2016 NISSAN MURANO HYBRID Owners Manual

HIGH-VOLTAGE COMPONENTS
AND THEIR LOCATIONS
WARNING
●The NISSAN PURE DRIVE Hybrid Sys-
tem uses high voltage up to approxi-
mately 144 volts. The system can be hot
during and after starting. Be careful of
both the high voltage and the high tem-
perature. Obey the warning labels at-
tached to the vehicle.
● Never touch, disassemble, remove or
replace the high-voltage parts, har-
nesses and their connectors. High-
voltage harnesses are orange. Touch-
ing, disassembling, removing or
replacing those parts and harnesses
can cause severe burns or electric
shock that may result in serious injury
or death.
● Do not change or modify the center con-
sole where the Li-ion battery is located.
For example, do not drill the center con-
sole. Modifying the center console may
cause a short circuit and damage the
Li-ion battery.
LHV2056
HYBRID VEHICLE PRECAUTIONS
HEV-10HEV Overview

1. DC/DC Converter
2. Service Plug
3. Lithium-ion (Li-ion) battery
4. High-Voltage Harness
5. 12–volt battery
6. Traction Motor Inverter
7. Traction Motor
The hybrid system uses high voltage up to ap-
proximately 144 volts. High-voltage components
are indicated in the illustration. High-voltage har-
nesses are orange. The system can be hot during
and after starting. Be careful of both the high
voltage and the high temperature.
HYBRID VEHICLE
CHARACTERISTICS
WARNING
●When you leave your vehicle, be sure to
place the ignition switch in the OFF
position. ●
Be sure to put the transmission in the P
(Park) position because the vehicle can
move when the READY to drive indica-
tor light is on even if the gasoline en-
gine is not running. When the READY to
drive indicator light is on, do not leave
your vehicle in a shift position other
than the P (Park) position. The vehicle
will creep and start abruptly if the accel-
erator pedal is depressed by mistake.
This may cause serious injury or death.
CAUTION
If the vehicle is parked for a long period of
time, the battery discharges gradually. To
avoid this occurrence, drive the vehicle for
approximately 30 minutes at least once
every two to three months. Otherwise, the
Li-ion battery may be damaged. If the Li-
ion battery is completely discharged and
the hybrid system cannot be activated, it is
recommended that you visit a NISSAN
dealer.
High-voltage parts and harnesses on the hybrid
vehicles emit approximately the same amount of
electromagnetic waves as the conventional
gasoline-powered vehicles or home electronic
appliances despite their electromagnetic shield-
ings. Charging the Li-ion battery while driving is impor-
tant. The vehicle cannot run if the Li-ion battery is
discharged. In the N (Neutral) position, the Li-ion
battery does not recharge. Leaving the transmis-
sion in the N (Neutral) position for an extended
period of time may discharge the Li-ion battery.
The Li-ion battery recharges when the shift lever
is in any position other than N (Neutral) .
CAUTION
●
Do not place large amounts of water in
open containers (aquariums or buckets)
on the front passenger’s side floor. If
the water spills onto the Li-ion battery
cooling fan, it may cause a short circuit
and damage the Li-ion battery cooling
fan.
● Do not spill water onto the center con-
sole or around the area. It may cause a
short circuit and damage the Li-ion
battery.
HEV OverviewHEV-11

Noise and vibration
After the hybrid system is activated, the following
noises and vibrations that are unique to the hy-
brid system may occur. The following situations
do not indicate a malfunction:● Electric motor noise from the engine com-
partment
● Noise from the rear of the vehicle when the
hybrid system activates or deactivates
● Noise and vibration when the gasoline en-
gine starts running or stops
● Operating noise or electric motor noise
when releasing the accelerator pedal or de-
pressing the brake pedal
● Engine noise due to rapid acceleration
● Fan noise from the air inlet located on the
rear parcel shelf
● Noise from the climate control system
HEV-12HEV Overview

0 Illustrated table of contents
Air bags, seat belts and child restraints..............0-2
Exterior front ......................................0-3
Exterior rear .......................................0-4
Passenger compartment ...........................0-5 Instrument panel
...................................0-6
Engine compartment check locations . . ..............0-8
Warning and indicator lights ........................0-9

1. Supplemental front-impact air bags(P. 1-46)
2. Occupant classification sensor
(weight sensor) (P. 1-46)
3. Head restraints/headrests (P. 1-9)
4. Front seat belts with pretensioner(s)
and shoulder height adjuster
(P. 1-13, 1-46)
5. Roof-mounted curtain side-impact and
rollover supplemental air bag (P. 1-46)
6. Rear seat center seat belt (located on
ceiling) (P. 1-13)
7. Rear seat outboard seat top tether
strap anchor (located on bottom of
seatback) (P. 1-26)
8. LATCH (Lower Anchors and Tethers for
CHildren) system (P. 1-26)
9. Folding rear bench seat (P. 1-2)
10. Front seat-mounted side-impact
supplemental air bag (P. 1-46)
11. Front seats (P. 1-2)
12. Driver supplemental knee air bag
(P. 1-46)
Refer to the page number indicated in pa-
rentheses for operating details.
LII2370
AIR BAGS, SEAT BELTS AND CHILD
RESTRAINTS
0-2Illustrated table of contents

1. Front view camera (P. 4-2)
2. Engine hood (P. 3-20)
3. Wiper and washer switch (P. 2-35)
4. Windshield (P. 8-21)
5. Power windows (P. 2-56)
6. Door locks (P. 3-4)NISSAN Intelligent Key® (P. 3-7)
Keys (P. 3-2)
7. Mirrors (P. 3-32) Side view camera (P. 4-2)
8. Tire pressure (P. 8-32) Flat tire (P. 6-3)
Tire chains (P. 8-32)
9. Fog light switch (P. 2-37)
10. Headlight and turn signal switch
(P. 2-37)
Replacing bulbs (P. 8-28)
Refer to the page number indicated in pa-
rentheses for operating details.
LII2371
EXTERIOR FRONT
Illustrated table of contents0-3

1. Rear wiper and washer switch (P. 2-35)
2. Liftgate release (P. 3-21)
3. Rearview camera (P. 4-2)
4. Replacing bulbs (P. 8-28)
5. Fuel-filler door (P. 3-26)Fuel recommendation (P. 9-2)
Fuel-filler cap (P. 3-26)
6. Child safety rear door lock (P. 3-4)
Refer to the page number indicated in pa-
rentheses for operating details.
LII2388
EXTERIOR REAR
0-4Illustrated table of contents

1. Glove box (P. 2-49)
2. Rearview mirror (P. 3-32)
3. Console box (P. 2-49)
4. Map lights (P. 2-60)
5. Luggage hooks (P. 2-49)
6. Rear center armrest (P. 1-2)
7. Sun visors (P. 3-30)
8. Cup holders (P. 2-49)
Refer to the page number indicated in pa-
rentheses for operating details.
LII2385
PASSENGER COMPARTMENT
Illustrated table of contents0-5
