2016 DODGE VIPER Owners Manual

Driver Information Display (DID) Messages
•Front Seat Belts Unbuckled
• Driver Seat Belt Unbuckled
• Passenger Seat Belt Unbuckled
• Key Fob Battery Low
• Service Air Bag System
• ESC Status (ESC OFF, ESC ON, ESC SPORT, ESC
TRACK, RAIN MODE) — Refer to “Electronic Brake
Control System” in “Starting And Operating” for
further information.
• Oil Pressure Low
• Fuel Low
• Service Antilock Brake System
• Service Electronic Throttle Control •
Cruise Off
• Cruise Ready
• Cruise Set To XXX MPH
• Tire Pressure Screen With Low Tire Pressure Warnings
• Service Tire Pressure System
• Parking Brake Engaged
• Brake Fluid Low
• Service Electronic Braking System
• Engine Temperature Hot
• Battery Voltage Low
• Brake Wear
• Service Electronic Throttle Control
• Lights On
4
UNDERSTANDING YOUR INSTRUMENT PANEL 175

•Right Turn Signal Light Out
• Left Turn Signal Light Out
• Turn Signal On
• Service Air Bag System
• Service Air Bag Warning Light
• Driver Seat Belt Unbuckled
• Passenger Seat Belt Unbuckled
• Front Seat Belts Unbuckled
• Door Open
• Doors Open
• Park Brake EngagedDID Selectable Menu Items
Push and release the UPorDOWN arrow buttons until
the desired Selectable Menu icon is highlighted in the
DID.
Tachometer
Push and release the UPorDOWN arrow
button until the Tachometer icon is highlighted
in the DID. Push and release the RIGHTarrow
button to change the display between full
tachometer or tachometer with digital speedometer.
176 UNDERSTANDING YOUR INSTRUMENT PANEL

MPH To km/h
Push and release theUPorDOWN arrow button
until the MPH to km/h icon is highlighted in the
DID. Push and release the OKbutton to change
the display between MPH or km/h.
Vehicle Info (Customer Information Features)
Push and release the UPorDOWN arrow
button until the Vehicle Info icon is highlighted
in the DID. Push and release the RIGHTarrow
button to display the following information
submenus: Tire Pressure
Push and release the
UPorDOWN arrow button until
“Tire Pressure” is highlighted in the DID. Push and
release the RIGHTarrow button, and one of the follow-
ing will be displayed:
• If tire pressure is OKfor all tires a vehicle ICON is
displayed with tire pressure values in each corner of
the ICON.
• If one or more tires have low pressure, the tire pressure
values in each corner of the ICON with the pressure
value of the low tire displayed in a different color than
the other tire pressure value.
• If the Tire Pressure system requires service, “Service
Tire Pressure System” is displayed.
Tire PSI is an information only function and cannot be
reset. Push and release the LEFTarrow button to return
to the main menu.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 177

Refer to “Tire Pressure Monitoring System (TPMS)”
under “Starting and Operating” for further information.
Coolant Temperature
Push and release theUPorDOWN arrow button until
“Coolant Temperature” is highlighted in the DID. Push
and release the RIGHTarrow button, and the coolant
temperature will be displayed.
Oil Temperature
Push and release the UPorDOWN arrow button until
“Oil Temperature” is highlighted in the DID. Push and
release the RIGHTarrow button, and the oil temperature
will be displayed. Engine Hours
Push and release the
UPorDOWN arrow button until
“Engine Hours” is highlighted in the DID. Push and
release the RIGHTarrow button, and the engine hours
will be displayed.
Intake Air Temp.
Push and release the UPorDOWN arrow button until
“Intake Air Temp.” is highlighted in the DID. Push and
release the RIGHTarrow button, and the intake air
temperature will be displayed.
Current Torque
Push and release the UPorDOWN arrow button until
“Current Torque” is highlighted in the DID. Push and
release the RIGHTarrow button, and the current torque
will be displayed.
178 UNDERSTANDING YOUR INSTRUMENT PANEL

Current Power
Push and release theUPorDOWN arrow button until
“Current Power” is highlighted in the DID. Push and
release the RIGHTarrow button, and the current power
will be displayed.
Fuel Economy
Push and release the UPorDOWN arrow
button until the Fuel Economy icon is high-
lighted and the following will display:
Range To Empty (RTE)
Average Fuel Economy/Miles Per Gallon (MPG Bar-
graph)
Current Miles Per Gallon (MPG)
Trip A
Push and release the UPorDOWN arrow
button until the Trip A icon is highlighted in
the DID. The Trip A information will display
the following:
• Distance
• Average Speed
• Elapsed Time
Hold the RIGHTarrow button to reset all the informa-
tion.
4
UNDERSTANDING YOUR INSTRUMENT PANEL 179

TripB—IfEquipped
Push and releaseUPorDOWN arrow button
until the Trip B icon is highlighted in the DID.
The Trip B information will display the
following:
• Distance
• Average Speed
• Elapsed Time
Hold the RIGHTarrow button to reset all the informa-
tion.
Audio
Push and release the UPorDOWN arrow
button until the Audio display icon is high-
lighted in the DID. Push and release the
RIGHT arrow button to display the active
source.
Stored Messages
Push and release the UPorDOWN arrow
button until the Messages Menu item is high-
lighted in the DID. This feature shows the
number of stored warning messages. Pushing
the RIGHT arrow button will allow you to see what the
stored messages are.
When no messages are present, main menu icon will be a
closed envelope.
180 UNDERSTANDING YOUR INSTRUMENT PANEL

Screen Setup Driver Selectable Items
Upper Left
•None
• Compass
• Temperature
• Range To Empty (RTE)
• Average Fuel
• Current Fuel
• Trip A
• Trip B
• Elapsed Time
• Oil Pressure
• Oil Temperature •
Battery
• Coolant Temperature
Upper Right
• None
• Compass
• Temperature
• Range To Empty (RTE)
• Average Fuel
• Current Fuel
• Trip A
• Trip B
• Elapsed Time
• Oil Pressure
4
UNDERSTANDING YOUR INSTRUMENT PANEL 181

•Oil Temperature
• Battery
• Coolant Temperature
• RIGHT Arrow Button
Restore To Defaults (Restores All Settings To Default
Settings) Push and release the RIGHTarrow button to
confirm.
Digital Speed
• On
• Off
Tach. Peak Hold
When enabled, the Tach. Peak Hold function marks the
peak Revolutions Per Minute (RPM) on the tachometer
gauge for 3 seconds when the RPM is above 4000. Using the
UP and DOWN arrow switches on the left side of the
steering wheel, select the gauges icon from the menu on
the left side of the cluster (highlighted red is the active
menu item). Use the RIGHTarrow to enter the gauges
setup screen and the UP/DOWNarrows to select Tach
Peak from the menu of gauge options.
Tach. Peak Hold
