module/
Voltage Stability Module (VSM)#2 – If Equipped With Engine Stop/Start Option
F59 30 Amp Pink –Drivetrain Control Module
(DTCM)
F60 –20 Amp Yellow Power Outlet – Center Console
F61 – –Not Used
F62 – –Not Used
F63 –20 Amp Yellow Front Heated Seats – If Equipped
F64 –20 Amp Yellow Heated Steering Wheel – If
Equipped
482 MAINTAINING YOUR VEHICLE

CavityCartridge Fuse Blade Fuse Description
F65 –10 Amp RedIn Vehicle Temperature Sensor/
Humidity Sensor/Driver Assist System Module (DASM)/Park
Assist (PAM) – If Equipped With Engine Stop/Start Option
F66 –15 Amp Blue Instrument Panel Cluster (IPC)/
(Electronic Climate Control(ECC)) HVAC
F67 –10 Amp RedIn Vehicle Temperature Sensor/
Humidity Sensor/Drivers Assist System Module (DASM)/Park Assist (PAM) – If Equipped
F68 – –Not Used
F69 –10 Amp Red Gear Shift Module (GSM)/Active
Grill Shutter (AGS). – IfEquipped/EPB SW
F70 –5 Amp TanIntelligent Battery Sensor (IBS) –
If Equipped with Engine Stop/ Start Option
7
MAINTAINING YOUR VEHICLE 483

CavityCartridge Fuse Blade Fuse Description
F71 –20 Amp Yellow HID Headlamp Right – If
Equipped with Engine Stop/Start Option
F72 –10 Amp Red Heated Mirrors – If Equipped
F73 – –Not Used
F74 30 Amp Pink –Rear Defroster/Defogger
F75 –20 Amp Yellow Cigar Lighter
F76 –10 Amp Red Drivers Window SW– If
Equipped
F77 –10 Amp Red UCI Port/Brake Pedal Switch
F78 –10 Amp Red Diagnostic Port/Steering Column
Control Module (SCCM)
F79 –10 Amp Red Integrated Center Stack (ICS)/
Switch Bank/Instrument Panel Cluster (IPC)/EPB SW
F80 –20 Amp Yellow Radio
F81 – –Not Used
F82 – –Not Used
F83 20 Amp Blue –Engine Control Module (ECM)
484 MAINTAINING YOUR VEHICLE

CavityCartridge Fuse Blade Fuse Description
F84 30 Amp Pink –Electric Park Brake (EPB) – Left
F85 – –Not Used
F86 –20 Amp Yellow Horns – If Equipped With Engine
Stop/Start Option
F87A –20 Amp Yellow HID Headlamp Left – If
Equipped Engine Stop/Start Op- tion
F88 –10 Amp Red Collision Mitigation Module
(CMM)/Electrochromatic Mirror/ Haptic Lane Feedback Module (Half)/Humidity Sensor– If Equipped
F89 – –Not Used
F90 – –Not Used
F91 – –Not Used
F92 – –Not Used
F93 40 Amp Green –Brake System Module (BSM) –
Pump Motor – If Equipped
F94 30 Amp Pink –Electric Park Brake (EPB) – Right
7
MAINTAINING YOUR VEHICLE 485

CavityCartridge Fuse Blade Fuse Description
F95 –10 Amp RedElectrochromatic Mirror/Rain/
Pass. Window SW/Power Outlet Console Illumination/Sensor/ Sunroof – If Equipped
F96 –10 Amp Red Occupant Restraint Controller
(ORC) (Airbag)
F97 –10 Amp Red Occupant Restraint Controller
(ORC) (Airbag)
F98 –25 Amp Clear Audio Amplifier – If Equipped
F99 – –Not Used
F100 – –Not Used
486 MAINTAINING YOUR VEHICLE
