2016 Lexus ES350 Quick Guide /

25
ES350_QG_OM33B82U_(U)
Automatic Transmission
nShifting the shift lever
While the engine switch is in IGNITI ON ON mode, move the shift lever with
the brake pedal depressed.
When shifting the shift lever between P and D, make sure that the vehicle is
completely stopped.
n Shift position purpose
*1: Shifting to the D position allows the system to select a gear suitable for the driv-
ing conditions.
Setting the shift lever to the D position is recommended for normal driving.
*2: Selecting shift ranges using S mode restricts the upper limit of the possible gear ranges, controls engine braking for ce, and prevents unnecessary upshifting.
Shift positionObjective or function
PParking the vehicle/starting the engine
RReversing
NNeutral
DNormal driving*1
SS mode driving*2

26
ES350_QG_OM33B82U_(U)
nSelecting gears in the S position
When the shift lever is in the S position, the shift lever can be operated as follows:
Upshifting
Downshifting
The selected shift range, from 1 to
6, will be displayed in the meter.
The initial shift range in S mode is
set automatically to 5 or 4 accord-
ing to vehicle speed. But, the initial
shift range may be set to 3 if AI-
SHIFT has operated while the shift
lever was in the D position.
1
2
n Shift ranges and their functions • Automatically selecting gears between 1 and 6 according to vehicle speed
and driving conditions. But, the gear is limited according to selected shift
range.
• You can choose from 6 levels of engine braking force.
• A lower shift range will provide greater engine braking force than a higher
shift range, and the engine speed will also increase.

27
ES350_QG_OM33B82U_(U)
Turn Signal Lever
Right turn
Lane change to the right (move the
lever partway and then release it)
The right hand signals will flash 3
times.
Lane change to the left (move the
lever partway and then release it)
The left hand signals will flash 3
times.
Left turn1
2
3
4
n Customization
The number of times the turn signals flash during a lane change can be changed.

28
ES350_QG_OM33B82U_(U)
Multi-information Display
Drive information
Select to display various drive data.
Navigation system-linked display (if equipped)
Select to display the following navigation system-linked information.
• Route guidance
• Compass display (north-up display/heading-up display)
Audio system-linked display
Select to enable selection of an audio source or track on the display
using the meter control switches.
Driving assist information
Select to display the cruise contro l or dynamic radar cruise control/
LDA (Lane Departure Alert with st eering control) information, when
the system is used. ( →P.37, 39, 43)
Warning message display
Select to display warning messages and measures to be taken if a mal-
function is detected.
Settings display
Select to change the meter display settings.
The multi-information display presents the driver with a variety of vehicle data.

29
ES350_QG_OM33B82U_(U)
nOperating the meter control switches
The multi-information display is oper-
ated using the meter control switches.
Select an item/change pages
Enter/Set
Return to the previous screen
Press:
Displays the screen registered to
When no screen has been regis-
tered, the drive information screen
will be displayed.
Press and hold:
Registers the currently displayed
screen to
The registration confirmation
screen is displayed. If the selected
screen cannot be registered, a regis-
tration failure message will be
shown.
1
2
3
4
If a problem is detected in any of th e vehicle’s systems, a warning message is
shown on the multi-information display.

30
ES350_QG_OM33B82U_(U)
Eco Driving Indicator
Eco Driving Indicator Light
During Eco-friendly acceleration
(Eco driving), the Eco Driving Indi-
cator Light will turn on. When the
acceleration exceeds the Zone of
Eco driving, or when the vehicle is
stopped, the light turns off.
Eco Driving Indicator Zone Dis-
play
Suggests the Zone of Eco driving
with current Eco driving ratio based
on acceleration.
Eco driving ratio based on accelera-
tion
If the acceleration exceeds the Zone
of Eco driving, the right side of the
Eco Driving Indicator Zone Dis-
play will illuminate.
When this happens, the Eco Driv-
ing Indicator Light will turn off.
Zone of Eco driving
Eco Driving Indicator will not operate
under the following conditions:
l The engine is not running.
l The shift lever is in any position other than D.
l Neither normal mode nor Eco drive mode is selected. ( →P. 4 6 )
l The vehicle speed is approximately
80 mph (130 km/h) or higher.
Settings of the display and non-display
of the Eco Driving Indicator Light can
be changed.1
2
3
4

31
ES350_QG_OM33B82U_(U)
Headlights
The side marker, parking,
daytime running, tail, license
plate and instrument panel
lights turn on.
The headlights, parking and
all lights listed above (except
daytime running lights) turn
on.
The headlights, daytime
running lights and all the
lights listed above turn on
and off automatically.
(When the engine switch is
in IGNITION ON mode.)
Off
The daytime running lights
turn on.
nTurning on the high beam headlights
With the headlights on, push the
lever away from you to turn on the
high beams.
Pull the lever toward you to the
center position to turn the high
beams off.
Pull the lever toward you and
release it to fl ash the high beams
once.
You can flash the high beams with
the headlights on or off.
n AFS (Adaptive Front-lighting System) (if equipped)
AFS (Adaptive Front-lighting System) improves visibility at intersections and on
curves by automatically ad justing the lateral angle of the headlights according to
vehicle speed and the degree of the tire angle that are controlled by steering input.
Operates at speed of 6 mph (10 km/h) or higher.
nDeactivating AFS
Select “AFS” on (settings display) of the multi-information display.
(Canada)
(U.S.A
1
2
3
4
(U.S.A
(Canada)
1
2
1

32
ES350_QG_OM33B82U_(U)
Press the meter control switch.2
