2016 SUBARU BRZ Owners Manual

8
Pictorial indexInterior
Power outlet
P. 269
Head restraints P. 56
Seatbelts P. 58
Cup holders
Console tray P. 263
P. 263
SRS side airbags P. 89
Front seats P. 51
Glove box P. 261
SRS curtain airbags
P. 89Child restraint
anchor brackets
P. 138
Display Audio system
, *1
Navigation system
, *2
SRS front
passenger airbag
P. 89

9
B
AA
Anti-glare inside rear view mirror P. 66
Interior light P. 259
Vanity mirrors P. 266
Sun visors P. 265

: If equipped
*1: Refer to the Owner’s Manual supplement for the audio system.
*2: Refer to “Navigation System Owner’s Manual”.
Lock levers P. 43
Outside rear view mirror switch
P. 67
Window lock switch P. 70
Power window switches
P. 70
Power door lock switch P. 43
Microphone P. 257

10

: If equipped
C
Pictorial indexInterior
Select lever
Shift lever
P. 174
P. 181
Parking brake lever P. 185
Vehicle stability control (VSC)/TRAC off switch P. 218, 221
Seat heater switches
P. 271
“VSC SPORT” switch P. 219
Power outlet P. 269
Shift lock release button
P. 396
Driving pattern selector switch
P. 176

11
Headlight switch
Turn signal lever
Fog light switch

P. 202
P. 184
P. 208
Gauges and meters
Multi-information display P. 187
P. 197
Clock P. 267
Windshield wiper and washer switch P. 209
Hazard warning
flasher switch
P. 358
Tilt and telescopic steering
lock release lever
P. 65
Floor mat
P. 273
Engine hood lock release lever P. 296
Fuel filler lid opener P. 74
Push-button ignition switch (vehicles with a keyless
access with push button start system)
P. 162
AUX port
USB port P. 256
P. 256
Pictorial indexInstrument panel

: If equipped

12
A
Vehicles with a manual air conditioning system
Air conditioning
system
P. 238
Vehicles with an automatic air conditioning system
Rear window and outside rear
view mirror defoggers
P. 254
Air conditioning
system
P. 245
Rear window and outside rear view mirror defoggers
switch

/rear window defogger switch
P. 254
Pictorial indexInstrument panel

13
C
BB
Paddle shift levers
P. 177, 179
Engine (ignition) switch (vehicles
without a keyless access with push
button start system)
P. 171
Cruise control switch P. 212Horn
SRS driver airbag P. 186
P. 89
Instrument panel light control dial P. 191
Manual headlight leveling dial P. 204
Trunk lid opener P. 45

: If equipped

14
For your information
Warranties
■Warranties for U.S.A.
SUBARU vehicles distributed by Subaru of America, Inc. and sold at retail by
an authorized SUBARU dealer in the United States come with the following
warranties:
●SUBARU Limited Warranties
●Federal Emission Control Systems Warranties
●California Emissions Control Systems Warranties
All warranty information, including applicability, details of coverage and
exclusions, is in the “Warranty and Maintenance Booklet”. Please read these
warranties carefully.
■Warranties for Canada
All SUBARU vehicles distributed by Subaru Canada, Inc. and sold at retail by
an authorized SUBARU dealer in Canada come with the following warran-
ties:
●SUBARU Limited Warranty
●Emission Control System Warranty
All warranty information, including details of coverage and exclusions, is in
the “Warranty and Service Booklet”. Please read these warranties carefully.
Main Owner’s Manual
Please note that this manual applies to all models and explains all equip-
ment, including options. Therefore, you may find some explanations for
equipment not installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the SUBARU policy of continual product improvement,
we reserve the right to make changes at any time without notice and without
incurring any obligation to make changes on vehicles previously sold.
Depending on specifications, the vehicle shown in the illustration may differ
from your vehicle in terms of color and equipment.

15
Noise from under vehicle after turning off the engine
Approximately five to ten hours after the engine is turned off, you may hear
sound coming from under the vehicle for several minutes. This is the sound
of a fuel evaporation leakage check and, it does not indicate a malfunction.
Accessories, spare parts and modification of your SUBARU
A wide variety of non-genuine spare parts and accessories for SUBARU
vehicles are currently available in the market. You should know that
SUBARU does not warrant these products and is not responsible for their
performance, repair, or replacement, or for any damage they may cause to,
or adverse effect they may have on, your SUBARU vehicle.
This vehicle should not be modified with non-genuine SUBARU products.
Modification with non-genuine SUBARU products could affect its perfor-
mance, safety or durability, and may even violate governmental regulations.
In addition, damage or performance problems resulting from the modification
may not be covered under warranty.
Installation of a mobile two-way radio system
The installation of a mobile two-way radio system in your vehicle could affect
electronic systems such as:
●Multiport fuel injection system/sequential multiport fuel injection system
●Cruise control system
●Anti-lock brake system
●SRS airbag system
●Seatbelt pretensioner system
Be sure to check with your SUBARU dealer for precautionary measures or
special instructions regarding installation of a mobile two-way radio system.
