2015 VOLKSWAGEN TOUAREG light

NOTICE
x To help prevent damage, do not use hard wax or polish on matte-finished parts, plastic parts, headlights or rear lights.
x Do not wax or polish your vehicle if it is dirty, or in a sandy or dusty place.
Caring for and cleaning chrome and aluminum parts

Removing stains
When treating stains, it may be necessary to clean the entire surface and not just the stain itself. This is especially true if the entire surface has become dirty from normal use. Otherwise, the area that is treated may become lighter than the untreated area. If you have questions or concerns, consult a professional cleaner.

Type of stain Recommended cleaning for fabric and uphol-
stery
Water-based stains,
such as coffee or
fruit juice.
– Moisten a sponge with water and rub the stain
gently with a circular motion.
– Wipe dry with an absorbent cloth.
Persistent stains,
such as chocolate
or make-up.
– Use only Volkswagen-approved cleaning products.
– If necessary, have the fabric or upholstery profes-
sionally cleaned.
Grease-based
stains, such as oil,
lipstick, etc.
– Use only Volkswagen-approved cleaning products.
– If necessary, have the fabric or upholstery profes-
sionally cleaned.

WARNING
If there is a malfunction in the airbag system, the airbag may not deploy correctly or at all, or it may deploy unexpectedly. This could cause fatal injuries.
x Have the airbag system inspected immediately by your authorized Volkswagen dealer or authorized Volkswagen Service Facility.
NOTICE
If the upholstery on power seats, heated seats, or seats with airbag components is wet, electri-cal components and the vehicle electrical system could be damaged.
x If the seating surface becomes soaked, have it dried and the system components checked immediately by an authorized Volkswagen dealer or authorized Volkswagen Service Facility.
x Do not use steam cleaners because the steam could cause the dirt to penetrate deeper into the fabric and make it impossible to remove.
x Pressure washers and cooling sprays can damage the upholstery.
NOTICE
x Clean only the carpet and floor mats with brushes. Other textile surfaces can be damaged by brushes.
x If detergent pastes or mild detergent solutions are applied with a damp cloth or sponge, the surfactants in the detergent may cause visible lines to form at the edges of the area where the detergent was applied. These lines are generally difficult or impossible to remove.

Type of stain Cleaning
Heavy stains – Apply a mild soapy solution with a cloth that has
been wrung nearly dry41.
– Dab dry with an absorbent cloth.
Water-based stains,
such as coffee, tea,
juice, or blood.
– Remove fresh stains with an absorbent cloth.
– If the stains are already dry, use an appropriate
cleaning agent ⇒ .
Grease-based
stains, such as oil,
lipstick, etc.
– Remove fresh stains with an absorbent cloth.
– Use an appropriate cleaning agent on stains that
have not yet penetrated the surface ⇒ .
Special stains, such
as ballpoint pen,
marker, nail polish,
latex paint, or shoe
polish.
– Dab dry with an absorbent cloth.
– Clean with a special stain remover designed for
leather.

NOTICE
x Stains that have been left in place too long will penetrate the surface of the leather and cannot be removed.
x Never treat leather with solvents, floor wax, shoe polish, stain remover or similar products.
x Wipe up spilled liquids immediately with an absorbent cloth. Liquid can penetrate leather surfaces and seams within a few seconds.
x If the vehicle is left in the sun for a long time, cover the upholstery to protect the leather from direct sunlight and to help prevent fading and discoloration.
Slight discoloration caused by wear and tear is normal.
Cleaning leatherette

NOTICE
x Do not clean leatherette with solvents, floor wax, shoe polish, stain remover, or similar products.
x These can cause the material to become brittle and break. Sharp-edged objects and items on clothing and belts (such as belt clips, mobile phone cases, zippers, rivets, and rhinestones) can damage upholstery material and fabric trim.
x If the vehicle is left in the sun for a long time, cover the upholstery to protect the leatherette from direct sunlight and to help prevent fading or discoloration.
Cleaning storage compartments and cup holders

Fig. 324 In the lower front center console: Front cup holders.

Lights
up Possible cause Proper response
%0# Engine control malfunction
(Electronic Power Control).
Have engine checked immediate-
ly by an authorized Volkswagen
dealer or authorized Volkswagen
Service Facility.
D Glow plug preheating before
diesel engine start-up.
B
Engine control/monitoring
system malfunction (engine
Malfunction Indicator Light -
MIL).
Ease off the accelerator. Careful-
ly drive to the nearest authorized
Volkswagen dealer or authorized
Volkswagen Service Facility.
Have engine checked.

Flashes Possible cause Proper response
B Misfire, which can damage
the catalytic converter.
Ease off the accelerator. Care-
fully drive to the nearest author-
ized Volkswagen dealer or au-
thorized Volkswagen Service
Facility. Have engine checked.

When the ignition is switched on, several warning and indicator lights come on briefly for a function check. They go out after a few seconds.
WARNING
Obey all applicable legal requirements when cleaning the diesel particulate filter.
x Clean diesel particulate filter as recommended only when visibility, weather, road, and traffic conditions permit.
x Do not put others at risk.
NOTICE
Failure to heed warning lights or text WARNINGS can result in vehicle damage.
As long as the indicator lights B, %0#, or

Description Possible causes
among others Possible remedy
when vehicle is
unlocked. Memory-seat settings
are stored.
– Reassign seat setting
– Clear memory-seat
memory
Front seats cannot
be adjusted with
power controls.
Vehicle battery dead. Charge vehicle battery
Fuse blown. Check fuse and replace if
necessary
No jack in vehicle
or no collapsible
spare tire or tire
mobility set in ve-
hicle.
Equipment differs
depending on vehicle.
No direct corrective action
possible because this de-
pends on the equipment.
Contact an authorized
Volkswagen dealer or an
authorized Volkswagen Ser-
vice Facility for assistance
Vehicle has mobility
tires.
Features do not
work as described
in this Manual.
Settings were
changed in the
Volkswagen Infor-
mation System or
Infotainment System.
Check and reset to factory
settings if necessary or
Headlights do not
light up the road as
they should.
– Headlights incorrect-
ly adjusted.
– Light bulbs burned
out.
– Low beams not
switched on.
– Adjust headlight range
– Change light bulbs
– Switch on low beams
Electrical appli-
ances do not work.
Vehicle battery charge
too low. Charge vehicle battery
Remaining fuel level
too low. Refuel
Fuse blown. Check fuse and replace if
necessary

Removing the wheel
x Review the checklist ⇒  Preparations for changing a wheel.
x Loosen the wheel bolts ⇒  Wheel bolts.
x Lift the vehicle ⇒  Lifting the vehicle with the vehicle jack.
x Unscrew the topmost loosened wheel bolt using the hexagonal socket in the screwdriver handle
⇒ fig. 334 place it on a clean surface.
x Screw the mounting pin in the vehicle tool kit into the empty hole by hand ⇒ fig. 342.
x Remove the remaining wheel bolts using the hexagonal socket in the screwdriver handle ⇒ fig. 334 and place them on a clean surface.
x Remove the wheel.
Mounting spare tire or collapsible spare tire
If the tire is a unidirectional tire, be sure to install it in the proper rolling direction ⇒  Unidirectional tires.
x Put the spare tire or collapsible spare tire into place on the vehicle.
x Screw in 4 wheel bolts clockwise and tighten them slightly using the hexagonal socket in the screwdriver handle.
x Unscrew the mounting pin and screw in the last wheel bolt.
x Lower the vehicle with the jack.
x Use the lug wrench to firmly tighten all wheel bolts (turn clockwise) ⇒ . Do not tighten them in sequence! Tighten any wheel bolt to begin, then tighten the wheel bolt diagonally opposite the first bolt, and so forth.
x Install the wheel bolt caps, center wheel hubcap, or wheel cover, if any ⇒  Wheel trim.
WARNING
Wheel bolts that are tightened or installed improperly can come loose, causing loss of vehi-cle control, a crash, and serious personal injury.
x Always keep wheel bolts and threads in the wheel hub clean and free of oil and grease. The wheel bolts must turn easily and must be tightened with the right torque.
x Use the hexagonal socket in the screwdriver handle only to turn the wheel bolts when they are loose, never to loosen them or tighten them firmly.
WARNING
Improper use of a collapsible spare tire can cause loss of vehicle control, a crash or other accident, and serious personal injury.
x Never use a collapsible spare tire if it is damaged or worn down to the wear indicators.
x Never drive faster than 50 mph (80 km/h) with a collapsible spare tire. Avoid full-throttle acceleration, heavy braking, and fast cornering!
x Never drive more than 125 miles (200 km) with a 16" collapsible spare wheel that is in-stalled on the front axle (drive axle).
x Replace the collapsible spare with a normal wheel and tire as soon as possible. Collapsi-ble spare tires are designed for brief use only.
