2015 VOLKSWAGEN TOUAREG cd select

x Press the CAR Infotainment button.
x Tap the Settings function key on the screen.
x Select Seat settings from the list.
x Check the check box in the Driver seat remote control key = function key.
x Shift the transmission into reverse.
x Adjust the passenger outside mirror for a clear view of the curb, for example.
x The adjusted mirror position is automatically stored and assigned to the vehicle key that used to unlock the vehicle. The preselected position will be recalled when the key assigned to that mirror adjustment position is used again. For vehicles with memory seat
Recalling passenger side mirror settings
x Turn the adjusting knob for the side mirrors to the R position.
x Shift the transmission into reverse gear with the ignition switched on.
x The mirror moves back to the regular position when the vehicle moves forwards faster than about 10 mph (15 km/h) or the adjusting knob is turned to the O or L position.
WARNING
Improper use of the folding outside mirrors can cause personal injury.
x Always make sure that nobody is in the way when folding the mirrors in or out.
x Make sure that you do not get your finger caught between the mirror and the mirror base when moving the mirrors.
WARNING
Incorrectly estimating distances with the right outside mirror can cause collisions and seri-ous injury.
x The right outside mirror has a convex (curved) surface. This widens your field of vision. But vehicles or other objects seen in a convex mirror will look smaller and farther away than they really are.
x If you use the right outside mirror to judge distances from vehicles behind you when changing lanes, you could estimate incorrectly and cause a crash and serious injuries.
x Whenever possible, use the inside mirror to more accurately judge distance and size of vehicles or other objects seen in the convex mirror.
x Always make sure you have a clear view to the rear of the vehicle.
NOTICE
x Always fold in the outside mirrors when taking the vehicle through an automatic car wash.
x Never fold power mirrors in manually because doing so could damage the electrical drive.
To reduce fuel consumption, use outside mirror heating only when needed.
When first switched on, outside mirror heating works with maximum heat for about 2 minutes.
If power mirror adjustment does not work, the outside mirrors can be adjusted by hand by press-ing on the edges of the mirror surface.

ating sequences that have been input are “memorized” and “processed” in succession once the back-ground processes have been completed.
Due to country-specific legal requirements, some functions are not selectable on the screen above a certain driving speed.
Using a mobile phone in the vehicle may cause noise from the vehicle speakers.
Some countries may have restrictions regarding the use of Bluetooth devices. Information can be obtained from the local authorities.
Controls

Fig. 131 Overview of rotary/push knobs and the Infotainment buttons.

Browsing lists

Fig. 134 List for selecting audio files for import.

Fig. 135 Station list in radio mode.

x OR: Press a point on the scale either side of the slider. The slider will then ? “jump” straight to the selected point.
Input windows with on-screen keyboard

Fig. 138 General view of an input window with on-screen keyboard.

Function keys Action and effect
Containing letters
and digits Press to insert the character in the input line.
Containing letters
anda
Press and hold to open a pop-up window with spe-
cial characters based on this letter.
Press the desired character to enter it. Some spe-
cial characters can also be written out (such as
“AE” for “Ä”).
y
Pressing briefly highlights all function keys for
which special characters are available.
Press a function key to open the pop-up window to
select a special character.
: Press to switch between upper and lower case.
; Press to open the input window for numbers and
special characters or to go back to the letter input
window. OR: A-Z
Press to enter a space.

Function key: Effect
Authentic , Soft , Dynamic , Speech : Press to select sound profile.
Surround : Set level of surround effect.

System settings

Function key: Effect
GPS : Use Time zone GMT to select the time and date. Time and
Date are then disabled for manual entry.
Manual : Time and date can be entered manually by pressing Time
and Date . Time zone GMT is then disabled.
Time : Set the time by pressing the arrow buttons ` or a and confirm
change with OK .
Time zone GMT : Press the

Function key: Effect
Scan : Starts and stops the scan feature
Screen off : Switching off the display. To switch on again, press any
Infotainment button or touch screen.
Tune : Opens the frequency dial for the selected frequency band
1... to 36... : Station buttons for storing radio stations

Changing radio station or selecting a station from the station list

Fig. 143 FM-station list: Station 2 is playing.
