2015 VOLKSWAGEN E GOLF Owners Manual

Manually unlocking and locking the driver door

Fig. 160 Door handle on driver door: Concealed lock cylinder (if applicable).

Manually locking the passenger doors

Fig. 161 On the front side of the right rear door: Manual lock, covered by a rubber seal.

Fig. 162 On the front side of the right rear door: Locking the vehicle with the key bit in the vehicle key.

Opening the rear hatch from inside the luggage compartment

Fig. 163 Inside the luggage compartment: Cover for the rear hatch release.

Fig. 164 Inside the luggage compartment: Opening the rear hatch.

Emergency release for the selector lever lock

Fig. 165 Removing the selector gate cover.

Fig. 166 Releasing the selector lever lock (versions A and B).

x Slip the cover up and over the selector lever ⇒ .
Emergency release for the selector lever (version A)
x With the screwdriver from the vehicle tool kit, carefully push the release lever ⇒ fig. 166 A in the direction of the arrow and hold it in this position.
x Press the release button in the selector lever handle and shift the selector lever to Neutral (N).
x Carefully press the selector gate cover back in place, making sure that the electrical wiring stays in the correct position and is not pinched or damaged.
Emergency release for the selector lever (version B)
x Push the colored release lever ⇒ fig. 166 B in the direction of the arrow and hold it in this position.
x Press the release button in the selector lever handle and shift the selector lever to Neutral (N).
x Carefully press the selector gate cover back in place, making sure that the electrical wiring stays in the correct position and is not pinched or damaged.
WARNING
Never shift the transmission out of Park (P) without first firmly applying the parking brake. Otherwise, the vehicle can start to roll unexpectedly, especially on hills or inclines, and cause an accident and serious injuries.
NOTICE
Even with the selector lever is in Neutral (N), the automatic transmission will be damaged if the vehicle is towed (or you let it coast) for an extended period or at high speed with the electric motor shut off.
Emergency release for the charging connector

Vehicle tool kit

The vehicle tool kit, spare wheel or compact spare wheel may be in one of several places under the floor covering in the luggage compartment.
x If necessary, detach the luggage net.
x Lift the floor covering and secure it in the stops on either side of the luggage compartment
⇒ fig. 167 (small arrows).
NOTICE
Always guide the luggage compartment floor covering back down carefully. Dropping the floor covering could damage the vehicle trim and the floor covering itself.
Completely retract the jack after use. Otherwise it will not fit in its compartment and cannot be stowed safely.
Contents

Fig. 168 Contents of the vehicle tool kit.

Wheel trim
