2016 FIAT 500X keyless

(20 km/h). To make your selection, press the “Auto Door
Locks” button on the touchscreen and select from “On”
or “Off.”
•Auto Unlock On Exit
When this feature is selected, all doors will unlock when
the vehicle is stopped and the transmission is in the
PARK or NEUTRAL position and the driver’s door is
opened. To make your selection, press the “Auto Unlock
on Exit” button on the touchscreen and select from “On”
or “Off.”
• Flash Lights With Lock
When this feature is selected, the exterior lights will flash
when the doors are locked or unlocked with the Remote
Keyless Entry (RKE) transmitter or the Passive Entry
Feature. To make your selection, press the “Flash Lights
w/Lock” button on the touchscreen and select from “On”
or “Off.” •
Horn With Lock
When this feature is selected, the horn will sound when
the Key Fob Lock button is pressed. To make your
selection, press the “Horn w/Lock” button on the touch-
screen and select from Off,” “1st Press,” or “2nd Press”
• Horn With Remote Start — If Equipped
Press the “Horn w/Remote Start” button on the touch-
screen to change this display. When this feature is se-
lected, the horn will sound when the remote start is
activated. To make your selection, press the “Sound Horn
With Remote Start” button on the touchscreen and select
“ON” or “OFF.”
• Passive Entry
This feature allows you to lock and unlock the vehicle’s
door(s) without having to press the Remote Keyless
Entry (RKE) transmitter lock or unlock buttons. To make
your selection, press the “Passive Entry” button on the
526 MULTIMEDIA

touchscreen and select from “On” or “Off. Refer to
“Keyless Enter-N-Go” in “Getting To Know Your Ve-
hicle” for further information.
•Remote Door Unlock/Door Unlock
When “Driver” is selected, only the driver’s door will
unlock on the first push of the Remote Keyless Entry
(RKE) transmitter UNLOCK button, you must push the
RKE transmitter UNLOCK button twice to unlock the
passenger’s doors. When “All” is selected, all of the doors
will unlock on the first press of the RKE transmitter
UNLOCK button. NOTE:
If “All” is programmed, all doors will unlock no
matter which Passive Entry equipped door handle is
grasped. If “Driver” is programmed, only the driver ’s
door will unlock when the driver ’s door is grasped.
Touching the handle more than once will only result in
the driver ’s door opening once. If the driver door is
opened, the interior door lock/unlock switch can be used
to unlock all doors (or use RKE transmitter).
Engine Off Options
After pressing the “Engine Off Options” button on the
touchscreen the following settings will be available.
• Headlight Off Delay
When this feature is selected, the driver can choose to
have the headlights remain on for 0, 30, 60, or 90 seconds
when exiting the vehicle. To change the Headlight Off
Delay status press the “+” or “–” button on the touch-
screen to select your desired time interval.
11
MULTIMEDIA 527

•Flash Lights With Lock
When this feature is selected, the exterior lights will flash
when the doors are locked or unlocked with the Remote
Keyless Entry (RKE) transmitter. This feature may be
selected with or without the Sound Horn on Lock feature
selected. To make your selection, press the “Flash Lights
with Lock” button on the touchscreen, then choose “On”
or “Off.”
• Headlights With Wipers — If Equipped
When this feature is selected, and the headlight switch is
in the AUTO position, the headlights will turn on ap-
proximately 10 seconds after the wipers are turned on.
The headlights will also turn off when the wipers are
turned off if they were turned on by this feature. To make
your selection, press the “Headlights With Wipers” but-
ton on the touchscreen, then choose “On” or “Off.”Doors & Locks
After pressing the “Doors & Locks” button on the touch-
screen the following settings will be available:
• Auto Door Locks
When this feature is selected, all doors will lock auto-
matically when the vehicle reaches a speed of 15 mph
(24 km/h). To make your selection, press the “Auto
Lock” button on the touchscreen, then choose “Yes” or
“No.” The button will highlight indicating that the set-
ting has been selected.
• Auto Unlock On Exit
When this feature is selected, all doors will unlock when
the vehicle is stopped and the transmission is in the
PARK or NEUTRAL position and the driver’s door is
opened. To make your selection, press the “Auto Lock On
542 MULTIMEDIA

Exit” button on the touchscreen, then choose “Yes” or
“No.” The button will highlight indicating that the set-
ting has been selected.
•Flash Lights With Lock
When this feature is selected, the exterior lights will flash
when the doors are locked with the Remote Keyless
Entry (RKE) transmitter. To make your selection, press
the “Flash Headlights With Lock” button on the touch-
screen, then choose “Yes” or “No.” The button will
highlight indicating that the setting has been selected.
• Sound Horn With Lock
When this feature is selected, the horn will sound when
the door locks are activated. To make your selection,
press the “Sound Horn With Remote Lock” button on the
touchscreen, then choose “1st Press” “2nd Press” or
“Off.” The button will highlight indicating that the
setting has been selected. •
Sound Horn With Remote Start
When this feature is selected, the horn will sound when
the Remote Start is activated. To make your selection,
press the “Sound Horn With Remote Start” button on the
touchscreen, then choose “On” or “Off.” The button will
highlight indicating that the setting has been selected.
• Remote Door Unlock
This feature will allow you to program your remote door
locks to open “All” or only the “Driver” with the first
push of the Remote Keyless Entry (RKE) transmitter or
grabbing the Passive Entry door handle. To make your
selection, press the “Remote Door Unlock” button on the
touchscreen and choose from “All” or “Driver.”
NOTE: If “Driver Door” is selected, the (RKE) transmitter
will have to be pushed two times in order to unlock all
doors.
11
MULTIMEDIA 543

•Passive Entry
This feature allows you to lock and unlock the vehicles
door(s) without having to press the Remote Keyless
Entry (RKE) transmitter lock or unlock buttons. To make
your selection, press the “Passive Entry” button on the
touchscreen, then choose “On” or “Off.” The button will
highlight indicating that the setting has been selected.
• Memory Linked To Key Fob — If Equipped
This feature provides automatic driver seat positioning to
enhance driver mobility when entering and exiting the
vehicle. To make your selection, press the “Memory
Linked To Key Fob” button on the touchscreen and select
from “On” or “Off.” NOTE:
The seat will return to the memorized seat
location (if Recall Memory with Remote Key Unlock is set
to ON) when the Remote Keyless Entry (RKE) transmitter
is used to unlock the door.
Engine Off Options
After pressing the “Engine Off Options” button on the
touchscreen the following settings will be available:
• Radio Off Delay
When this feature is selected, the radio will stay on for a
preset time after the ignition key is turned to STOP/OFF.
To change the Radio Off Delay status, press the “0 MIN”
or “20 MIN” button on the touchscreen to select your
desired time interval.
544 MULTIMEDIA

Cooling System.......................... .458
Adding Coolant (Antifreeze) ...............460
Coolant Capacity ...................... .509
Coolant Level ..................... .458, 463
Disposal Of Used Coolant .................462
Drain, Flush, And Refill ...................459
Inspection ........................... .463
Points To Remember ..................462, 463
Pressure Cap ......................... .462
Selection Of Coolant (Antifreeze) ......459, 509, 510
Corrosion Protection ...................... .469
Cupholders ............................ .153
Customer Assistance ........................10
Customer Programmable Features .............517
Data Recorder, Event ...................... .240
Daytime Running Lights .....................94
Dealer Service ........................... .432
Defroster, Rear Window ..............106, 112, 125 Defroster, Windshield
................111, 124, 265
Dimmer Switch, Headlight ...................95
Disabled Vehicle Towing ....................419
Disposal Antifreeze (Engine Coolant) ................462
Door Locks Door Locks ............................52
KeyFob...............................52
Remote ...............................52
Remote Keyless Entry (RKE) ................52
Driver’s Seat Back Tilt .......................64
Driving Through Flowing, Rising, Or Shallow Standing
Water ............................... .347
Electrical Outlet, Auxiliary (Power Outlet) ........147
Electric Park Brake ....................... .279
Electric Parking Brake ..................... .279
12
INDEX 571

Introduction..............................4
Jacking Instructions ....................... .394
Jack Location ........................... .391
Jack Operation .....................390, 394, 476
Jump Starting ........................... .406
Key Fob Arm The Alarm .........................50
Keyless Entry ...........................55
Keyless Enter-N-Go Enter The Trunk .........................55
KeyFob...............................55
Lock The Vehicle’s Doors ...............55, 542
Passive Entry ...........................55
Passive Entry Programming .............55, 542
Remote Control .........................55
Unlock From The Driver’s Side ..............55
Unlock From The Passenger Side .............55Unlock Liftgate
........................ .542
Keyless Entry System .....................30, 31
Key, Replacement ..........................37
Keys ...................................38
Key, Sentry (Immobilizer) ....................47
Lane Change And Turn Signals ................96
LaneSense ............................. .321
Lap/Shoulder Belts ........................211
Latches ............................... .267
Lead Free Gasoline ....................... .335
Leaks, Fluid ............................ .267
Life Of Tires ............................ .497
Liftgate Window Wiper/Washer ...............106
Light Bulbs ............................. .267
Lights ................................ .267
AirBag ...........................237, 264
Automatic Headlights .....................93
Daytime Running ........................94
12
INDEX 575

Pregnant Women And Seat Belts...............220
Preparation For Jacking .....................393
Pretensioners Seat Belts ............................ .221
Radial Ply Tires ......................... .492
Radio Operation ......................... .551
Rain Sensitive Wiper System .................104
Rear Camera ........................... .327
Rear Cross Path ...........................88
Rear ParkSense System .....................316
Rear Window Defroster .....................106
Rear Wiper/Washer ....................... .106
Recorder, Event Data ...................... .240
Recreational Towing ...................... .351
Reformulated Gasoline .....................336
Refrigerant ............................. .452
Reminder, Lights On ........................95
Reminder, Seat Belt ....................... .209Remote Control
Starting System .........................43
Remote Keyless Entry (RKE) ................30, 31
Arm The Alarm .........................50
Keyless Enter-N-Go ......................55
Remote Sound System (Radio) Controls .........549
Remote Starting Exit Remote Start Mode ...................46
Uconnect Customer Programmable Features .....46
Uconnect Settings ........................46
Remote Starting System ......................43
Replacement Keys .........................37
Replacement Parts ........................ .432
Replacement Tires ........................ .497
Reporting Safety Defects .....................13
Restraint, Head ...........................72
Restraints, Child ......................... .241
Restraints, Occupant ...................... .207
Roll Over Warning ..........................7
578 INDEX
