2016 Citroen DS5 display

35 Audio and Telematics



Level 3



Level 4



Level 5



Comments


Traffic Traffic observed Display traffic information in real time: type,
description and duration (in minutes).
Danger areas List of danger areas Display danger areas (roadworks, breakdowns,
accidents, ...) in real time.
Points of interest Points of
interest Select POI Display the list of POIs for the location selected.

22
23
1

Settings specific to
connected navigation

For access to connected navigation,
you have to select the option:
" Authorize sending information
".

Select " Options
".

Select " Alerts
".


- " Allow declaration of danger
areas
"

- " Guidance to final destination
on foot
"

- " Authorise sending
information
"

Activate or deactivate:

Activate or deactivate " Warn of
danger zones
".
The display of danger zones is
conditioned by the legislation in force
and subscription to the ser vice.



The temperature displayed at 6 o'clock in the morning
will be the maximum temperature for the day.
The temperature displayed at 6 o'clock in the evening
will be the minimum temperature for the night.



Select " Settings
".
Press on Navigation
to display the
primary page.

Press the " MENU
" button to go to the
secondary page.


Display the weather


Select " Weather
".

Press on this button to display the
first level of information.

Press on this button to display the
detailled weather information.
Select " View map
".
Press on Navigation
to display the
primary page.

Press on this button to display the list
of ser vices.

37 Audio and Telematics


To distribute information on the
declaration of danger zones, you
should check the option: " Allow
declaration of danger areas
".

You can download updates to the
system, danger zones and mapping,
from the brand's website.
The download procedure can be found
in the same place.



Declaration of "Danger
areas"

Press on Navigation
to display the
primary page.

Press on the "Declare a new danger
area" button located in the upper bar
of the touch screen.

Select the option " Ty p e
" to choose
the type de "Danger area".

Select the " Speed
" option and enter
it using the virtual keypad.

Press on " Confirm
" to save and
distribute the information.

39 Audio and Telematics






Internet browser


Press on " Internet Browser
" to
display the browser home page.

The internet connection is made
via one of the network connections
provided by the vehicle or the user.

Press on Connected connectivity

to display the primary page.

1
1
1
1
6
7
8
2
3
4
5
41 Audio and Telematics



Level 1



Level 2



Comments




Connectivity



Secondary page



Bluetooth
connection


All
Display all telephones, connected or
disconnected.

Connected
Display all connected telephones.

Search
Start a search for a device to connect.


Connectivity



Secondary page



Wi- Fi network
connection


Secured
Display secured Wi-Fi networks.

Not secured
Display non-secured Wi-Fi networks.

Stored
Display remembered Wi-Fi networks.


Connectivity



Secondary page



Manage connection

Display the state of the subscription to connected
ser vices, the state of the network connection and
the connection mode.


Connectivity



Secondary page



Share Wi- Fi
connection


Activation
Activate or deactivating the sharing of the Wi-Fi
connection.

Settings
Select a Wi-Fi network found by the system and
connect to it.
Save settings.


Functionalities available according to equipment.

1





Bluetooth connection ®



Procedure from the system
Connection sharing


Press on " Te l e p h o n e
" to display the
secondary page.

Press on " Bluetooth connection
".

Select " Search
".
The list of deteted telephones is
displayed.


If the pairing procedure fails, it is recommended
that you deactivate and then reactivate the
"Bluetooth" function in your telephone.


The " Mobile internet data
" profile
must be activated for connected
navigation (where the vehicle does not
have "Emergency and assistance call"
ser vices), having first activated sharing
of this connection on your smartphone.
The system offers to connect the
telephone with 3 profiles:


- " Te l e p h o n e
" (hands-free kit, telephone
only),

- " Streaming
" (wireless play of audio files
on the telephone),

- " Mobile internet data
".


Select the name of the chosen
telephone in the list.

Press on " Confirm
".

Select one or more profiles.
Press on the " OPTIONS
" button to
go to the secondary page.
As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-
free system of your audio system must
be done with the vehicle stationary

and the ignition on.


Procedure from the telephone


Select the name of the system in the
list of devices detected.

In the system, accept the connection request
from the telephone.
Activate the Bluetooth function on the
telephone and ensure that it is "visible
to all" (telephone configuration).

To complete the pairing, whichever
procedure used (from the telephone or
from the system), ensure that the code
is the same in the system and in the
telephone.
Depending on the type of telephone, you
may be asked to accept or not the transfer
of your contacts and messages.

11
1
7
8
43 Audio and Telematics






Wi-Fi connection
Sharing the Wi-Fi connection
Managing connections


To protect from any piracy and provide
maximum security for your systems,
it is recommended that you use a
security code or complex password.

The Wi-Fi connection and the sharing
of the Wi-Fi connection are exclusive.

Press on " Confirm
" to start the
connection.
Press on " Confirm
".
Press on " Connectivity
" to display
the primary page.
Network connection by the smartphone Wi-Fi.
Creation of a local Wi-Fi network by the
system.

Press on Connectivity
to display the
primary page.
Press on Connectivity
to display the
primary page.

Press on " OPTIONS
" to go to the
secondary page.
Press on the " OPTIONS
" button to
go to the secondary page.
Press on the " OPTIONS
" button to
go to the secondary page.

Select " Wi- Fi network connection
".
Select " Share Wi- Fi connection
".
Select " Manage connection
".

And / Or
Select the " Secured
", " Not secured
"
or " Stored
" tab.
Select the " Activation
" tab to
activate or deactivate sharing of the
Wi-Fi connection.

Select the " Settings
" to change the
name of the system network and the
password.
With this function you can view the access
to connected ser vices, the availability of
connected ser vices and modify the connection
mode.


Using the virtual keypad, enter the
" Key
" for the Wi-Fi network and the
" Password
".
Select a network.

45 Audio and Telematics


As a safety measure and because it
requires the sustained attention of
the driver, using a smartphone when
driving is prohibited.
Operation must be with the vehicle
stationary
.

The synchronisation of a
smartphone allows applications on a
smartphone that are adapted to the
MirrorLink
TM technology to be displayed
in the vehicle's screen.
The principles and standards
are constantly evolving. For the
communication process between
the smartphone and the system to
work correctly, the smartphone must
be unlocked; update the operating
system of your smar tphone as
well as the date and time in the
smar tphone and the system.
For the list of eligible smar tphones,
connect to the brand's internet website
in your country.
The " MirrorLink

TM
" function requires
the use of a compatible smartphone
and applications.

There may be a wait for the availability
of applications, depending on the
quality of your network.



When connecting a smartphone to
the system, it is recommended that
Bluetooth
® be started on the smartphone


Depending on the smartphone, it may be
necessary to activate the " MirrorLink
TM
" function.

During the procedure, several screen
pages relating to certain functions
are displayed.
Accept to start and end the
connection.
Connect a USB cable. The
smartphone charges when
connected by a USB cable.

Press on " MirrorLink

TM
" to start the
application in the system.
Once connection is established, a page
is displayed with the applications already
downloaded to your smartphone and adapted
to MirrorLink
TM technology.

Access to the different audio sources remains
accessible in the margin of the MirrorLink
TM
display, using touch buttons in the upper bar.
Access to the menus for the system is possible
at any time using the dedicated buttons

From the system, press on
" Connectivity
" to display the primary
page.
As a safety measure, applications
can only be viewed with the vehicle
stationary; display is interrupted once
the vehicle is moving.
