2016 Citroen C5 Owner's Manual

247
C5_en_Chap10_caracteristique_ed01-2015
Interior (Saloon)
A1 030
B 1 115
C 566
D 504
E 1 040
F 1 705
10
Technical data

248
C5_en_Chap10_caracteristique_ed01-2015
Exterior (Tourer)
A2 815
B 1 054
1 065***
C 959
D 4 829
4 840***
E 1 586
F 2 096
G 1 557
H 1 860
I * 1 479
1 483**
* Without roof bars.
** With metal spring suspension.
*** Crosstourer version.
Technical data

249
C5_en_Chap10_caracteristique_ed01-2015
Interior (Tourer)
A1 060
B 1 115
C 510
D 8 51
E 1 058
F 1 723
10
Technical data

250
C5_en_Chap10_caracteristique_ed01-2015
Identification markings
Various visible markings for identification of the vehicle.
Refer also to the registration document for your vehicle for the vehicle type, serial number, the weights...
All genuine CITROËN replacement parts are available exclusively within the dealer network.
For your safety and in order to remain within the terms of the warranty, you are advised to use only
CITROËN replacement parts.D.
Tyre / paint label
Affixed to the left hand centre door pillar, it
bears the following information:
- Tyre pressures, laden and unladen.
- Tyre sizes (including the load index and
speed rating).
- Tyre pressure for the spare wheel.
- Paint colour code.
o bserve the tyre pressures indicated by
CITROËN.
Check the tyre pressures at least
monthly, when cold.
A. Manufacturer's label.
- Gross train weight (GTW).
- Maximum weight on front axle.
- Maximum weight on rear axle.
B. Vehicle Identification Number (VIN)
under the bonnet
C. Vehicle Identification Number (VIN) at
the bottom of the windscreen aper ture Never deflate a warm tyre.
When changing tyres, it is essential to
use the sizes recommended for your
vehicle.
Low tyre pressures increase the fuel
consumption of your vehicle.
Affixed to the left hand centre door pillar, it
bears the following information:
- Manufacturer's name.
- EU type approval number.
- Vehicle Identification Number (VIN).
- Gross vehicle weight (GV W).
Technical data

251
C5_en_Chap11a_bTa_ed01-2015
Emergency or assistance call
If an impact is detected by the airbag
control unit, and independently of
the deployment of any airbags, an
emergency call is made automatically.
Localised Emergency Call
In an emergency, press this
button for more than 2 seconds.
Flashing of the green indicator
lamp and a voice message
confirm that the call has
been made to the "Localised
Emergency Call"* centre.
Pressing this button again immediately cancels
the call.
The green indicator lamp goes off.
At any time, pressing this button for more than
8 seconds cancels the call.
The green indicator lamp remains on (without
flashing) when communication is established.
It goes off at the end of the call.
This call is dealt with by the "Localised
Emergency Call" centre, which receives
locating information from the vehicle and
can send a detailed alert to the appropriate
emergency services.
In countries in which a centre is not
operational, or when the locating service
has been expressly declined, the call is dealt
with directly by the emergency services (112)
without the vehicle location. *
These services are subject to conditions and
availability.
Consult a CITROËN dealer. If you benefit from the CITROËN
Connect Box offer with the SOS and
assistance pack included, there are
additional services available to you in
your MyCITR
oËn personal space, via
the CITR oËn Internet website in your
country, accessible on www.citroen.com.
.
audio and Telematics

252
C5_en_Chap11a_bTa_ed01-2015
Localised Assistance Call
If you purchased your vehicle outside
the CITROËN dealer network, we
invite you to have a dealer check the
configuration of these services and, if
desired, modified to suit your wishes.
In a multi-lingual country, configuration
is possible in the official national
language of your choice.
For technical reasons, particularly
to improve the quality of Telematic
services to customers, the
manufacturer reserves the right to
carry out updates to the vehicle's
on-board telematic system.
The fault with the system does not
prevent the vehicle being driven. Press this button for more than
2 seconds to request assistance
if the vehicle breaks down.
A voice message confirms that
the call has been started*.
Pressing this button again immediately cancels
the request.
The cancellation is confirmed by a voice
message.
The orange indicator lamp is on fixed: the back-
up battery should be replaced.
In both cases, the emergency and assistance
calls service may not work.
Contact a qualified repairer as soon as
possible.
Operation of the system
When the ignition is switched on,
the green indicator lamp comes
on for 3 seconds indicating that
the system is operating correctly.
The orange indicator lamp
flashes then goes off: the system
has a fault.
* These services are subject to conditions and
availability.
Consult a CITROËN dealer.
audio and Telematics

253
C5_en_Chap11b_SMEGplus_ed01-2015
7-inch touch screen tablet
GPS satellite navigation - Multimedia audio - Bluetooth® telephone
Contents
First steps 254
Steering mounted controls 256
Menus 257
Navigation 258
Navigation - Guidance 266
Tr a f fi c 2 7 0
Radio Media 272
Radio 278
DAB (Digital Audio Broadcasting) radio 280
Media 282
Settings 286
Internet 294
Internet browser 295
MirrorLink
TM 298
Telephone 300
Frequently asked questions 308
The system is protected in such a way that it will only operate in
your vehicle. As a safety measure, the driver should only carry out operations
which require prolonged attention while the vehicle is stationary.
The display of the energy economy mode message signals
that the system is about to go into standby. Refer to the Energy
economy (mode) section.
.
audio and Telematics

254
C5_en_Chap11b_SMEGplus_ed01-2015
First steps
Use the buttons arranged below the touch
screen tablet for access to the menu carousel,
then press the virtual buttons in the touch
screen tablet.
Each menu is displayed in one or two pages
(primary page and secondary page).Secondary page
Primary page In very hot conditions, the system may
go into stand-by (screen and sound
completely off) for a minimum period of
5 minutes.
