2016 FORD EXPEDITION Quick Reference Guide

fuel pressure glove box night vision ground clearance technical specifications inflation pressure

Page 1 of 10

FORD EXPEDITION 2016 3.G Quick Reference Guide owner.ford.comford.ca2016
Quick Reference Guide

EXPEDITION
This Quick Reference Guide is not intended to
replace your vehicle Owner’s Manual which
contains more detailed information concerning

Page 2 of 10

FORD EXPEDITION 2016 3.G Quick Reference Guide page no. thre e
BASIC COMMANDS
• Main menu
• Go back
• Cancel
• List of commands
• Next page
• Previous page
• Help
NAVIGATION *
• Navigation list of commands
•

Page 3 of 10

FORD EXPEDITION 2016 3.G Quick Reference Guide inStrument panel
2
5
1
6
8
7
9
1| WINDSHIELD WIPERS AND WASHERS
Rotate the end of the control away from you to increase the
wiper speed and toward you to decrease the wiper speed.
To use the washer

inStrument panel
2
5
1
6
8
7
9
1| WINDSHIELD WIPERS AND WASHERS
Rotate the end of the control away from you to increase the
wiper speed and toward you to decrease the wiper speed.
To use the washer feature, push the end of the lever.
To operate the rear window wiper, rotate the control.
For a rear wash cycle, rotate and hold the rear wiper control
to either the top or bottom position.
Note: For optimal wiper performance, clean your blades and
glass regularly.
2 | LIGHTING CONTROL
Switches off the headlamps.
Switches the parking lamps on.
Switches the headlamps on.
Autolamps: Automatically turns the exterior lamps on in
low light situations.
Pull the control toward you to switch the fog lamps on.
3 | INSTRUMENT LIGHTING DIMMER
Press and hold the top of the control to switch on the
interior courtesy lamps. Press and hold the bottom of the
control to switch off the interior lamps.
4 | POWER -ADJUSTABLE FOOT PEDALS *
lets you move your brake and accelerator pedals. Press the
arrow to move the pedals closer to you or the arrow to move
the pedals away from you. Adjust the pedals only after you
stop the vehicle and place the transmission in park (P).
5 | TILT AND TELESCOPING STEERING COLUMN *
lets you adjust the position of the steering column. Use the
4-way control on the side of the steering column. The column
automatically moves to the full up position when you switch
the ignition off. It returns to the previous position when you
switch the ignition on. You can switch this feature off in the
information display. For more details about your information
display functions, please see your Owner’s Manual.
6| LEFT VEHICLE INFORMATION DISPLAY
provides important vehicle information through a constant
monitoring of vehicle systems. The system notifies you of
potential vehicle problems by displaying system warnings
followed by a long indicator tone.
Use the left-hand, 5-way controls on your steering wheel to
scroll through, highlight and make minor adjustments within a
selected menu.
For more details about your information display functions,
refer to your Owner’s Manual.
7| CRUISE CONTROL
To set the speed
A. Press and release ON.
B. Accelerate to the desired speed.
C. Press SET+ and take your foot off the accelerator.
To set a higher or lower speed, either press and hold or press
SET+ or SET– repeatedly until you reach the desired speed.
To cancel a set speed, tap the brake pedal. The set speed will
not be erased.
To return to a previously set speed, press RSM. To switch off,
press OFF or switch the ignition off.
8| SERVICE ENGINE SOON LIGHT
lights briefly when you switch the ignition on. If it
remains on or blinks after you start the engine, the On-Board
Diagnostics (OBD-II) system detects a problem. Drive in a
moderate fashion and contact an authorized dealer as soon
as possible.
3
6
101113
4
12
14
ABC
page no. fo ur*if equipped
9
page no. five

Page 4 of 10

FORD EXPEDITION 2016 3.G Quick Reference Guide 12| CONTROLS * (CONTINUED )
TRAILER SWAY CONTROL* applies your vehicle brakes at
individual wheels and, if necessary, reduces engine power. If
the trailer begins to sway, the stability control light

12| CONTROLS * (CONTINUED )
TRAILER SWAY CONTROL* applies your vehicle brakes at
individual wheels and, if necessary, reduces engine power. If
the trailer begins to sway, the stability control light flashes
and the message TRAILER SWAY REDUCE SPEED appears
in the information display. The first thing to do is slow down
your vehicle, then pull safely to the side of the road and check
for proper tongue load and trailer load distribution. For more
information, please refer to the Towing chapter in your
Owner’s Manual.
13 | INTEGRATED TRAILER BRAKE CONTROLLER *
assists in smooth and effective trailer braking by powering
the trailer’s electric or electric over hydraulic brakes with a
proportional output based on the towing vehicle’s
brake pressure.
Use the GAIN adjustment buttons to increase or decrease the
braking feature’s power output to the trailer.
Adjust the GAIN by pressing the GAIN + or GAIN – buttons to
increase or decrease the setting to the desired starting point.
A GAIN setting of 6.0 is a good starting point for heavier loads.
To test the adjusted GAIN setting:
• In a traffic-free environment, tow the trailer on a dry,
level surface at a speed of 20-25 mph (30-40 km/h) and
squeeze the manual control lever completely.
• If the trailer wheels lock up (the tires will squeal), reduce
the GAIN setting. If the trailer wheels turn freely, increase
the GAIN setting.
• The proper GAIN setting will be at the point just below
trailer wheel lock-up. If towing a heavier trailer, trailer
wheel lockup may not be attainable even with the
maximum GAIN setting of 10.
For more information, please refer to the Towing chapter in your
Owner’s Manual.
14 | FOUR -WHEEL DRIVE (4W D )*
operates in four modes for a variety of road conditions:
2H (4X2) mode delivers power to the rear wheels only, that is
appropriate for normal, on-road driving on dry pavement and
provides the best fuel economy.
4A (4X4 AUTO) mode provides electronic control four-wheel
drive with power delivered to all four wheels, as required, for
increased traction. This mode is appropriate for all on-road
driving conditions, such as dry road surfaces, wet pavement,
snow and gravel.
4H (4X4) mode provides electronically locked four-wheel drive
power to all four wheels. This position is not recommended for
use on dry pavement and is only intended for severe winter or
off-road conditions, such as deep snow, ice or shallow sand.
4L (4X4) mode provides electronically locked four-wheel
drive when extra power at reduced speeds is needed. Use this
mode for off-road, low-speed operation, such as climbing steep
grades, pulling a boat out of the water and more. Refer to the
Four-Wheel Drive (4WD) chapter in your Owner’s Manual.
inStrument panel (co ntinued )
page no. six*if equipped*if equippedpage no. seven
9| RIGHT VEHICLE INFORMATION DISPLAY *
provides various information about important vehicle systems.
Use the right-hand, 5-way controls located on your steering
wheel to scroll through, highlight and make minor adjustments
within a selected menu. For more information, see your
SYNC Supplement.
10 | STEERING WHEEL CONTROLS
Press VOL+ or VOL– to increase or decrease your volume level.
Press
to access the previous or next radio station,
CD track or preset satellite radio channel.
Press OK repeatedly to access all possible media sources.
Press
to access voice recognition*.
Press
to access SYNC® phone features.
Note: Some of your steering wheel media controls may vary.
See the Steering Wheel chapter in your Owner’s Manual for
more details.
11| PUSH BUTTON START *
allows you to start your vehicle by pressing the START STOP
button while fully pressing down on the brake pedal. If you
leave your vehicle idling for an extended period of time, it
automatically shuts down. Before the engine shuts down, a
message appears in the information display, allowing the driver
to override the shutdown feature. Press the button again to
switch the engine off.
Note: Your intelligent access transmitter must be inside the
vehicle for the ignition to start. Keyless warning alert sounds the
horn twice when you exit the vehicle with the intelligent access
transmitter and the keyless vehicle is on.
12| CONTROLS *
A. POWER LIFTGATE CONTROL* lets you open or close
your power liftgate from inside your vehicle. To use,
press the control.
B. HILL START ASSIST keeps your vehicle stationary long
enough to move your foot from the brake pedal to the
accelerator pedal when your vehicle is on a slope. Press
the control to switch this feature off. It turns back on
automatically after you re-start your vehicle.
C. STABILITY CONTROL WITH RSC
® (ROLL STABILITY
CONTROL™) automatically activates when you start your
engine and helps you keep control of your vehicle when on
a slippery surface. The electronic stability control portion
of the system helps avoid skids and lateral slides, while
the roll stability control helps avoid a vehicle rollover. The
traction control system helps avoid drive wheel spin and
loss of traction.

Page 5 of 10

FORD EXPEDITION 2016 3.G Quick Reference Guide 15| HAZARD CONTROL
16| AUDIO SYSTEM CONTROLS
A. EJECT: Press to eject a CD.
B. CD SLOT: Insert a CD.
C. VOL and SYSTEM POWER: Press to switch the system on
and off. Rotate the control to adjust

Page 6 of 10

FORD EXPEDITION 2016 3.G Quick Reference Guide Getting Started with Your SYNC System
SYNC is a hands-free, voice recognition system used
for entertainment, information and communication.
SYNC. Say the Word.BEFORE YOU GET STARTED
1. Set up you

Getting Started with Your SYNC System
SYNC is a hands-free, voice recognition system used
for entertainment, information and communication.
SYNC. Say the Word.BEFORE YOU GET STARTED
1. Set up your owner account at owner.ford.com (U.S.)
or SyncMyRide.ca (Canada). Register by following the
on-screen instructions. After registering, you can receive the
latest system software updates and choose how you want
to receive them: via your personal computer or device, or
through the SYNC 3 system to deliver automatic updates.
2. SYNC uses a wireless connection called
Bluetooth® to
communicate with your phone. Switch on Bluetooth mode in
your phone’s menu options. This lets your phone find SYNC.
3. You can also enjoy free customer service. For more details on setting up your account, visit owner.ford.com (U.S.) or
SyncMyRide.ca (Canada).
PAIRING YOUR PHONE WITH SYNC
Note: If you have SYNC 3*, see the pairing instructions on page 12.
In order to use the many features of SYNC, such as making a
phone call, you must first connect or pair your phone
with SYNC.
TO PAIR YOUR PHONE FOR THE FIRST TIME
1. Make sure that your vehicle is in park (P), then switch on your
ignition and radio.
2. Press the phone button
. When the display indicates No
Phone Found, press OK.
3. When Add Bluetooth Device? appears in the display, press OK.
4. When Find SYNC appears in the display, press OK. When
prompted on your phone’s display, enter the PIN provided by
SYNC into your phone.
5. The display indicates when the pairing is successful.
Note: The system may prompt you to — • Set your phone as the primary or favorite (the primary phone
receives messages and voicemail).
• Download your phone book (required to use the full set of
voice commands).
• Switch on 911 Assist
®.
TIPS
• Make sure you accept the request from SYNC to access
your phone.
• To pair subsequent phones, please refer to Pairing
Subsequent Phones in the SYNC chapter of your
Owner’s Manual.
SYNC®*
USING YOUR PHONE WITH SYNC
Note: You must download your phone book to make phone
calls with voice commands by name.
MAKING A PHONE CALL
Use SYNC to make a phone call to anyone in your phone book
by pressing the button and when prompted, say any of the
following voice commands:
Call Call at work
Call on cell Call at home
For example, you could say “Call Jake Smith at home”. SYNC
repeats the command back to you and dials the number.
Note: You can also make phone calls by pressing the

button. When prompted, say the voice command “Dial”,
then verbally say the phone number.
ANSWERING INCOMING CALLS
Whenever you have an incoming call, the name and number
of the person calling appears in your display. Press the phone
button
to answer an incoming call. You can hang up at any
time by pressing and holding the phone button .
USING SYNC TO ACCESS DIGITAL MEDIA
SYNC has a media hub with multiple inputs allowing you to
access personal media from your digital devices. Plug in your
USB media devices such as phones and MP3 players and use
SYNC to play all of your favorite music. Wait for the system to
finish indexing your music to begin listening.
Using voice commands to play music
1. Plug your media player into your USB port.
2. Press the
button. When prompted, say
“USB”, then follow-up saying one of the following
voice commands:
“Play all” “Play next ”
“Play ” “Play ”
3. The system repeats your command and then plays
your selection.
page no. ten*if equippedpage no. eleven

Page 7 of 10

FORD EXPEDITION 2016 3.G Quick Reference Guide SYNC® 3*
page no. twelve*if equipped
A Revo lutio nary Way to Co nnect with Yo ur Vehicle.
PAIRING YOUR PHONE
WITH SYNC 3
Pair your phone to SYNC before using SYNC 3.
Make sure that your vehicle is

SYNC® 3*
page no. twelve*if equipped
A Revo lutio nary Way to Co nnect with Yo ur Vehicle.
PAIRING YOUR PHONE
WITH SYNC 3
Pair your phone to SYNC before using SYNC 3.
Make sure that your vehicle is in park (P) and
you switch on both your ignition and radio.
1. Make sure that you switch on Bluetooth in
your cellular phone. This lets your phone
find SYNC.
2. Touch Add Phone on the touchscreen.
3. Select SYNC on your device. A six-digit PIN
appears on your device.
4. If your device prompts you to enter a PIN,
enter the PIN displayed on the touchscreen.
Skip the next step.
5. When prompted on your phone’s display,
confirm that the PIN provided by SYNC 3
matches the PIN displayed on your
cellular phone.
6. The display indicates when the pairing
is successful.
Use the touchscreen to explore and interact with your vehicle. The touch\
screen works the same way traditional controls, knobs

and buttons do. Press the various areas on your touchscreen to personali\
ze the many features and settings of your vehicle all in
one place. The system provides easy interaction with your audio, climate\
, phone, navigation*, mobile apps and settings.
GET IN TOUCH USING YOUR TOUCHSCREEN
Use the feature bar at the bottom of the touchscreen to access the many \
features of SYNC 3.
Phone
After pairing your phone, you can access
more phone-dependent features:
• Recent call lists.
• Contacts: Sort alphabetically and
choose a specific letter to begin
viewing your entries.
• Phone settings: Pair another phone,
and set ring tones and alerts.
• Text messages.
• Do not disturb: Send all calls to your
voice mail, and all ring tones and
alerts set to silent mode.
Note: Use the voice commands to make
calls. Say “Call James at home” or “Dial
555-1212”. You can use the touchscreen
to place calls as well. Refer to the SYNC
Supplement for complete details.
navigation*
Press the navigation* icon to set your
destination. Select one of two ways to
find your destination: • Destination mode lets you key in a
specific address or use a variety of
search methods to locate where you
want to go.
• Map mode shows advanced viewing
of 2D city maps, 3D landmarks and
3D city models (when available).
See your SYNC Supplement for details.
SET A DESTINATION
Press Destination on your touchscreen
and then press Search. Enter a street
address, intersection, city or a point of
interest (POI).
You can also use voice commands. Say
“Find a point of interest” and then select a
category, such as hotels or restaurants.
After you choose your destination, press
Start. The system uses a variety of
screens and visible prompts to guide
you to your destination.
The navigation map shows your
estimated time of arrival, remaining travel
time and the distance to your destination.
NAVIGATION MENU
During active navigation, touch the
bottom of the screen to view the menu,
and then select Screen View.
• Full Map.
• Highway Exit Info displays on the
right side of the touchscreen. View
POI icons (restaurants, ATMs, etc.)
as they pertain to each exit. You
can select a POI as a waypoint, if
you wish.
• Turn List shows all of the available
turns on your current route.
• Traffic List displays SiriusXM Traffic
and Travel Link* information.
*if equippedpage no. thirte en

Page 8 of 10

$FORD EXPEDITION 2016 3.G Quick Reference Guide comfort SEATING-TO -CARGO VERSATILITY Note: Before folding the second- or third-row seats, make sure to flip down th\ e head restraints by pulling on the strap, and remove all items from the floor \$

comfort
SEATING-TO -CARGO VERSATILITY
Note: Before folding the second- or third-row seats, make sure to flip down th\
e head
restraints by pulling on the strap, and remove all items from the floor \
and seats.
TO FOLD THE FLAT
-FOLDING SECOND-ROW SEATS TO
THE LOAD FLOOR
Pull up on the handle located behind the seatback while pushing the seat\
back
forward and down into the seat cushion.
Note: You may need to exert a moderate force to move the seat forward and dow\
n.
TO RETURN THE SEATS TO AN UPRIGHT
SEATING POSITION
Lift and pull the seat rearward until the latch engages fully.
E -Z ENTRY INTO THE THIRD -ROW SEATS
The E-Z entry seat allows for easier entry and exit to and from the thir\
d-row seat.
To enter the third-row seating area
1. Fold the head restraint forward.
2. Pull up on lever 1.
3. Fold down the second-row seat and release the handle.
4. Pull the handle up again until the seat releases from the floor.
5. Push the seat upward and fold it away from the third row.
Pull StrapHandle
Lever 1 Position 2 Position 3
To return the seat to an upright seating position
1. Push the seat down and latch it to the floor.
2. Bring the seatback to an upright position. It
should lock into position.
3. Lift up on the head restraint until it locks into
its original position.
*if equippedpage no. fifte en
Climate
Access climate control features, including
the temperature, airflow direction, fan
speed and other climate features for you
and your front passenger.
SET YOUR TEMPERATURE
• Touch the Climate icon on
the touchscreen.
• Use voice commands to change your
settings, like “Climate set temperature
to 72 degrees” and SYNC 3 makes
that adjustment.
• You can also use the
▲ or ▼ buttons
on the touchscreen.
audio
No matter how you store your music,
SYNC makes it yours to enjoy when you’re
behind the wheel. Just press the Audio
icon on the touchscreen. From here, you
can easily go between AM/FM, SiriusXM
and other media sources.
SET YOUR RADIO PRESETS
• Tune to the station and then press
and hold one of the memory preset
buttons. The audio mutes briefly
while the system saves the station,
and then the audio returns.
• Two preset banks are available for
AM and three banks for FM. To access
additional presets, tap the preset
button. The indicator on the preset
button shows which bank of presets
you are currently viewing.
BRING IN YOUR OWN MUSIC
Use SYNC 3 to play all of your favorite
music from phones, flash drives and
other devices.
Plug your device into a USB port, select
Sources and then choose USB. Wait for
the system to finish indexing your music
to begin listening. You can even create
random playlists by using the
Shuffle function.
Apps
STREAM APPS
The system supports the use of certain
types of apps such as Pandora® or
iHeartRadio® through a USB or Bluetooth-
enabled devices.
Each app gives you different on-screen
options depending on the app’s content.
For more information, refer to the SYNC
Supplement. For support, visit the website
or call the toll-free number.
See the inside front cover of this guide
for details.
SYNC® 3* ( co ntinued )
page no. fo urteen*if equipped

Load next 8 pages

Page: 1-8 9-16 next >

lumbar support tire pressure reset night vision charging service ground clearance
