2016 Lexus ES350 Quick Guide /

17
ES350_QG_OM33B82U_(U)
Front Seats
nAdjustment procedure
Seat position adjustment switch
Seatback angle adjustment switch
Seat cushion (front) angle adjust-
ment switch Vertical height adjustment switch
Lumbar support adjustment switch
Seat cushion length adjustment
switch (if equipped for driver’s
side)1
2
3
4
5
6

18
ES350_QG_OM33B82U_(U)
Head Restraints
nFront seats
Vertical adjustment
Up
Pull the head restraints up.
Down
Push the head restraint down while
pressing the lock release button.
Horizontal adjustment
The position of the head restraint can be
adjusted forwar d in 4 stages.
If the head restraint is pulled forward
from the foremost position, it will
return to the rearmost position.
n Rear seats
Lock release but-
1
2
Outboard Center
Up
Pull the head restraints up.
Down
Push the head restraint down while pressing the lock release button.
Lock release but-Lock release but-
1
2

19
ES350_QG_OM33B82U_(U)
Driving Position Memory (if equipped)
nDriving position memory
n
Recording procedure
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Adjust the driver’s seat, steering wheel, and outside rear view mirrors to the
desired positions.
While pressing the “SET” button, or
within 3 seconds af ter the “SET” button
is pressed, press button “1”, “2” or “3”
until the buzzer sounds. If the selected button has already
been preset, the previously recorded
position will be overwritten.
nRecall procedure
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Press one of the buttons for the driving
position you want to recall until the
buzzer sounds.
This feature automatically adjusts the front seats, steering wheel (power adjust-
ment type) and outside rear view mirrors to suit your preferences.
1
2
3
4
1
2
3

20
ES350_QG_OM33B82U_(U)
nMemory recall function (driver’s side only)
Each electronic key can be registered to recall your preferred driving position.
nRegistering procedure
Check that the shift lever is in P.
Turn the engine switch to IGNITION ON mode.
Recall the driving position that you want to record.
While pressing the recalled button,
press and hold the door lock switch
(either lock or unlock) until the buzzer
sounds. If the button could not be registered,
the buzzer sounds continuously for
approximately 3 seconds.1
2
3
4

21
ES350_QG_OM33B82U_(U)
Outside Rear View Mirrors
Selects a mirror to adjust (“L”: left
or “R”: right)
Adjust the mirror up, down, in or
out using the switch
nFolding the mirrors
Push the mirror back in the direction of
the vehicle’s rear.
n Linked mirror function when reversing
When the mirror select switch is in the L or R position, the outside rear view mirrors
will automatically angle downwards when the vehicle is reversing in order to give a
better view of the ground.
To disable this function, move the mirror select switch to the neutral position
(between L and R).
nAdjusting the mirror angle when the vehicle is reversing
With the shift lever in R, adjust the mirror angle at a desired position. The adjusted
angle will be memorized and the mirror will automatically tilt to the memorized
angle whenever the shift lever is shifted to R from next time.
The memorized downward tilt position of the mirror is linked to the normal posi-
tion (angle adjusted with the shift lever in other than R). Therefore, if the normal
position is changed after adjustment, the tilt position will also change. When the
normal position is changed, readjust the angle in reversing.
1
2

22
ES350_QG_OM33B82U_(U)
Engine (Ignition) Switch
nStarting the engine
Check that the parking brake is set.
Check that the shift lever is set in P.
Firmly depress the brake pedal.
will be displayed on the
multi-information display. If it is
not displayed, the engine cannot
be started.
Press the engine switch. The engine will crank until it
starts or for up to 30 seconds,
whichever is less.
Continue depressing the brake
pedal until the engine is com-
pletely started.
The engine can be started from
any engine switch mode.
Performing the following operations wh en carrying the electronic key on your
person starts the engine or changes engine switch modes.
1
2
3
4

23
ES350_QG_OM33B82U_(U)
nStopping the engine
Stop the vehicle.
Shift the shift lever to P.
Set the parking brake.
Press the engine switch.
Release the brake pedal and check that “POWER ON” on the multi-information
display is off.
n Changing engine switch modes
Modes can be changed by pressing the engi ne switch with the brake pedal released.
(The mode changes each time the switch is pressed.)
Off
*
The emergency flashers can be used.
ACCESSORY mode Some electrical components such as
the audio system can be used.
“POWER ON” will be displayed on
the multi-information display.
IGNITION ON mode All electrical components can be
used.
“POWER ON” will be displayed on
the multi-information display.
*: If the shift lever is in a position other
than P when turning off the engine,
the engine switch will be turned to
ACCESSORY mode, not to off.
1
2
3
4
5

24
ES350_QG_OM33B82U_(U)
nIf your vehicle has to be stopped in an emergency
Only in an emergency, such as if it b ecomes impossible to stop the vehicle in the
normal way, stop the vehicle using the following procedure:
Steadily step on the brake pedal with both feet and firmly depress it.
Do not pump the brake pedal repeatedly as this will increase the effort required
to slow the vehicle.
Shift the shift lever to N.
If the shift lever is shifted to N
After slowing down, stop the vehicle in a safe place by the road.
Stop the engine.
If the shift lever cannot be shifted to N
Keep depressing the brake pedal with both feet to reduce vehicle speed as much
as possible. To stop the engine, press and hold the
engine switch for 2 consecutive seconds
or more, or press it briefly 3 times or
more in succession.
Stop the vehicle in a safe place by the road.
1
2
3
4
3
Press and hold for 2 seconds or
more
4
5
