2016 Citroen DS5 display

49 Audio and Telematics


As a safety measure and because it
requires the sustained attention of
the driver, using a smartphone when
driving is prohibited.
Operation must be with the vehicle
stationary
.

The synchronisation of a
smartphone allows applications on a
smartphone that are adapted to the
CarPlay
® technology to be displayed
in the vehicle's screen, having first
activated the CarPlay
® function in your
smartphone.
As the principles and standards
are constantly changing, it is
recommended that you keep your
smartphone's operating system
updated
.
For the list of eligible smar tphones, go
to the brand's internet website in your
country.
Connect a USB cable. The
smartphone charges when
connected by a USB cable.
Connect a USB cable. The
smartphone charges when
connected by a USB cable.

Press on " Te l e p h o n e
" to display the
CarPlay
® interface.

Press on " CarPlay
" to display the
CarPlay
® interface.
On connecting the USB cable, the
CarPlay
® function deactivates the
system's Bluetooth mode.


In the system, press on
" Connectivity
" to dsplay the primary
page.
Or

5
12
8
6
13
14
9
7
10
11
1
1
1
4
53 Audio and Telematics


Level 1

Level 2

Comments


Radio Media



Secondary page



Audio settings

Ambience
Select the sound ambience.

Distribution
Sound distribution by the Arkamys
®
system.

Sound
Adjust the volume or activate volume linked to
speed.

Voice
Adjust the voice volume.

Ringtone
Adjust the ringtone volume.

Confirm
Save settings.

Radio Media



Secondary page



Radio settings

General

Activate or deactivate settings.

Announcements


Confirm
Save settings.

Radio Media



Secondary page



Radio stations

FM

Display the list of radio stations for the band
selected.
DAB


AM


Presets
Select a preset radio station.

Frequency
Enter a frequency manually.
Change the screen display mode.
Update the list according to reception.

15
18
16
19
17
1
1
14
55 Audio and Telematics


Level 1

Level 2

Comments


Radio Media



Secondary page



Music files

Albums

Choose a selection mode.
Artists


Genres


Playlists


Folders


Radio Media



Secondary page



Managing photos

USB
Display photos.
The system supports the following image
formats: .gif, .jpg, .jpeg, .bmp, .png, .raw et .tiff
with a maximum size of 10 Mb per image.

1

Press Radio Media
to display the
menu.

Press on the " OPTIONS
" button to
go to the secondary page.
Press on " Frequency
".
Press on " Frequency
".

Enter the values using the virtual
keypad.
First enter the units then click on the
decimals zone to enter the figures
after the decimal point.
Press one of the buttons for an
automatic search for radio stations.

Press on Radio Media
to display the
primary page.








Radio


Selecting a station


Radio reception may be affected by
the use of electrical equipment not
approved by the brand, such as a USB
charger connected to the 12 V socket.
The exterior environment (hills,
buildings, tunnel, car park, below
ground...) may prevent reception,
even in RDS station tracking mode.
This phenomenon is normal in the
propagation of radio waves and is in no
way indicative of a fault with the audio
system.


Select " Radio stations
" in the
secondary page.
Or

Or
Move the cursor for a manual search
for frequencies up or down.
Select a radio station or frequency (refer to the
corresponding section).

Press on " Presets
".

Make a long press on one of the
buttons to preset the station.










Preset a station


Press on " Confirm
".

1
19
910
57 Audio and Telematics


Press on Radio Media
to display the
primary page.

Press on Radio Media
to display the
primary page.
Press on the " OPTIONS
" button to
go to the secondary page.

Press on the " OPTIONS
" button to
go to the secondary page.
Select " Radio settings
".

Select " Radio settings
".
Select " General
".

Select " General
".
Select " Announcements
".
Activate/deactivate " Station follow
".

Activate / Deactivate " Display radio
text
".
Activate / Deactivate " Tr a f f i c
announcement
".











Activate/ Deactivate RDS


RDS, if activated, allows you to continue
listening to the same station by automatic
retuning to alternative frequencies.
However, in certain conditions, coverage
of an RDS station may not be assured
throughout the entire country as radio
stations do not cover 100 % of the
territory. This explains the loss of
reception of the station during a journey.

Press on " Confirm
".

Press on " Confirm
".

Press on " Confirm
".

The "radiotext" function allows
information transmitted by the radio
station and related to the station or the
song playing to be displayed.











Display text information









Play TA messages


The TA (Traffic Announcement)
function gives priority to TA alert
messages. To operate, this function
needs good reception of a radio station
that carries this type of message. While
traffic information is being broadcast,
the current media is automatically
interrupted so that the TA message can
be heard. Normal play of the media
previously playing is resumed at the
end of the message.

Display of options:
if active but not available, the display will be greyed out.
if active and available, the display will be clear.
Display "Radiotext" for the
current station.
Switch between the page
with the presets and the
page with the frequences.

Change of band.
Display of the name of the current station
and "multiplex" being listened to, also
called an "ensemble".

Display of the list of radio
stations.
Next "multiplex".
Next radio station.

Secondary page.
Select audio source.

Previous "Multiplex".
Previous radio station.








DAB radio (Digital Audio Broadcasting)


Terrestrial Digital Radio


If the current "DAB" station is not available on
"FM" the "DAB/FM" option is greyed out.

1
9
59 Audio and Telematics


Select the audio source.
Press on Radio Media
to display the
primary page.

Press on " Band
" to select the " DAB
"
waveband.

Press on Radio Media
to display the
primary page.

Press on the " OPTIONS
" button to
go to the secondary page.









DAB / FM auto tracking








Digital radio


"DAB" does not cover 100% of the
territory.
When the digital radio signal is poor,
"DAB/FM auto tracking" allows you to
continue listening to the same station,
by automatically switching to the
corresponding "FM" analogue station
(if there is one).
If "DAB / FM auto tracking" is activated,
there is a difference of a few seconds
when the system switches to "FM"
analogue radio with sometimes a
variation in volume.
Once the digital signal is restored, the
system automatically changes back to
"DAB".
Digital radio provides higher quality
reception.
The different multiplexes offer a
choice of radio stations arranged in
alphabetical order.

If the "DAB" station being listened to
is not available on "FM" (" DAB/FM
"
option greyed out), or "DAB/FM auto
tracking" is not activated, the sound
will cut out while the digital signal is too
weak.


Select " Radio settings
".

Select " General
".

Activate / Deactivate " Station
follow
".

Press on " Confirm
".

Media


USB player















Selecting the source


Select " Source
".
Press on Radio Media
to display the
primary page.

The system builds playlists (in temporary
memory), an operation which can take from
a few seconds to several minutes at the first
connection.
Reduce the number of non-music files and the
number of folders to reduce the waiting time.
The playlists are updated every time the
ignition is switched off or connection of a USB
memory stick. The lists are memorised: if they
are not modified, the subsequent loading time
will be shorter.

Insert the USB memory stick into the USB port
or connect the USB device to the USB port
using a suitable cable (not supplied).

















Auxiliary (AUX) socket










CD player


Insert the CD in the player (depending on
equipment).

First adjust the volume of your portable device
(to a high level). Then adjust the volume of your
audio system.
Display and management of the controls are
via the portable device.

This source is only available if "Auxiliary input"
has been checked in the audio settings.

Connect the portable device (MP3 player…) to
the auxiliary Jack socket using an audio cable
(not supplied).
Choose the source.








Bluetooth ®
audio streaming


Streaming allows you to listen to music from
your telephone.

The Bluetooth profile must be activated. First
adjust the volume on your portable device
(to a high level).
Then adjust the volume of your audio system.

If play does not start automatically, it may be
necessary to star t the audio playback from the
telephone.
Control is from the portable device or by using
the audio system buttons.

Once connected in streaming mode,
the telephone is considered to be a
media source.
