2017 CHRYSLER 200 Owners Manual

Ski Pass-Through
There is a ski pass-through door located behind the rear
seat armrest that allows longer items, such as snow skis, to
be stored in the rear cargo area. Lower the armrest and pull
downward on the latch to open the ski pass-through door.
Ski Pass-Through
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 239

REAR WINDOW FEATURES
Rear Window Defroster
The rear window defroster button is located on the
climate control. Push this button to turn on the rear
window defroster and the heated outside mirrors (if
equipped). An indicator in the button will illuminate when
the rear window defroster is on. The rear window defroster
automatically turns off after approximately 15 minutes. For
an additional 5 minutes of operation, push the button a
second time.
CAUTION!
Failure to follow these cautions can cause damage to
the heating elements:
• Use care when washing the inside of the rear win-
dow. Do not use abrasive window cleaners on the
interior surface of the window. Use a soft cloth and a
mild washing solution, wiping parallel to the heat-
ing elements. Labels can be peeled off after soaking
with warm water.
• Do not use scrapers, sharp instruments, or abrasive
window cleaners on the interior surface of the win-
dow.
• Keep all objects a safe distance from the window.
240 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

UNDERSTANDING YOUR INSTRUMENT PANEL
CONTENTS
INSTRUMENT PANEL FEATURES ...........243
 INSTRUMENT CLUSTER ..................244
 WARNING AND INDICATOR LIGHTS ........247
▫ Red Telltale Indicator Lights ...............247
▫ Yellow Telltale Indicator Lights .............256
▫ Green Telltale Indicator Lights ..............265
▫ White Telltale Indicator Lights ..............268
▫ Blue Telltale Indicator Lights ...............270
 INSTRUMENT CLUSTER DISPLAY ...........271
▫ Instrument Cluster Display Location
and Controls ......................... .271
▫ Oil Change Reset ..................... .273
▫ Instrument Cluster Display Messages ........274
▫ Instrument Cluster Display Menu Items .......276
CYBERSECURITY ....................... .282
 UCONNECT SETTINGS ...................284
▫ Buttons On The Faceplate .................285
▫ Buttons On The Touchscreen ...............285
▫ Customer Programmable Features/
Personal Settings —
Uconnect 5.0/8.4/8.4 NAV Settings ..........285
 UCONNECT RADIOS — IF EQUIPPED ........303
 USB PORT AND AUX JACK — IF EQUIPPED . . . .303
 STEERING WHEEL AUDIO CONTROLS — IF
EQUIPPED ........................... .304
▫ Radio Operation ....................... .304
▫ Media Mode ......................... .304
 RADIO OPERATION AND MOBILE DEVICES . . .305
▫ Regulatory And Safety Information ..........3054

CLIMATE CONTROLS ....................306
▫ Climate Controls Without A Touchscreen
Overview ........................... .306
▫ Climate Controls With A Touchscreen
Overview ........................... .310
▫ Automatic Temperature Control (ATC) — If
Equipped ........................... .318
▫ Operating Tips ....................... .319
 PERSONALIZED MENU BAR ...............322
 UCONNECT VOICE RECOGNITION
QUICK TIPS .......................... .322
▫ Introducing Uconnect ....................322
▫ Get Started .......................... .323
▫ Basic Voice Commands ...................324
▫ Radio .............................. .325
▫ Media .............................. .326
▫ Phone .............................. .327▫
Voice Text Reply ...................... .328
▫ Climate (8.4/8.4 NAV) ...................329
▫ Navigation (8.4 /8.4 NAV) ................330
▫ Uconnect Access (8.4/8.4 NAV) .............331
▫ Register (8.4/8.4 NAV) ...................332
▫ Vehicle Health Alert ....................332
▫ Mobile App (8.4/8.4 NAV) ................332
▫ Voice Texting (8.4/8.4 NAV) ...............334
▫ Yelp (8.4/8.4 NAV) ..................... .335
▫ SiriusXM Travel Link (8.4/8.4 NAV) ..........335
▫ Siri Eyes Free — If Equipped ..............336
▫ Do Not Disturb ....................... .339
▫ General

Information .....................340
▫ Additional Information ...................340
242 UNDERSTANDING YOUR INSTRUMENT PANEL

INSTRUMENT PANEL FEATURES
1 — Air Outlet6 — Radio Screen11 — Steering Wheel
2 — Instrument Cluster Display Controls 7 — Passenger Air Bag 12 — Hood Release
3 — Instrument Cluster 8 — Glove Compartment13 — Headlight Switch
4 — Cruise Controls 9 — Radio Controls
5 — Ignition Switch 10 — Climate Controls
4
UNDERSTANDING YOUR INSTRUMENT PANEL 243

INSTRUMENT CLUSTER
Instrument Cluster — Base
244 UNDERSTANDING YOUR INSTRUMENT PANEL

Instrument Cluster — Premium
4
UNDERSTANDING YOUR INSTRUMENT PANEL 245

1. Tachometer•Indicates the engine speed in revolutions per minute
(RPM x 1000).
2. Instrument Cluster Display •When the appropriate conditions exist, this display
shows the Instrument Cluster Display messages. Refer
to “Instrument Cluster Display” in “Understanding
Your Instrument Panel” for further information.
3. Speedometer •Indicates vehicle speed.
4. Fuel Gauge •The fuel gauge shows the level of fuel in the fuel tank
when the ignition switch is in the ON/RUN position.
•
The fuel pump symbol points to the side of the
vehicle where the fuel door is located.
5. Temperature Gauge
•The temperature gauge shows engine coolant tem-
perature. Any reading within the normal range indi-
cates that the engine cooling system is operating
satisfactorily. •
The gauge pointer will likely indicate a higher tem-
perature when driving in hot weather or up mountain
grades. It should not be allowed to exceed the upper
limits of the normal operating range.
WARNING!
A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call an authorized dealer for
service if your vehicle overheats. If you decide to look
under the hood yourself, see “Maintaining Your Ve-
hicle”. Follow the warnings under the Cooling System
Pressure Cap paragraph.
CAUTION!
Driving with a hot engine cooling system could dam-
age your vehicle. If the temperature gauge reads “H”
pull over and stop the vehicle. Idle the vehicle with the
air conditioner turned off until the pointer drops back
into the normal range. If the pointer remains on the
“H”, turn the engine off immediately and call an
authorized dealer for service.
246 UNDERSTANDING YOUR INSTRUMENT PANEL
