2016 TOYOTA LAND CRUISER engine

3885-1. Using the air conditioning system and defogger
LC200_OM_OM60M88U_(U)
NOTICE
■To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the
engine is not running.

389
LC200_OM_OM60M88U_(U)
5-1. Using the air conditioning system and defogger
5
Interior features
Heated steering wheel/seat heaters/seat
ventilator s
Turns the heated steering wheel
on/off
The indicator light comes on when
the heated steering wheel is oper-
ating.
: If equipped
Heated steering wheel and seat heaters heat the side grips of the
steering wheel and seats. Seat ve ntilators maintain good airflow
by blowing air from the seats.
WARNING
● Care should be taken to prevent injury if anyone in the following categories
comes in contact with the steering wheel and seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically chal-
lenged
• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping drugs, cold remedies, etc.)
● Observe the following precautions to prevent the minor burns or overheat-
ing:
• Do not cover the seat with a blanket or cushion when using the seat
heater.
• Do not use seat heater more than necessary.
NOTICE
● Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.
● To prevent battery discharge, do not use the functions when the engine is
not running.
Heated steering wheel (if equipped)

3905-1. Using the air conditioning system and defogger
LC200_OM_OM60M88U_(U)
●The heated steering wheel can be used when the engine switch is in IGNI-
TION ON mode.
● The heated steering wheel will automatically turn off after about 30 minutes.
● If the indicator light flashes, press the switch to turn the heated steering
wheel off and then press the switch again. If the indicator light still flashes, a
malfunction may be occurring. Turn the heated steering wheel off and have
the vehicle inspected by your Toyota dealer.
Seat heater switches
The indicator light (yellow) on the
switch comes on when the seat
heater is operating.
Seat ventilator switches
The indicator light (green) on the
switch comes on when the seat
ventilator is operating.
Level indicator lights
The seat heater temperature level
or the seat ventilator fan speed
level (for front seats only) is dis-
played.
“AUTO” indicator lights
Front seat heaters and ventilators
1
2
3
4

LC200_OM_OM60M88U_(U)
3915-1. Using the air conditioning system and defogger
5
Interior features
■Modes and indicators
The mode can be changed by pressing the switch.
*: When automatic mode is selected, the level automatically changes
depending on the air conditioning settings.
■ The seat heaters and ventila tors can be used when
The engine switch is in IGNITION ON mode.
■ Replacing the air filters
Filters are installed in the seat ventilators. For replacement of the filters, con-
tact your Toyota dealer.
■ Customization
The automatic mode settings for the seat heaters and ventilators can be
changed. ( P. 574)
Mode“AUTO” indicator lightLevel indicator lights
OffOffOff
Automatic*On3 to 1, or off
HiOff3
MidOff2
LoOff1

3925-1. Using the air conditioning system and defogger
LC200_OM_OM60M88U_(U)
For left-hand second seat
For right-hand second seat
High heating temperature
Low heating temperature
To turn on the seat heater, press
“HI” or “LO”.
Off
■The seat heaters can be used when
The engine switch is in IGNITION ON mode.
Second outboard seat heaters (if equipped)
1
2
3
4
45

393
LC200_OM_OM60M88U_(U)
5-2. Using the interior lights
5
Interior features
Interior lights list
Front interior lights ( P. 394)
Front personal lights ( P. 395)
Rear interior lights ( P. 394)
Rear personal lights ( P. 395)
Inside door handle lights Footwell lights
Scuff lights
Engine switch light
Door courtesy lights
Ambient lights1
2
3
4
5
6
7
8
9
10

LC200_OM_OM60M88U_(U)
3955-2. Using the interior lights
5
Interior features
Front
Turns the light on/off
Rear
Turns the light on/off
■ Illuminated entry system
The lights automatically turn on/off according to engine switch mode, the
presence of the electronic key, whether the doors are locked/unlocked, and
whether the doors are open/closed.
■ To prevent battery discharge
If the interior lights remain on when the engine switch is turned off, the lights
will go off automatically after 20 minutes:
■ Customization
Settings (e.g. adjust the time elapsed before the interior lights automatically
turn off) can be changed. (Customizable features: P. 574)
Personal lights
NOTICE
To prevent battery discharge, do not leave the lights on longer than neces-
sary when the engine is not running.

406
LC200_OM_OM60M88U_(U)
5-4. Using the other interior features
Other interior features
While the engine is running, the cool box, which is cooled by the air
conditioning, can be used.
Lift the lid while pulling up the
lower lever to release the lock.
Turns the cool box on/off
When on, the indicator light comes
on.
If the front air conditioning system
is not in use, the front air condition-
ing system is automatically turned
on when the cool box is turned on.
■While the cool box is on
The front air conditioning system cannot be turned off.
■ When the outside temperature is 0 C (32 F) or below
The cool box may not operate.
Cool box (if equipped)
1
2
