2016 FIAT 500X radio controls

General Information
This vehicle has systems that operate on radio frequency
that comply with Part 15 of the Federal Communications
Commission (FCC) rules and with Industry Canada
Standards RSS- GEN/210/220/310.
Operation is subject to the following two conditions:
1. The device may not cause harmful interference.
2. The device must accept any interference received,including interference that may cause undesired op-
eration of the device.
Changes or modifications to any of these systems by
other than an authorized service facility could void
authorization to use this equipment.
EXTERIOR LIGHTS
Headlights
The headlight switch is located on the left side of the
instrument panel. The headlight switch controls the
operation of the headlights, side marker lights, daytime
running lights, fog lights and the dimming of the instru-
ment cluster and interior lighting.
92 GETTING TO KNOW YOUR VEHICLE

MULTIMEDIA
CONTENTS
UCONNECT SETTINGS ..................515
▫ Buttons On The Faceplate ................516
▫ Buttons On The Touchscreen ..............517
▫ Customer Programmable Features — Uconnect 5.0
Settings ........................... .517
▫ Customer Programmable Features — Uconnect
6.5AN Settings ...................... .531
 UCONNECT RADIOS ...................548
 USB/MEDIA PLAYER CONTROL — IF
EQUIPPED .......................... .548
 STEERING WHEEL AUDIO CONTROLS ......549▫
Radio Operation ..................... .550
▫ Media Mode ........................ .551
 RADIO OPERATION AND MOBILE DEVICES . .551
▫ Regulatory And Safety Information .........551
 UCONNECT VOICE RECOGNITION
QUICK TIPS ......................... .553
▫ Introducing Uconnect ...................553
▫ Get Started ......................... .554
▫ Basic Voice Commands ..................556
▫ Radio ............................. .557
11

UCONNECT RADIOS
For detailed information about your Uconnect radio,
refer to your Uconnect Supplement Manual.
USB/MEDIA PLAYER CONTROL — IF EQUIPPED
This feature allows an external device to be plugged into
the USB port or AUX Jack.Located below the heating ventilation and air condition-
ing controls is the front USB port.
Front USB Port And AUX Jack
1 — AUX/Cable Jack
2 — USB Port
548 MULTIMEDIA

Refer to the Uconnect Radio Supplement for external
USB support capability.
Center Console USB Port
Located in the center console is a second USB port.
NOTE:Depending on vehicle configuration, the USB
port may be charge only, or media file capable.
STEERING WHEEL AUDIO CONTROLS
The remote sound system controls are located at the rear
of the steering wheel. Reach behind the wheel to access
the switches.
Center Console USB (Charge Only) Port — If Equipped
11
MULTIMEDIA 549

The right-hand control is a rocker-type switch with a
pushbutton in the center and controls the volume and
mode of the sound system. Pushing the top of the rocker
switch will increase the volume, and pushing the bottom
of the rocker switch will decrease the volume.Pushing the center button will make the radio switch
between the various modes available (AM/FM/SAT/
AUX/Media Player, etc.) and can also be used to select/
enter an item while scrolling through menu.
The left-hand control is a rocker-type switch with a
pushbutton in the center. The function of the left-hand
control is different depending on which mode you are in.
The following describes the left-hand control operation in
each mode.
Radio Operation
Pushing the top of the switch will “Seek” up for the next
listenable station and pushing the bottom of the switch
will “Seek” down for the next listenable station.
The button located in the center of the left-hand control
will tune to the next preset station that you have pro-
grammed in the radio preset button.Remote Sound System Controls (Back View Of Steering
Wheel)
550 MULTIMEDIA

Pregnant Women And Seat Belts...............220
Preparation For Jacking .....................393
Pretensioners Seat Belts ............................ .221
Radial Ply Tires ......................... .492
Radio Operation ......................... .551
Rain Sensitive Wiper System .................104
Rear Camera ........................... .327
Rear Cross Path ...........................88
Rear ParkSense System .....................316
Rear Window Defroster .....................106
Rear Wiper/Washer ....................... .106
Recorder, Event Data ...................... .240
Recreational Towing ...................... .351
Reformulated Gasoline .....................336
Refrigerant ............................. .452
Reminder, Lights On ........................95
Reminder, Seat Belt ....................... .209Remote Control
Starting System .........................43
Remote Keyless Entry (RKE) ................30, 31
Arm The Alarm .........................50
Keyless Enter-N-Go ......................55
Remote Sound System (Radio) Controls .........549
Remote Starting Exit Remote Start Mode ...................46
Uconnect Customer Programmable Features .....46
Uconnect Settings ........................46
Remote Starting System ......................43
Replacement Keys .........................37
Replacement Parts ........................ .432
Replacement Tires ........................ .497
Reporting Safety Defects .....................13
Restraint, Head ...........................72
Restraints, Child ......................... .241
Restraints, Occupant ...................... .207
Roll Over Warning ..........................7
