2015 VOLKSWAGEN TOUAREG light

Replacing light bulbs

WARNING
Improper replacement of burned out headlights and other light bulbs can cause serious per-sonal injury.
x Stop! Always read and heed the WARNINGS before doing any work in the engine com-
partment ⇒  Working in the engine compartment. The engine compartment of any motor vehi-cle is a potentially dangerous area, and work in this area can lead to serious personal injury.
x HID – High Intensity Discharge (Xenon) get power from a high-voltage source that can cause severe personal injury and even death if handled improperly.
x H7 bulbs and HID – High Intensity Discharge (Xenon) are under high pressure and can explode if handled improperly.
x Always let a burned out light bulb cool down before replacing it.
x Never replace a light bulb unless you are familiar with all of the necessary procedures. In particular, never remove a headlight unless you know exactly how to carry out the job and have the correct tools and light bulbs.
x If you are uncertain about what to do, have the work performed by an authorized Volkswagen dealer, an authorized Volkswagen Service Facility, or another qualified work-shop. Serious personal injury may result from improperly performed work.
x We strongly recommend that you always have HID - High Intensity Discharge (Xenon) lamps and H7 bulbs replaced by a qualified technician.
x Do not touch the glass of light bulbs with your bare hands. Fingerprints left on the bulb evaporate due to the heat when the bulb is switched on and cause the reflector to “cloud”.
x There are sharp edges on and around the headlight housing in the engine compartment and the taillight housing. Wear hand protection if you replace bulbs.
NOTICE
After replacing a headlight bulb or other light bulb, always make sure that the rubber covers or plastic caps have been properly and securely reinstalled to help prevent water from getting into the electrical connections and headlight housing and damaging the electrical system.
Indicator lights

8 One or more brake lights
burned out.
See an authorized Volkswagen
dealer, an authorized
Volkswagen Service Facility, or
other qualified workshop to re-
place the light bulb that isn't
working.
; License plate light not work-
ing.
See an authorized Volkswagen
dealer, an authorized
Volkswagen Service Facility, or
other qualified workshop to re-
place the light bulb that isn't
working.

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
Failure of a single LED within a taillight is not indicated. However, the  indicator light will come on if all LEDs fail.

2. Turn the ignition of the vehicle with the dead battery. If the engine starts, wait 2 to 3 minutes until it
“runs smoothly” before removing the jumper cables as described below ⇒ . If the engine does not start within about 10 seconds, turn off the ignition and wait at least 1 minute; then try again.
Before removing the jumper cables
1. Switch off the headlights (if they are on).
2. In the vehicle with the dead battery, switch on the heater fan and the rear window defroster. This helps tit minimize voltage spikes when the cables are disconnected.
Removing the jumper cables
1. Before you remove the jumper cables, switch off the headlights (if they are on).
2. In the vehicle with the dead battery, switch on the heater fan and the rear window defroster. This helps to minimize voltage spikes when the jumper cables are disconnected.
3. With the engine running, remove the jumper cables in reverse order to the way they were con-nected. Specifically:
– Disconnect the black (–) cable from the vehicle with the dead battery.
– Disconnect the black (–) cable from the other vehicle (vehicle with the good battery).
– Disconnect the red (+) cable from the other vehicle (vehicle with the good battery).
– Disconnect the red (+) cable from the vehicle with the dead battery.
4. Turn off the heater fan and the rear winder defroster on the vehicle with the dead battery.
5. Snap the cap of the positive jump-start terminal back on, reinstall covers, and close engine hoods.

As driver of the towed vehicle:
x If your vehicle is the one being towed, the ignition switch must be switched on to keep the steering wheel from locking. Also make sure that the turn signals, horn, windshield wipers, and windshield washers work properly.
x Since power steering does not work when the engine is switched off, more effort is needed to steer the vehicle.
x Since the brake booster also does not work when the engine is stopped, you will need to press harder on the brake pedal to slow down or stop. Do not hit the towing vehicle.
x Read and heed the information and WARNINGS in the towing vehicle's owner's manual.
As driver of the towing vehicle
x Drive especially carefully and accelerate gently. Avoid sudden driving maneuvers.
x Brake earlier than usual and with light pedal pressure.
x Read and heed the information and WARNINGS in the owner's manual of the vehicle being towed.

Abbreviations
Abbreviation Meaning
A2DP Advanced Audio Distribution Profile for cross-manufacturer Bluetooth audio signal transmission compatibility.
ABS Anti-lock Brake System.
AFS Adaptive Front Lighting System.
AKI Anti-Knock Index.
AM AM (amplitude modulation).
ANSI American National Standards Institute.
ASL Automatic Shift Lock.
ASR Anti-Slip Regulation.
ATA Anti-Theft Alarm system.
BAS Brake Assist System.
cc Cubic centimeter unit of volume for specifying engine displacement.
ccm Cubic centimeters. Unit of measure for engine displacement.
CCS Cruise Control System.
CCS Cruise Control System.
CID Cubic inch displacement, unit of volume for specifying engine displacement.
cm Centimeter – metric unit of measure for length.
CO2 Carbon dioxide.
DIN Deutsches Institut für Normung (German Institute for Standardization).
DPF Diesel Particulate Filter.
DRL Daytime Running Lights.
DTMF Dual Tone Multiple Frequency.
EDL Electronic Differential Lock.
EN European Norm.
EON Enhanced Other Network (support for other radio networks).
EPC Engine control (Electronic Power Control).
ESC Electronic Stability Control.
ETC Electronic Toll Collection system.
FLA Headlight assistant.
FSI Fuel Stratified Injection.
g/mi Generated carbon monoxide amount in grams per mile driven.

GAWR Gross Axle Weight Rating.
GSM Global System for Mobile Communications.
GVWR Gross Vehicle Weight Rating.
HDD Media Center (Hard Disk Drive).
HFP Hands-Free-Profile (mobile phone operation).
HID High Intensity Discharge headlights (HID).
hp Horsepower, engine power rating.
IMEI International Mobile Station Equipment Identity (unique serial number for identifica-tion of GSM terminal devices).
kg Kilogram – metric unit for weight.
kN Kilonewton, tractive force.
kp Kilopond, a measure of force.
kPa Kilopascal, unit of measure for tire pressure.
kW Kilowatt, engine rating.
LED Light Emitting Diode.
m Meter – metric unit of measure for length.
MDI Media Device Interface.
MFI Multi-Function Indicator.
MP3 Audio file compression format.
Nm Newton meter, engine torque unit.
OPS Optical Parking System.
PDC Park Distance Control.
PIN Personal identification number.
RDS Radio Data System (enables additional functions).
RON Research Octane Number, measurement of anti-knock resistance of gasoline.
rpm Engine revolutions per minute (engine speed).
rSAP Remote SIM Access Profile (via Bluetooth).
SAE Society of Automotive Engineers.
SIM Subscriber Identity Module.
SMS Short Message Service.
TDI® Turbocharged Direct Injection (Turbocharged diesel engine with direct fuel injec-tion).
TIN Tire Identification Number.
TMC Traffic Message Channel (for dynamic navigation).
