2015 VOLKSWAGEN TOUAREG light

In order to Operation
OR: If the vehicle rolls backwards.
Automatically
deactivate
the PDC:
Drive forward faster than about 5 – 10 mph (10 – 15 km/h).
OR: Shift into Reverse R.
Switch to full-
screen view:
Vehicle rolls backwards slowly.
OR: Press the lit-up button  or ∗.
OR: Tap the /03 function key ⇒ fig. 299.

The indicator light in the button  ⇒ fig. 298 comes on and stays on as long as the feature is active.
A chime sounds to tell you that the system is on. If the chime does not sound, PDC is not working. Have the system inspected by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.
Special considerations when using Park Distance Control
x In some cases, the Park Distance Control system interprets water and ice on the sensors as an obstacle. To prevent automatic PDC activation in these cases, you can turn Park Distance Control off
permanently in the Infotainment System ⇒  Automatic activation in the Infotainment System.
x If the distance remains the same, the warning tone volume decreases after a few seconds. If a continuous tone sounds, its volume remains the same.
x If the vehicle moves away from the obstacle, the beeping sound stops automatically. The beep turns on once more automatically if the vehicle approaches the obstacle again.
x There is no beeping when the transmission is in Park (P) or the electronic parking brake is en-gaged.
x The volume of the audible signals can be adjusted by an authorized Volkswagen dealership or an authorized Volkswagen Service Facility.
WARNING
Never rely completely on the PDC for information about people and objects that might be in the way of the vehicle and could be struck by the vehicle causing serious personal injury.
x The PDC sensors have blind spots where they cannot detect people or objects.
x Always watch for people, especially small children and animals, because the sensors may not always be able to detect them.
If you hear a long beep lasting about 3 seconds when you first turn PDC on or the indicator light in the button starts blinking, this means there is a malfunction in the Park Distance Control system. Switch off the Park Distance Control system with the button and have it immediately checked by an authorized Volkswagen dealer or an authorized Volkswagen Service Facility.

The air recirculation mode helps prevent outside air from entering the vehicle interior.
In very hot or cold outside temperatures, temporarily switch to manual air recirculation in order to cool or heat the vehicle interior faster.
For safety reasons, air recirculation is switched off if you push the  button ⇒ .
Switching air recirculation on and off manually
Switching on: Press the 3 button repeatedly until the indicator light in the button comes on.
Switching off: Press the 3 button repeatedly until the indicator light in the button goes out.
Switching air recirculation on and off automatically
x Press the CLIMATE Infotainment button.
x Tap the Extras function key.
x Switch automatic air recirculation on or off by tapping the Automatic air recirculation function key.
If the check box in the function key is checked =, automatic air recirculation is switched on.
What automatic air recirculation does
In automatic air recirculation mode, fresh air will enter the passenger compartment. If the system detects an increased concentration of pollutants in the outside air, it automatically switches to air recirculation. As soon as the pollutant level is back in the normal range, air recirculation is switched off.
Unpleasant odors cannot be detected by the system.
To keep the windows from fogging up, automatic air recirculation is not switched on automatically in certain circumstances.
WARNING
Stale air causes driver fatigue and reduces driver alertness, which can cause accidents, colli-sions and serious personal injury.
x Never use air recirculation mode over an extended period of time, since no fresh air will enter the passenger compartment.
x When the air conditioner is off and recirculation mode is on, condensation can quickly form on the windows and greatly reduce visibility.
x Always switch off recirculation mode when it is not needed.
NOTICE
Do not smoke when air recirculation is switched on. Smoke drawn into the ventilation system can leave residue on the evaporator and on the dust and pollen active carbon filter, resulting in permanent odors whenever the air conditioner is switched on.
When backing up and while the automatic wiper/washer is operating, air recirculation is briefly activated to avoid unpleasant odors in the passenger compartment. This feature only works if automat-
ic air recirculation is enabled ⇒  Switching air recirculation on and off automatically.
Heated steering wheel

Indicator lights and fuel gauge

Fig. 304 In the instrument cluster: Fuel gauge for gasoline and diesel fuel.

After switching on the ignition, the indicator light

Checklist
If you are uncertain in any way, have the work done by an authorized Volkswagen dealer or author-ized Volkswagen Service Facility. Serious personal injury may result from improperly performed work. Make sure that you check the following items regularly. The best thing is to check them every time you refuel:
d Windshield washer fluid level ⇒  Windshield wiper and washer
d Engine oil level ⇒  Engine oil
d Engine coolant level ⇒  Engine coolant
d Brake fluid level ⇒  Braking and parking
d Tire pressure ⇒  Tires and wheels
d Vehicle lighting necessary for driving safety:
– Turn signals
– Parking lights, low beams and high beams
– Taillights
– Brake lights
– License plate light
Information regarding replacing light bulbs ⇒  Replacing light bulbs.
WARNING
Disregarding the safety-related checklist may lead to accidents and injuries.
x Please note and follow the points listed in the checklist.

Warning and indicator lights

Lights
up
Possible cause or meaning
⇒  Proper response
together
with
ing or not filled standard
AdBlue.
authorized Volkswagen dealer
or an authorized Volkswagen
Service Facility.
>

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
WARNING
Failure to heed warning lights and instrument cluster text messages can cause the vehicle to break down in traffic and result in a collision and serious personal injury.
x Never ignore warning lights or text WARNINGS.
x Always stop the vehicle as soon as it is safe to do so.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
AdBlue information

WARNING
Off-road driving can be dangerous, can lead to accidents, vehicle damage, stranding in re-mote areas, and serious personal injury.
x Never drive too fast or for terrain and weather conditions.
x Always adjust your speed and driving style to road, terrain, traffic, and weather condi-tions.
x Always avoid sudden, sharp maneuvers that increase the risk of loss of vehicle control or getting stuck.
x When driving off-road look and think ahead, expect the unexpected.
x To reduce the risk of loss of control and serious personal injury, never use the cruise control when driving off-road. Cruise control is designed for highway use. It is completely unsuitable for off-road situations and can even be dangerous when used off-road.
NOTICE
Always make sure the vehicle has enough ground clearance. Severe damage to the underbody can occur if the vehicle bottoms out. The damage could disable the vehicle and leave you stranded.
“Tread lightly” is an educational program designed to increase public awareness of land use regulations and responsibilities in our nation's wilderness areas. Volkswagen supports the U.S. Forest Service and the Bureau of Land Management in encouraging you to preserve our national forests and other public and private lands by “treading lightly”.
Technical terms explained

Fig. 310 Illustration of grade (gradient angle) A and lateral angle B.
