2016 NISSAN LEAF navigation


> (GLW    0RGHO (1-1 (91$01&*. @
4. Touch a preferred events from the list tocheck the detailed information and the map.
Displaying urgent traffic informationENJN1502-640E1972-00BA-4AAB-817F-9DD492D3BEE6When an urgent event is found around the
current vehicle location, a message pops up
automatically on the touch screen display with a
voice announcement.
The message includes the icon, event type, event
information and the direct distance from the
current location to the event.
INFO:
. Urgent traffic information is displayed re-
gardless of whether [Use Traffic Info] func-
tion is on or off.
ªTraffic information settingº
(page 3-51)
. When there are multiple urgent events, the
event with the shortest direct distance from
the current location is displayed.
. If the urgent event is on the recommended
route, and if a detour is found, the detour
route notification screen is displayed when
the vehicle approaches the detour point.
Traffic information on mapENJN1502-349B2DD4-5AE0-4619-9823-43EBC8BCDC55With a subscription to SiriusXM Traffic service,
traffic information is displayed on both 2D map
and Birdview
TMmap screen.
ªNotes on SiriusXM Traffic informationº
(page 6-9)
Screen information
5GB0452X
*1Road conditions
Free Flow: Green arrow
Moderate traffic: Yellow arrow
Heavy traffic: Red arrow
Section affected by serious traffic event:
Purple arrow
*2Traffic information icon:
If a route is not already set, all of the traffic
information icons on the map screen are
displayed in color. When a route is already
set, the icons on the route are displayed in
color, and the icons outside the route are
displayed in gray.
: Accident
: Closed road
: Information
: Road work
: Slippery road
: Weather
: Incident
*3Traffic indicator:
Displays the reception condition of traffic
information transmitted from the provider.
When reception condition of traffic infor-
mation transmitted from the provider is not
detected, the traffic indicator will be
ªgrayed-outº.
&RQGLWLRQ
3-50
3. Navigation


> (GLW    0RGHO (1-1 (91$01&*. @
*4Remaining distance and estimated time to
the destination calculated with considera-
tion of traffic information on route.
INFO:
Traffic icons are displayed in the scale level of
1/64 miles (25 m) - 5 miles (10 km) range. Some
traffic icons are displayed only on the map at
higher detail levels.
TRAFFIC INFORMATION SETTINGENJN1502-9E862250-858D-4540-8106-66DE14C1E881Settings for the traffic information related func-
tions can be changed.
5GB0499X
1. Touch [Settings] on the Launch Bar.
2. Touch [Navigation].
3. Touch [Traffic Info Setting].
4. Touch the preferred setting. The indicator for the selected setting illuminates.
Available setting items .
[Use Traffic Info]:
Enables all traffic information related func-
tions.
. [Show Incidents on Map]:
Displays the traffic incidents (e.g., accident)
on the map screen.
. [Show Traffic Flow on Map]:
Displays the traffic flow with an arrow on the
map screen.
. [Traffic Announcement]:
Announces the traffic information event on
the route.
INFO:
. Even when [Show Traffic Flow on Map] and
[Show Incidents on Map] are set to off, the
list display of [Info on Route] and [Nearby
Traffic Info] will not be affected.
ªViewing traffic events from listº
(page 3-49)
. Even when [Traffic Announcement] is set to
off, the route guidance will not be affected.
Also, the announcement of emergency in-
formation and weather information will not be
turned off.
Voice command
1. Push <
>located on the steering wheel.
2. After the tone sounds, speak a command. Use the following voice command to turn the
traffic information system on/off:
ªTraffic Informationº
&RQGLWLRQ
3-51
3. Navigation


> (GLW    0RGHO (1-1 (91$01&*. @
STORING A LOCATION/ROUTEENJN1502-120906-D56E2757-E480-448D-84DE-0D0260214C62
STORING LOCATIONENJN1502-120906-544965B9-F333-49EA-BE90-4D6BE51EE5F0Often visited locations can be stored in the
Stored Locations. The stored addresses can be
easily retrieved to set them as a destination or
waypoint. The Stored Locations can store up to
200 locations.
Storing home locationENJN1502-120906-18F9446E-22F6-4B69-B465-63E96AFC7E1DA home location can be stored in the system.
This operation is not available when a destination
is set for route guidance.
5GB0453X
1. Touch [Navi] on the Launch Bar.
2. Touch [Home].
3. If a home location is not registered, thesystem asks if you wish to store it. Touch
[Yes] to continue with the storing operation. 4.
Set the Home location using the same
procedure as setting a destination.
ªSetting destinationº (page 3-17)
5. The selected location is displayed on the map screen as a home icon. Edit the
contents of the stored item as necessary
and touch [OK].
ªEditing stored home and locationº
(page 3-55)
Other Settings
1. Touch [Settings] on the Launch Bar.
2. Touch [Navigation] and touch [Address
Book].
3. Touch [Home Location (None)].
4. Touch an appropriate method to set a
location. Refer to the search methods used
for destination setting.
ªSetting destinationº (page 3-17)
When stored, the location is displayed at the
center of the map on the touch screen
display.
5. Edit the contents of the stored item as necessary and touch [OK].
ªEditing stored home and locationº
(page 3-55)
Storing location by searchingENJN1502-120906-6B0517E8-1830-49EB-812C-0BAA64EC0CEAIt is possible to store a location by searching in
various ways.
5GB0454X
1. Touch [Settings] on the Launch Bar.
2. Touch [Navigation].
3. Touch [Address Book].
4. Touch [Stored Locations].
5. Touch [Add New].
6. Touch a method to set a location. Refer to thesearch methods used for destination setting.
ªSetting destinationº (page 3-17)
7. A message is displayed, and the address of the location is stored in the Address Book.
8. Adjust and edit the contents of the stored item as necessary. Touch [OK] to confirm.
ªEditing stored home and locationº
(page 3-55)
&RQGLWLRQ
3-52
3. Navigation


> (GLW    0RGHO (1-1 (91$01&*. @
INFO:
. When the location is stored in the Stored
Locations, [Address Book] can be used to
search for the location.
ªSearching from address bookº
(page 3-24)
. When 200 locations are already stored, a
new location cannot be stored until a
currently stored location is deleted.
Storing location by moving mapENJN1502-120906-F725F4DF-5CDD-4070-ADB6-D4BF2474895F1. Move to the preferred location on the map
and touch [
] on the touch screen display.
5GB0576X
2. Touch [Save Location]. A message is dis-
played.
3. The icon representing the stored location is displayed on the map. Push


> (GLW    0RGHO (1-1 (91$01&*. @
5GB0456X
5. Touch [Add New].Touch an appropriate method to search for a
location.
ªSetting destinationº (page 3-17)
6. Adjust the information of the Avoid Area as necessary.
ªEditing avoid areaº (page 3-57)
7. Touch [OK] to store the avoid area informa- tion.
INFO:
. A maximum of 10 Avoid Areas can be stored.
When 10 Avoid Areas are already stored, a
new Avoid Area cannot be stored until a
currently stored Avoid Area is deleted.
ªDeleting stored itemº (page 3-57)
EDITING STORED INFORMATIONENJN1502-120906-39CF1CB1-4830-4B51-BE7E-70154B58A89CItems stored in the system can be edited.
&RQGLWLRQ
3-54
3. Navigation


> (GLW    0RGHO (1-1 (91$01&*. @
Editing stored home and locationENJN1502-120906-D9E4FAC6-0EAD-4C1E-9D3C-A1EBC19926E11. Touch [Settings] on the Launch Bar.
2. Touch [Navigation] and touch [Address Book].
Setting itemAction
[Home Location]* [Edit] [Show Icon on Map] Displays the home icon on the map.
[Icon] Selects a home icon of a preferred design.
[Sound] Sets the type of the alarm that sounds when the
vehicle approaches home.
[Direction] Sets the alarm to sound when approaching from a
specific direction.
[Distance] Sets the alarm to sound when reaching a specific
distance to home.
[Phone No.] Stores the home telephone number.
[Move Location] Adjusts the stored home location.
[Delete] Deletes the stored home location.
[OK] Confirms and saves the edited home information.
[Stored Locations] [Sort] [Sorted By Number] Sorts the stored locations.
ªSearching from address bookº (page 3-24)
[Sorted By Name]
[Sorted By Icon]
[Sorted By Group]
[Add New] Adds a new location.
ªStoring location by searchingº (page 3-52)
Stored Location List [Edit] [Show Icon on Map]Displays the icon on the map.
[Name] Registers a name of the entry.
&RQGLWLRQ
3-55
3. Navigation


> (GLW    0RGHO (1-1 (91$01&*. @
[Voicetag]Registers a voicetag for the entry which allows the
entry to be used with the voice recognition system.
[Charging Sta. Att.] [Quick Charge Station]The location is registered as a charging station with
quick charge equipment and can be included in the
charging station search.
[Normal
Charge Sta-
tion] The location is registered as a s charging station
with normal charge equipment and can be included
in the charging station search.
[Not a Charge
Station] The location is registered as a location that is not a
charging station.
[Icon] Selects an icon for the entry.
[Sound] Sets the type of the alarm that sounds when the
vehicle approaches the location.
[Direction] Sets the alarm to sound when approaching from a
specific direction.
[Distance] Sets the alarm to sound when reaching a specific
distance to the location.
[Phone No.] Registers a phone number of the location.
[Group] Registers a group of the entry.
[Entry Numbers] Registers an entry number for the location.
[Move Location] Adjusts the stored location information.
[Delete] Deletes the stored location information.
[OK] Confirms and saves the edited stored location
information.
&RQGLWLRQ
3-56
3. Navigation


> (GLW    0RGHO (1-1 (91$01&*. @
*: When home location has not been stored,
[Home Location (None)] is displayed and a home
location can be stored from the menu.
Editing stored routeENJN1502-120906-FA819EB7-2462-4CCA-9FCA-6945BF4DA07F1. Touch [Settings] on the Launch Bar.
2.Touch [Navigation] and touch [Address
Book].
3. Touch [Stored Routes].
4. Touch the preferred stored route from the list.
Setting item Action
[Rename] Changes the stored route
name.
[Replace] Overwrites the stored tracked route to the current tracked
route.
[Delete] Deletes the stored route.
[OK] Applies the edited settings.
Editing avoid areaENJN1502-120906-7741D32C-748E-4BE2-9BE8-E72FF75E70C61. Touch [Settings] on the Launch Bar and
touch [Navigation].
2. Touch [Address Book] and then touch [Avoid Area]. 3. Touch a preferred Avoid Area from the list.
Avoid Area editing screen will be displayed.
Setting item Action
[Rename] Changes the name of an Avoid Area.
[Move Loca-
tion] Display the Avoid Area on the
touch screen display, and ad-
justs the location of the Avoid
Area.
[Resize Area] Adjusts the range of the Avoid Area.
[FWY] Sets the route to include or not include freeways.
On the map, the Avoid Area will
be displayed in green if it
includes a freeway or in blue if it
does not include a freeway.
[Delete] Delete an Avoid Area.
[OK] Applies the edited setting.
DELETING STORED ITEMENJN1502-120906-A49F7444-AEBA-437D-B1BF-DA7457A3F577The locations and routes in the Address Book
can be deleted. Two deletion methods are
available: deleting an individual item and deleting
all stored items.
INFO:
. Deleted items cannot be restored. Before
deleting an item, always make sure that the
item is no longer needed.
&RQGLWLRQ
3-57
3. Navigation
