2015 VOLKSWAGEN TOUAREG cd select

WARNING
Driving on today's roads demands the full attention of the driver at all times. Driver distrac-tion causes accidents, collisions and serious personal injury!
x Never pair the mobile phone or configure user profiles while driving. Do this only when the vehicle is parked in a safe place.
x Never let yourself be distracted when setting, adjusting, or using the Infotainment System, when using your mobile phone, or when operating the mobile phone controls.
x Always drive attentively and responsibly. Use the Infotainment system, your mobile phone, and the mobile phone controls only if road, traffic, and weather conditions permit and you will not be distracted from your driving.
x If you cannot use the Infotainment System, your mobile phone, or the mobile phone con-trols safely while driving, wait until later or find a safe spot where you can pull off the road and park the vehicle.
x Always set sound volume levels so that you can clearly hear horns, sirens, and other warning sounds outside the vehicle.
For device search, select a location with the likelihood of only a few unknown Bluetooth devices, for example in the garage. The search range for Bluetooth is approximately 10 meters.
Pairing a mobile phone via Bluetooth-HFP

x If necessary activate “wait for incoming Bluetooth connections”.
x Hold the mobile phone in your hand ready to enter the password within the time limit.
x Select the mobile phone from the device list in the vehicle by pressing the corresponding function key.
x Select the required pairing protocol below the mobile phone found.
x On the mobile phone, confirm the connection queries from the vehicle if required.
x Confirm the 4-digit password displayed on the Infotainment System screen.
x Enter the password on the mobile phone within 30 seconds.27.
x Confirm password entry.
x If necessary, confirm further queries on the mobile phone.
Pairing procedure if a mobile phone has already been paired with the telephone control
x Set the Bluetooth connection to visible on the mobile phone ⇒  step 1.
x Switch on the ignition.
x Access the SETUP main menu with the SETUP Infotainment button.
x Press the Telephone function key.
x Press the Bluetooth settings function key.
x In the Bluetooth settings menu, press the Search for Bluetooth devices function key.
x If necessary, confirm the query about whether Bluetooth has been activated on the mobile phone with Next .
x Carry out pairing as described ⇒  step 3.
Failed pairing
There is no limit on the number of attempts to pair the device with the telephone control.
Linking will not be successful if the password input time limit is exceeded or if the PIN code is entered incorrectly.
Restart linking if the process fails despite correct entries.
Copying telephone directory to the telephone control
Once pairing has been successfully completed, the telephone directory entries from the mobile phone27 are loaded automatically into the data memory of the telephone control. Depending on the number of entries copied, the process can take several minutes.
The telephone directory memory of the telephone control is limited to 5000 entries. Each user profile can be assigned a maximum of 2000 entries as well as 100 user-created or edited entries.
Automatic connection to a paired mobile phone

Function key: Effect
o: Open the number pad to enter a telephone number
Call lists : Opens a pop-up window for selection of a call list for calls
missed, dialed or received on the telephone control
SMS31: Opens a pop-up window with the following options:
Inbox : Displays received SMS.
Templates : Selection of available templates for sending SMS.
Extras : Opens a pop-up window with the following options:
Display off : Switches off the display. Press one of the Infotainment
buttons or the screen to switch on again.
Conference details29: Opens a list of the parties in a current confer-
ence call
Mute : Switches the microphone off during a telephone call, so that the
person on the line cannot hear what is being said in the vehicle.
]: Opens the telephone directory of the paired mobile phone to select a
telephone number

31 Dependent on mobile phone and country.

The entries in the telephone directory of the mobile phone cannot be changed permanently via the telephone control. A telephone number stored in the telephone directory on the mobile phone can only be modified for calls from the vehicle. You can add a country code
The telephone directory entries can be called up in the Navigation system via the Directory menu.
Searching for an entry in the telephone directory

Fig. 235 Telephone directory.

Fig. 236 Search window for selecting a telephone directory entry.

If no name is suggested as you enter text, there is no telephone directory entry matching the se-quence of characters you have entered. Using the  function key, delete characters in the input line until a name is suggested again. Please take the sorting order into consideration
Selecting displayed entry
Press the # function key to open the menu showing the search results that are still available
⇒ fig. 236.
Using voice operation, you can also record the name stored in the telephone directory after the corresponding voice command
Displaying and editing telephone number

Fig. 237 Editing a telephone number.

When a connection is made to a dialed telephone number, the PHONE main menu changes to the
telephone call view ⇒ fig. 240.
Holding a call34
x Press the 5 function key to “mute” the current telephone call (display: Call being held).
x Press the  function key to resume the call.
While a call is being held, no sound is transmitted. Conversations in the vehicle cannot be heard by the other party.
Ending a telephone call
x Press the ^ function key to end the current call.
The PHONE main menu is displayed again ⇒ fig. 239.
DTMF tones
Every telephone button has a specific DTMF tone assigned to it. DTMF tones are used, for example, to send a password or to select an employee in a call center or to access the voice mail.
x If you are asked to enter a sequence of characters during a telephone call, open the keypad by
pressing the o function key and enter the characters ⇒ fig. 241.
Making an additional call, “toggling calls” and “call waiting”

Fig. 242 Telephone call with call on hold.

Function key: Effect
Telephone ID38: Display of IMEI (telephone ID, serial number). If a mobile
phone is paired via Bluetooth rSAP or a SIM card is inserted in the SIM
card reader, the telephone ID of the telephone control will be displayed. If
a mobile phone is paired via Bluetooth HFP, the telephone ID of the mo-
bile phone is displayed ⇒  Bluetooth profiles.
Call options : Function settings for telephone calls that are made via the
telephone control
SIM PIN settings38: Setting for use of the SIM PIN for the connection with
a mobile phone.
Speed dial buttons : Set the telephone numbers for the speed dial buttons
SMS settings38: Setting for receiving and sending SMS from the vehicle.
Call forwarding38: Setting for forwarding incoming calls.
Automatic network selection38: Available mobile phone networks are dis-
played and can be selected. Logging on may not be possible due to re-
strictions for the SIM card being used. If the user profile is changed, the
setting is reset to automatic if necessary.
Switch off telephone38: Switch the telephone control on or off.

Call options

WARNING
Improper use of vehicle keys can result in serious personal injury.
x Always take the key with you when you leave the vehicle. The engine can be started and vehicle systems such as the power windows can be operated, leading to serious personal injury.
x Never leave children, disabled persons, or anyone who cannot help themselves in the vehicle. The doors can be locked with the remote control vehicle key. This could result in people being trapped in the vehicle in an emergency. For example, depending on the time of year, people trapped in the vehicle can be exposed to very high or very low temperatures.
x Heat build-up in the passenger and luggage compartment of a parked vehicle can result in temperatures in the vehicle that are much higher than the outside temperatures, particularly in summer. Temperatures can quickly reach levels that can cause unconsciousness and death, particularly to small children.
x Never remove the key from the ignition switch while the vehicle is moving or rolling to a stop. The steering wheel will lock and you will not be able to steer or control the vehicle.
Leaving the key in the ignition for a long time when the engine is not running will drain the vehicle battery.
Leaving the selector lever for a long period of time in any position other than Park (P) when the ignition is switched off can drain the vehicle battery.
The vehicle key can be removed from the ignition switch only when the transmission is in Park (P). You may have to press the release button on the transmission selector lever to put the lever into Park (P).
Starter button

Fig. 247 In the front center console: Starter button of the Keyless Access locking and starting system.
