4416-3. Using the storage features
6
Interior features
NX200t_OM_USA_OM78081U
Lift the deck board and attach the hook. (P. 442) The following item can be
stowed.
First-aid kit and other items
Accessories
Wa r n i n g r e f l e c t o r
*
*
: The warning reflector itself is not included as an original equipment.
Grocery bag hooks
NOTICE
Do not hang any object heavier than 11 lb. (5 kg) on the grocery bag hooks.
Deck under tray
1
2
3

4426-3. Using the storage features
NX200t_OM_USA_OM78081U
If the luggage cover is used: Unhook
the cords.
If the luggage cover is used: Fold up
the luggage cover.
Pull the lever upwards and open the
deck board.
Lift the deck board and remove the
hook on the backside of the deck
board.
Deck board
1
2
3
4

4436-3. Using the storage features
6
Interior features
NX200t_OM_USA_OM78081U
Attach the hook to the upper edge
of the back door opening as shown.
Unhook the cords.
Fold up the luggage cover.
5
When attaching the side deck board, attach it so
that the “FRONT” mark points to the front side
of the vehicle.
WA R N I N G
If the deck boards are opened or removed, return them to their original positions
before driving. In the event of sudden braking, an accident may occur due to an occu-
pant being struck by the deck boards or the items stored in the deck under tray.
Stowing the luggage cover
1
2

4446-3. Using the storage features
NX200t_OM_USA_OM78081U
Pull the lever upwards and open the
deck board.
Remove the luggage cover.
When the seatback for the rear seat is
collapsed to the rear, remove the cover
after the cover most upright position.
(  P. 1 3 8 )
Stow the luggage cover in the deck
under tray while lifting the deck
board.
3
4
5
WA R N I N G
●Do not place anything on the luggage cover. In the event of sudden braking or turn-
ing, the item may go flying and strike an occupant. This could lead to an unexpected
accident, resulting in death or serious injury.
●Do not allow children to climb on the lugg age cover. Climbing on the luggage cover
could result in damage to the luggage cover, possibly causing death or serious injury
to the child.

4456-4. Other interior features
6
Interior features
NX200t_OM_USA_OM78081U
Other interior features
To set the visor in the forward posi-
tion, flip it down.
To set the visor in the side position,
flip down, unhook, and swing it to the
side.
To use the side extender, place the
visor in the side position, then slide it
backward.
If the vanity lights remain on when the engine switch is turned off, the light will go off auto-
matically after 20 minutes.
Sun visors
1
2
3
Vanity mirrors
On the sun visorsOn the sunglass holder
Slide the cover to open.
The light turns on when the cover is
opened.
Remove the lid of sunglasses holder
using the strap. ( P. 4 3 9 )
There is a vanity mirror on the back
side of the lid.
NOTICE
●To prevent damage to the vanity mirror, when the lid of sunglass holder is removed, do
not subject it to strong impacts or set heavy objects on top of it.
●To prevent battery discharge, do not leave the vanity lights on for extended periods
while the engine is off.
Strap

4466-4. Other interior features
NX200t_OM_USA_OM78081U
The clock can be adjusted by pressing the buttons. Pressing and holding will move the
clock hands backward.
Pressing and holding will move the
clock hands forward.
Please use a power supply for electronic goods that use less than 12 VDC/10 A
(power consumption of 120 W).
When using electronic goods, make sure that the power consumption of all the
connected power outlets is less than 120 W.
●The power outlet can be used when the engine switch is in ACCESSORY or
IGNITION ON mode.
Clock
1
2
Power outlet (12 VDC)
Inside the console boxIn the luggage compartment
Open the lid. Open the lid.
●The notch in console box allows power cables
to be passed through even when the console
box is closed.

4476-4. Other interior features
6
Interior features
NX200t_OM_USA_OM78081U
Please use a power supply for electronic goods that use less than 120 VAC
(power consumption of 100 W).
Open the lid.
The power outlet can be used when the engine switch is in IGNITION ON mode.
NOTICE
●To avoid damaging the power outlet, close the power outlet lid when the power outlet
is not in use.
Foreign objects or liquids that enter the power outlet may cause a short circuit.
●To prevent battery discharge, do not use the power outlet longer than necessary
when the engine is off.
Power outlet (120 VAC) (if equipped)
NOTICE
●To avoid damaging the power outlet, close the power outlet lid when the power outlet
is not in use.
Foreign objects or liquids that enter the power outlet may cause a short circuit.
●To prevent blown fuse, do not use a 120 VAC appliance that requires more than
100 W.
If a 120 VAC appliance that consumes more than 100 W is used, the protection cir-
cuit will cut the power supply.
●To prevent battery discharge, do not use the power outlet longer than necessary
when the engine is off.
●The following 120 VAC appliances may not operate properly even if their power con-
sumption is under 100W:
• Appliances with high initial peak wattage
• Measuring devices that process precise data
• Other appliances that require an extremely stable power supply

4486-4. Other interior features
NX200t_OM_USA_OM78081U
A portable device can be charged by ju st placing Qi standard wireless charge
compatible portable devices according to the Wireless Power Consortium, such
as smart phones and mobile batteries, etc., on the charge area.
This function cannot be used with port able devices that are larger than the
charging area. Also, depending on the portable device, it may not operate as
normal. Please read the operation manual for portable devices to be used.
■The “Qi” symbol
The “Qi” symbol is a trademark of the Wireless Power Consortium.
■Name for all parts
Power supply switch
Operation indicator light
Charge area
Wireless charger (if equipped)
1
2
3
